Core stand - Swivel Plate Add-on
Assembly Instructions
Fixed Mounting
Swivel Mounting
©Compulocks Brands Inc. All Rights Reserved.j
SKU: SWB
PRIOR TO INSTALL OF
VHB PAD CLEAN BOTH
MOUNTING SURFACES USING
ALCOHOL PADS PROVIDED
VHB PAD
Or
SWIVEL LOCKNUT
PLASTIC WASHER
SWIVEL DISK
FLAT HEAD
MOUNTING SCREWS
(PROVIDED)
FIXING DISK
www.compulocks.com | online@maclocks.com | +1 800-948-0344
CLOSE THE
PLASTIC CAP
PRIOR TO INSTALL OF
VHB PAD CLEAN BOTH
MOUNTING SURFACES USING
ALCOHOL PADS PROVIDED
VHB PAD
Sheet 1 of 2
