LOVATO ELECTRIC ADXT Series Communications Manual
  1. Manuals
  2. Brands
  3. LOVATO ELECTRIC Manuals
  4. Controller
  5. ADXT Series
  6. Communications manual
LOVATO ELECTRIC ADXT Series Communications Manual

LOVATO ELECTRIC ADXT Series Communications Manual

Soft starters, modbus-tcp
Hide thumbs Also See for ADXT Series:
Table of Contents

Advertisement

Available languages

Available languages

Quick Links

Download this manual
LOVATO ELECTRIC S.P.A.
24020 GORLE (BERGAMO) ITALIA
VIA DON E. MAZZA, 12
TEL. 035 4282111
L
E
E-mail info@
ovato
lectric.com
L
E
Web www.
ovato
lectric.com
CONTENTS
1. INTRODUCTION .............................................................................................................................................................................................................................................................................
1.1 Product design ........................................................................................................................................................................................................................................................................
1.2 Connections ............................................................................................................................................................................................................................................................................
2. INSTALLATION ...............................................................................................................................................................................................................................................................................
2.1 Installing the expansion card ...................................................................................................................................................................................................................................................
2.2 Network connection ................................................................................................................................................................................................................................................................
2.3 Network establishment ............................................................................................................................................................................................................................................................
2.4 Addressing ..............................................................................................................................................................................................................................................................................
3. DEVICE CONFIGURATION ..............................................................................................................................................................................................................................................................
3.1 Configure network settings via the starter ...............................................................................................................................................................................................................................
3.2 Enabling network control ........................................................................................................................................................................................................................................................
4. PLC CONFIGURATION ....................................................................................................................................................................................................................................................................
5. OPERATION ....................................................................................................................................................................................................................................................................................
5.1 Device classification ................................................................................................................................................................................................................................................................
5.2 Ensuring safe and successful control ......................................................................................................................................................................................................................................
5.3 Feedback LEDs ........................................................................................................................................................................................................................................................................
6. MODBUS REGISTERS ....................................................................................................................................................................................................................................................................
6.1 Command and configuration registers (read/write) .................................................................................................................................................................................................................
6.2 Parameter management ..........................................................................................................................................................................................................................................................
6.3 Status reporting registers (read only) .....................................................................................................................................................................................................................................
6.4 Trip Codes ................................................................................................................................................................................................................................................................................
7. NETWORK DESIGN ........................................................................................................................................................................................................................................................................
7.1 Star topology ..........................................................................................................................................................................................................................................................................
7.2 Line topology ..........................................................................................................................................................................................................................................................................
7.3 Ring topology ..........................................................................................................................................................................................................................................................................
7.4 Combined topology ..................................................................................................................................................................................................................................................................
8. SPECIFICATIONS ............................................................................................................................................................................................................................................................................
COMPATIBILITY
The ADXTTCP Modbus-TCP card is suitable for soft starters ADXT series.
DISCLAIMER
The examples and diagrams in this manual are included solely for illustrative purposes. The information contained in this manual is subject to change at any time and without prior notice. In no
event will responsibility or liability be accepted for direct, indirect or consequential damages resulting from the use or application of this equipment.
Failure to follow the information and instructions in this manual will void the warranty.
WARNINGS
It is the installer's responsibility to follow all instructions in this manual and to follow correct electrical practice.
WARNINGS
For your safety, isolate the soft starter completely from mains voltage before attaching or removing accessories.
WARNINGS
Inserting foreign objects or touching the inside of the starter while the expansion port cover is open may endanger personnel, and can damage the starter.
GB SOFT STARTERS ADXT...
MODBUS-TCP COMMUNICATION MANUAL
I SOFT STARTER ADXT...
MANUALE DI COMUNICAZIONE MODBUS-TCP
ADXTTCP
2
2
2
2
2
2
2
2
3
3
3
3
4
4
4
4
4
4
4
5
7
8
8
8
9
9
9
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ADXT Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for LOVATO ELECTRIC ADXT Series

Summary of Contents for LOVATO ELECTRIC ADXT Series

  • Page 1: Table Of Contents

    8. SPECIFICATIONS ......................................................COMPATIBILITY The ADXTTCP Modbus-TCP card is suitable for soft starters ADXT series. DISCLAIMER The examples and diagrams in this manual are included solely for illustrative purposes. The information contained in this manual is subject to change at any time and without prior notice. In no event will responsibility or liability be accepted for direct, indirect or consequential damages resulting from the use or application of this equipment.

  • Page 2: Introduction

    INTRODUCTION 1.1 Product design The Modbus TCP Card allows the soft starter to connect to an Ethernet network and be controlled or monitored using an Ethernet communication model. Familiarity with Ethernet protocols and networks is required to operate the device successfully. For difficulties using this device with third party products, including PLCs, scanners and commissioning tools, contact the relevant supplier.

  • Page 3: Device Configuration

    DEVICE CONFIGURATION NOTE The Error LED flashes whenever the device is receiving power but is not connected to a network. The Error LED will flash occasionally during the configuration process. NOTE At power-up, the card loads the IP address stored in the soft starter. –...

  • Page 4: Operation

    OPERATION The Modbus TCP Card must be controlled by a Modbus client (such as a PLC) which complies with the Modbus Protocol Specification. For successful operation, the client must also support all functions and interfaces described in this document. NOTE The available features and parameter details may vary according to the model and software version of the starter.

