BrandMe
SKU:140B/W
Assembly Instructions
1 Floor Mounting Option - Freestanding
USING FOUR M6x14mm FLAT HEAD SCREWS (PROVIDED).
Body bottom plate
Countersunk holes
for screwing base
plate to body
*NOTE: FLOOR STAND MUST BE TRANSPORTED WITHOUT THE STABILITY PLATE ATTACHED TO PREVENT DAMAGE.
©Compulocks Brands Inc. All Rights Reserved
INSTALL BASE PLATE TO BODY BOTTOM PLATE
TIGHTEN USING T-30 TORX SCREWDRIVER
Base plate
www.compulocks.com | online@maclocks.com | +1 800-948-0344
1A Floor Mounting Option - Bolt To Floor
COMPLETE STEP 1
TILT
Align shapes
when installing
Straight holes
for mounting base
plate & body
to floor
REMOVE RUBBER CAP
Sheet 1 of 5
Advertisement
Related Manuals for compulocks BrandMe 140B
Summary of Contents for compulocks BrandMe 140B
- Page 1 & body plate to body to floor *NOTE: FLOOR STAND MUST BE TRANSPORTED WITHOUT THE STABILITY PLATE ATTACHED TO PREVENT DAMAGE. ©Compulocks Brands Inc. All Rights Reserved www.compulocks.com | online@maclocks.com | +1 800-948-0344 Sheet 1 of 5...
- Page 2 1.181in 12.00in 30mm 304.80mm 3.150in 80mm LOCATE SCREW HOLES IN BODY BOTTOM PLATE BOLT TO FLOOR USING APPROPRIATE BOLTS FOR FLOOR TYPE (NOT PROVIDED) ©Compulocks Brands Inc. All Rights Reserved www.compulocks.com | online@maclocks.com | +1 800-948-0344 Sheet 2 of 5...
-
Page 3: Cable Management Options
D - EXIT IN BASE PLATE *for easier insertion of the rubber cap, use a flat head screwdriver or simlliar object to adjust the cap. ©Compulocks Brands Inc. All Rights Reserved www.compulocks.com | online@maclocks.com | +1 800-948-0344 Sheet 3 of 5... -
Page 4: Install Device
ADJUST TILT RESISTANCE BY (OR VESA COMPATIBLE MOUNTING SOLUTION) TIGHTENING THE SCREW LOCATED USING FOUR M4x8mm PHILLIPS PAN HEAD SCREWS (PROVIDED) ON THE HINGE ASSEMBLY ©Compulocks Brands Inc. All Rights Reserved www.compulocks.com | online@maclocks.com | +1 800-948-0344 Sheet 4 of 5... - Page 5 Phillips Screw printing services for recommended material and print methods. Hardware Kit 150mm 5.9in 64mm 2mm Cover Panel BrandMe Stand Base Plate 2.51in 160mm 6.3in ©Compulocks Brands Inc. All Rights Reserved www.compulocks.com | online@maclocks.com | +1 800-948-0344 Sheet 5 of 5...
- Page 6 (SUPLLIED WITH BRANDME STAND) RETURN BRANDME TO UPRIGHT AND READJUST VESA MOUNTING PLATE BRANDME BOTTOM VIEW In The Box Left Base Plate Right Base Plate ©Compulocks Brands Inc. All Rights Reserved www.compulocks.com | online@maclocks.com | +1 800-948-0344 Sheet 1 of 1...
