ASSEMBLY INSTRUCTIONS
for :
PRO-III
®
DON'T OVERLOAD YOUR VEHICLE!
3
@
X
100" =
lbs.
@
X
35" =
lbs.
WEIGHT CARRIED ABOVE THE FLOOR OF THE TRUCK BED (E.G. ON AN OVERHEAD TRUCK RACK)
WILL SIGNIFICANTLY INCREASE THE VEHICLE'S TENDENCY TO OVERTURN. ALWAYS KEEP
HEAVY LOADS EVENLY DISTRIBUTED AND AS LOW AS POSSIBLE. IT IS IMPORTANT TO NOTE THAT
THE KARGO MASTER RACK LOAD BEARING CAPACITY OF 1700 LBS. MAY BE GREATER THAN YOUR
TRUCK'S GAWR OR GVWR CAPACITY, AND IS PROBABLY GREATER THAN THE WEIGHT THAT CAN BE
SAFELY CARRIED OVERHEAD.

Advertisement

loading
Need help?

Need help?

Do you have a question about the PRO-III and is the answer not in the manual?

Questions and answers

Summary of Contents for Kargo Master PRO-III

  • Page 1 HEAVY LOADS EVENLY DISTRIBUTED AND AS LOW AS POSSIBLE. IT IS IMPORTANT TO NOTE THAT THE KARGO MASTER RACK LOAD BEARING CAPACITY OF 1700 LBS. MAY BE GREATER THAN YOUR TRUCK'S GAWR OR GVWR CAPACITY, AND IS PROBABLY GREATER THAN THE WEIGHT THAT CAN BE...
  • Page 2 RO - 1/2", 9/16", & 3/4"...
  • Page 3 (2 ea.) (2 ea.) (8 ea.) (4 ea.) (4 ea.) (2 ea.) (4 ea.) 1/2" x 2 1/4" 5/16" x 3/4" 1/2" x 3 1/2" 5/16" x 3/4" 5/16" x 2" 3/8" x 2" 3/8" x 1 3/4" Button Head Bolt Hex Bolt Carriage Bolt Button Head Bolt...
  • Page 4 STEP 1 #1 = Cover entire swedge joints with silicone sealant and join FRONT and REAR side channels together, there is a LEFT & RIGHT FRONT, with the Right marked with a GREEN dot on the overlapping plate. There is a RIGHT & LEFT REAR.
  • Page 5 STEP 4 #1 = Cover entire swedge joints with silicone sealant and insert the CENTER CROSS BAR into the SIDE RAIL CUPS and attach with bolts E, washers K and lock nuts N. STEP 5 #1 = Insert PLASTIC CAPS onto the rear crossbar uprights, (the tall side of the tube).
  • Page 6 STEP 7 NOTE: If it is not possible to locate a second hole close to the front leg, or if you would like to mount Be sure MOUNTING PLATES are as far forward #1 = your rack without drilling into your truck’s bed rail, towards the cab as possible, and as far back as possible please see OPTIONAL MOUNTING METHODS on for rear mounts, as shown.
  • Page 7 STEP 8 #1 = Attach front leg with bolts A, washers H, and nut L. Center rack on truck bed. Tighten up the bolts on the crossbar and clamp plates as well as the set screws P. STEP 9 #1 = Attach the front SUPPORT UPRIGHT where the 1”...
  • Page 8 PRO 3 Footplate Pre-Drilled Holes 3" Rack Mounting Bracket Drill 1st hole in truck bedrail, through pre-drilled hole in the footplate, as shown. Optional T-nut TRUCKs’ BEDRAIL Optional Clamp-On Mount Follow instruction that come with your Stake Pocket T- Bolt Mounting Kit #31560 NO DRILL clamp-on mounting OPTION...
