H-11740
METRO COLLECTION
COFFEE TABLE
TOOL NEEDED
Allen Wrench
(included)
Tabletop x 1
A
M6 x 45 mm Bolt x 6
NOTE: Use Allen wrench to tighten all bolts.
NOTE: Assemble table on a smooth,
non-marring surface to prevent scratching.
NOTE: Check that all parts are included.
1.
Using four M6 x 15 mm bolts (B), attach center beam
to each leg frame. (See Figure 1)
Figure 1
PAGE 1 OF 6
1-800-295-5510
uline.com
Two Person Assembly
Recommended
B
M6 x 15 mm Bolt x 4
ASSEMBLY
B
PARTS
Leg Frame x 2
2. Using six M6 x 45 mm bolts (A), attach leg frame and
center beam to tabletop. (See Figure 2)
NOTE: Do not fully tighten bolts until assembly is
complete.
Figure 2
Para Español, vea páginas 3-4.
Pour le français, consulter les pages 5-6.
Center Beam x 1
C
Adjustable Glide x 4
A
1124 IH-11740
