Field Implementation & Environmental Conditions
# Description
1 Rail slide lock
2 DIN rail mounting bracket
Figure 2. DIN Rail Mounting Position
3.4.5. Ventilation
To ensure a proper ventilation of the equipment, a free gap of at least 2 cm must be respected in front of all
upper and lower ventilation openings of the unit. A free gap of at least 1 cm must be respected on each side of
the unit.
