  • Page 1 MPN: SWBENCH1-SWBENCH2 Owner’s Manual...
  • Page 2 P A R T S & H A R D W A R E L I S T B O X 1 B O X 2 (SWBENCH1) (SWBENCH2) KEY NUMBER/LETTER DESCRIPTION UPRIGHT SIDE SUPPORT FRAME – 1 SIDE SUPPORT FRAME – 2...
  • Page 3 A S S E M B L Y I N S T R U C T I O N S For Step 1 1. Connect UPRIGHTS (A) to SIDE SUPPORT FRAMES – 1 (B) and SIDE SUPPORT FRAMES – 2 (C) using M12x85 BOLTS (1), M12 WASHERS (2), and M12 NYLON NUTS (3).
  • Page 4 For Steps 2–3 2. Attach a BRIDGE FRAME (D) to the SIDE SUPPORT FRAMES – 1 (B) using M12x85 BOLTS (1), M12 WASHERS (2), and M12 NYLON NUTS (3). 3. Secure the other BRIDGE FRAME (D) to the SIDE SUPPORT FRAMES – 2 (C) using M12x85 BOLTS (1), M12 WASHERS (2), and M12 NYLON NUTS (3).
  • Page 5 This concludes the assembly of your product. Make sure to tighten all nut-and-bolt combinations before use. Enjoy! NEED HELP? CONTACT US FIRST. 1 (800) 605-8241 info@titandistributorsinc.com / www.titan.fitness Business Hours: Monday–Friday • 8:00 a.m.–5:00 p.m. (CT)
