Core Stand
SKU: 111B/111W
Assembly Instructions
COUNTER MOUNTING PATTERN
0.33in
8.3mm
0.26in
6.7mm
2
INSTALL STAND COVER
IN THE BOX
©Compulocks Brands Inc. All Rights Reserved.j
2.86in
72.5mm
0.26in
6.7mm
1.40in
35.5mm
3
WIRE INLET
LOCK SLOTS
Fixed Stand
www.compulocks.com | online@maclocks.com | +1 800-948-0344
1
PLEASE USE M6 SCREWS
INSTALL YOUR TABLET
ENCLOSURE AS SHOWN
USING M4 SCREWS
PROVIDED
Plastic cover
M4x8MM Phillips Screws
LOCATE YOUR STAND
AND MOUNT IT
MOUNTING SCREWS
NOT PROVIDED
4
Sheet 1 of 1
