- Page 1 SMITH MACHINE SMTHMACHKIT 401254 Operator’s Manual Read the Operator’s Manual entirely. When you see this symbol, the subsequent instructions and warnings are serious follow without exception. Your life and the lives of others depend on it!
- Page 2 PARTS DIAGRAM / EXPLODED VIEW...
- Page 3 DESCRIPTION DESCRIPTION MAIN FRAME – L (22) STRETCH CORDS HOLDER MAIN FRAME – R (23) END CAP 45 LONGER PLATE STORAGE TOP CROSS FRAME GUN RAKC (25) END CAP 38 GUIDE ROD (26) RUBBER BUMPER 77*44*13 SLIDING MECHANISM (27) CABLE ASSEMBLY –...
- Page 4 ASSEMBLY INSTRUCTIONS STEP 1 Connect the Top Cross Frames (2) to the Main Frames (1 and 2), using 4 Allen Bolts (33), 12 Flat Washers (29), and 8 Lock Nuts (32). NOTE: Please tighten all the nuts and bolts with wrenches...
- Page 5 ASSEMBLY INSTRUCTIONS STEP 2 Loosen the Allen Bolt (42) and pull-up the Smith Guide Rod (5). Connect the Barbell (8) to the Guide Rod (5), then pull-down the Guide Rod (5) and tighten the Allen Bolt (42).
- Page 6 ASSEMBLY INSTRUCTIONS STEP 3 Connect the Counter Balance Cable (27) to the Sliding Mechanism by removing the Flat Washer at the end of the cable, then connect the Cable to the hole in the Sliding Mechanism, tighten it with 2 Bolts.
- Page 7 ASSEMBLY INSTRUCTIONS STEP 4 Install the Weight Plate Storage Bar (21) to the Main Frames (1 and 2) using 3 Allen Bolts (34) and 3 Flat Washers (29). Fixing the Stretch Cord Holders (22) to the Main Frame (1) using 2 Flat Washers (30) and 2 Allen Bolts (36).
- Page 8 ACKNOWLEDGEMENT OF RISK AND RELEASE OF LIABILITY The use of any equipment, including this one, involves the potential risk of injury. Apart from any warranty claim that might be presented for a claimed defect in material or workmanship of the product, you accept and assume full responsibility for any and all injuries, damages (both economic and non-economic), and losses of any type, which may occur, and you fully and forever release and discharge Titan, its insurers, employees, officers, directors, associates, and agents from any and all claims, demands, damages,...
- Page 9 NEED HELP? CONTACT US FIRST. 1-888-410-1503 info@titan.fitness www.titan.fitness © 2021 Titan Brands...
