H-11739
METRO COLLECTION
END TABLE
TOOL NEEDED
Allen Wrench
(included)
Tabletop x 1
B
M6 x 15 mm Bolt x 8
NOTE: Use Allen wrench to tighten all bolts.
NOTE: Assemble table on a smooth,
non-marring surface to prevent scratching.
NOTE: Check that all parts are included.
1.
Using two M6 x 15 mm bolts (B), attach L-Bracket (D)
to leg frame. Repeat on other leg. (See Figure 1)
Figure 1
PAGE 1 OF 6
1-800-295-5510
uline.com
Two Person Assembly
Recommended
D
PARTS
Leg Frame x 2
C
Adjustable Glide x 4
ASSEMBLY
2. Using two M6 x 15 mm bolts (B), attach L-Bracket (D)
to underside of tabletop. Repeat on other side.
(See Figure 2)
NOTE: Do not fully tighten bolts until assembly is
complete.
Figure 2
B
Para Español, vea páginas 3-4.
Pour le français, consulter les pages 5-6.
A
M6 x 45 mm Bolt x 4
D
L-Bracket x 2
B
D
1124 IH-11739
