- Page 1 STEALTH LEG PRESS STLTHLEGPRS 401376 Operator’s Manual Read the Operator’s Manual entirely. When you see this symbol, the subsequent instructions and warnings are serious follow without exception. Your life and the lives of others depend on it!
- Page 2 PARTS DIAGRAM / EXPLODED VIEW DESCRIPTION DESCRIPTION Left Arm Frame (19) Rubber Cushion Right Arm Frame (20) Φ48 End Cap Connecting Frame (21) Flat WasherΦ13.5*Φ24*2.5 Upper Contacting Frame (22) Nut M12 Weight Plate Holder (23) Hex Bolt M12*80 Countersunk Head Screw Fixing Frame (24) M8*45...
- Page 3 ASSEMBLY INSTRUCTIONS Step 1 Connect Left &Right Arm Frame (1&2) and Connecting Frame (3), using Flat Washer Φ11*Φ20.2(25), Spring Washer Φ10 (26), Countersunk Head Screw M8*25(29) and Hex Bolt M10*20(27)
- Page 4 ASSEMBLY INSTRUCTIONS Step 2 1. Remove the Small Pin (16), Buffer (34) and Plastic Sleeve (35) from the Weight Plate Holder (5). 2. Place the Upper Connecting Frame (4) between the Left &Right Arm Frame (1&2). Then connect Left &Right Arm Frame (1&2), Upper Connecting Frame (4) and Weight Plate Holder (5), using Flat Washer Φ13.5*Φ24*2.5(21), M12 Nut (22) and Hex Bolt M12*80(23).
- Page 5 ACKNOWLEDGEMENT OF RISK AND RELEASE OF LIABILITY The use of any equipment, including this one, involves the potential risk of injury. Apart from any warranty claim that might be presented for a claimed defect in material or workmanship of the product, you accept and assume full responsibility for any and all injuries, damages (both economic and non-economic), and losses of any type, which may occur, and you fully and forever release and discharge Titan, its insurers, employees, officers, directors, associates, and agents from any and all claims, demands, damages,...
- Page 6 NEED HELP? CONTACT US FIRST. 1-888-410-1503 info@titan.fitness www.titan.fitness © 2023 Titan Brands...