  • Page 5: Status Reporting Registers (Read Only)

    6.3 Status reporting registers (read only) Register Description Bits Details 30003 ~ 30008 Reserved 30600 Product information 0 to 5 Binary protocol version 6 to 8 Reserved 9 to 15 Product type code: 13 = ADXT 30601 Model number 0 to 7 Reserved 8 to 15 Soft starter model ID...
  • Page 6 Register Description Bits Details 30619 Trip code 0 to 7 Refer to Trip Codes 8 to 15 Reserved 30620 Reserved 30621 Frequency 0 to 15 Frequency (Hz) 30622 Ground current 0 to 15 Ground current (A) 30623~30631 Reserved NOTE The reset input is normally closed by default. If parameter 7I Reset/Enable Logic is set to normally open, the reported state will be inverted (0 = closed, 1 = open). NOTE For model ADXT0060 and smaller, current reported via communications is 10 times greater than the actual value (displayed on the keypad).

  • Page 7: Trip Codes

    Motor Connection T1 Motor Connection T2 Motor Connection T3 Firing Fail P1 Firing Fail P2 Firing Fail P3 VZC Fail P1 VZC Fail P2 VZC Fail P3 Low Control Volts 84~96 Internal fault x. Contact Lovato Electric with the fault code (X)

  • Page 8: Network Design

    NETWORK DESIGN The device supports star, line and ring topologies. 7.1 Star topology In a star network, all controllers and devices connect to a central network switch. 7.2 Line topology In a line network, the controller connects directly to one port of the first device. The second Ethernet port connects to another device, which in turn connects to another device until all devices are connected.

  • Page 9: Ring Topology

    7.3 Ring Topology In a ring topology network, the controller connects to the first card, via a network switch. The second Ethernet port of the card connects to another device, which in turn connects to another device until all devices are connected. The final device connects back to the switch. The device supports beacon based ring node configuration.
  • Page 10 SOMMARIO 1. INTRODUZIONE ......................................................1.1 Design del prodotto ....................................................1.2 Connessioni ......................................................2. INSTALLAZIONE ......................................................2.1 Installazione della scheda di espansione ..............................................2.2 Collegamento di rete ....................................................2.3 Stabilire una connessione di rete ................................................2.4 Indirizzamento ......................................................3. CONFIGURAZIONE DEL DISPOSITIVO ................................................3.1 Configurare i parametri di rete ................................................

  • Page 11: Introduzione

    INTRODUZIONE 1.1 Design del prodotto La scheda Modbus-TCP permette al soft starter di collegarsi ad una rete Ethernet per controllo e monitoraggio. 1.2 Connections 2 x porte ethernet RJ45 2 connettore pin per TA guasto a terra (solo modelli selezionati) connettore DB9 per tastiera remota opzionale ADXTC01 INSTALLAZIONE 2.1 Installazione della scheda di espansione...

  • Page 12: Configurazione Del Dispositivo

    CONFIGURAZIONE DEL DISPOSITIVO I parametri di comunicazione di rete della scheda devono essere impostati tramite l'avviatore statico. – La scheda utilizza di default un indirizzo IP statico. Per abilitare l'indirizzamento via DHCP impostare il parametro 12T DHCP a ‘Enable’. – L'indirizzo IP può essere configurato tramite il parametro dedicato sul soft starter. NOTA Il LED di errore Error lampeggia quando il dispositivo è...

  • Page 13: Funzionamento

    FUNZIONAMENTO La scheda Modbus TCP deve essere gestita con un client Modbus (ad esempio un PLC) conforme alle specifiche del protocollo Modbus. Per un funzionamento corretto, il client deve supportare anche tutte le funzioni e interfacce descritte in questo documento. 5.1 Classificazione del dispositivo La scheda Modbus TCP è...

  • Page 14: Registri Di Stato (Sola Lettura)

    6.3 Registri di stato (sola lettura) Registro Descrizione Dettagli 30003 ~ 30008 Riservato 30600 Versione 0 ~ 5 Versione protocollo binario 6 ~ 8 Riservato 9 ~ 15 Codice del tipo di prodotto: 13 = ADXT 30601 Numero di modello 0 ~ 7 Riservato 8 ~ 15...
  • Page 15 Registro Descrizione Dettagli 30619 Codice di allarme 0 ~ 7 Consultare Codici di allarme 8 ~ 15 Riservato 30620 Riservato 30621 Frequenza 0 ~ 15 Frequenza (Hz) 30622 Corrente di terra 0 ~ 15 Corrente di terra (A) 30623~30631 Riservato NOTA L'ingresso di reset è...

  • Page 16: Codici Di Allarme

    Collegamento motore T2 Collegamento motore T3 Mancata accensione P1 Mancata accensione P2 Mancata accensione P3 Errore VCZ P1 Errore VCZ P2 Errore VCZ P3 Bassa tensione controllo 84~96 Guasto interno X. Rivolgersi a Lovato Electric con il codice di errore (X)

  • Page 17: Schema Di Configurazione Della Rete

    SCHEMA DI CONFIGURAZIONE DELLA RETE Il dispositivo supporta le topologie a stella, lineare e ad anello. 7.1 Topologia a stella In un rete a stella, tutti i controllori e i dispositivi sono collegati a un commutatore di rete centrale. 7.2 Topologia lineare In una rete con topologia lineare, il controllore è...

  • Page 18: Topologia Ad Anello

    7.3 Topologia ad anello In una rete con topologia ad anello, il controllore è collegato alla prima scheda, tramite un commutatore di rete. La seconda porta Ethernet della scheda consente il collegamento di un altro dispositivo, che a sua volta è collegato a un altro dispositivo finché tutti i dispositivi risultano collegati. Il dispositivo finale viene collegato al commutatore. Il dispositivo supporta la configurazione di nodi ad anello basata su beacon.
