UG594: EFR32xG26 Explorer Kit User's
Guide
The EFR32xG26 Explorer Kit is an ultra-low cost, small form factor
development and evaluation platform for the EFR32MG26 Wire-
less System-on-Chip.
The EFR32xG26 Explorer Kit is focused on rapid prototyping and concept creation of IoT
applications. It is designed around the EFR32MG26 SoC, which is an ideal device family
for developing energy-friendly connected IoT applications.
The kit features a USB interface, an on-board SEGGER J-Link debugger, two user-LEDs
and two buttons, and support for hardware add-on boards via a mikroBus socket and a
Qwiic connector. The hardware add-on support allows developers to create and proto-
type applications using a virtually endless combination of off-the-shelf boards from MIK-
ROE, SparkFun, Adafruit, and Seeed Studio.
silabs.com | Building a more connected world.
Copyright © 2024 by Silicon Laboratories
TARGET DEVICE
• EFR32MG26 Wireless System-on-Chip
(EFR32MG26B510F3200IM48-B)
• High-performance 2.4 GHz radio
• 32-bit ARM® Cortex®-M33 with 78 MHz
maximum operating frequency
• 3200 kB flash and 512 kB RAM
KIT FEATURES
• 2x User LEDs and push buttons
• 28-pin 2.54 mm breakout pads
• mikroBUS™ socket
• Qwiic® connector
• SEGGER J-Link on-board debugger
• Virtual COM port
• Packet Trace Interface (PTI)
• USB-powered
SOFTWARE SUPPORT
• Simplicity Studio™
ORDERING INFORMATION
• xG26-EK2709A
Rev. 1.0
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Silicon Laboratories EFR32xG26
Summary of Contents for Silicon Laboratories EFR32xG26
- Page 1 System-on-Chip. • EFR32MG26 Wireless System-on-Chip (EFR32MG26B510F3200IM48-B) The EFR32xG26 Explorer Kit is focused on rapid prototyping and concept creation of IoT • High-performance 2.4 GHz radio applications. It is designed around the EFR32MG26 SoC, which is an ideal device family •...
- Page 2 Table of Contents 1. Introduction ....... . 3 1.1 Kit Contents ....... 3 1.2 Getting Started .
- Page 3 The following items are included in the box: • 1x EFR32xG26 Explorer Kit board (BRD2709A) 1.2 Getting Started Detailed instructions for how to get started with your new EFR32xG26 Explorer Kit can be found on the Silicon Labs web page: https:// www.silabs.com/dev-tools 1.3 Hardware Content...
- Page 4 UG594: EFR32xG26 Explorer Kit User's Guide Introduction 1.4 Kit Hardware Layout EFR32xG26 Explorer Kit layout is shown below. 35.56 mm EFR32MG26 Wireless SoC Top View Push Buttons Qwiic Connector LEDs 57.38 mm Breakout Pads On-board USB J-Link Debugger mikroBUS Socket...
- Page 5 UG594: EFR32xG26 Explorer Kit User's Guide Specifications 2. Specifications 2.1 Recommended Operating Conditions Table 2.1. Recommended Operating Conditions Parameter Symbol Unit USB Supply Input Voltage – +5.0 – Supply Input Voltage (VMCU supplied externally) +3.3 VMCU 2.2 Current Consumption The operating current of the board greatly depends on the application and the amount of external hardware connected. The table below attempts to give some indication of typical current consumptions for the EFR32MG26 and the on-board debugger.
- Page 6 UG594: EFR32xG26 Explorer Kit User's Guide Hardware 3. Hardware The core of the EFR32xG26 Explorer Kit is the EFR32MG26 Wireless System-on-Chip. Refer to section 1.4 Kit Hardware Layout placement and layout of the hardware components. 3.1 Block Diagram An overview of the EFR32xG26 Explorer Kit is illustrated in the figure below.
- Page 7 Wireless SoC Peripherals Figure 3.2. EFR32xG26 Explorer Kit Power Topology The 5 V power net on the USB bus is regulated down to 3.3 V using a low-dropout regulator (LDO). An automatic isolation circuit iso- lates the LDO when the USB cable is not plugged in.
- Page 8 3.5 On-board Debugger The EFR32xG26 Explorer Kit contains a microcontroller separate from the EFR32MG26 Wireless SoC that provides the user with an on-board J-Link debugger through the USB Type-C port. This microcontroller is referred to as the "on-board debugger", and is not pro- grammable by the user.
- Page 9 3.6 Connectors The EFR32xG26 Explorer Kit features a USB Type-C connector, 28 breakout pads, a mikroBUS connector for connecting mikroBUS add-on boards, and a Qwiic connector for connecting Qwiic Connect System hardware. The connectors are placed on the top side of the board, and their placement and pinout are shown in the figure below.
- Page 10 The pin-routing on the Wireless SoC is very flexible, so most peripherals can be routed to any pin. However, pins may be shared be- tween the breakout pads and other functions on the EFR32xG26 Explorer Kit. The table below includes an overview of the breakout pads and functionality that is shared with the kit.
- Page 11 UG594: EFR32xG26 Explorer Kit User's Guide Hardware Connection Shared Feature Peripheral Mapping PD04 PTI_DATA PTI_DATA 3.6.2 Mini Simplicity Connector The Mini Simplicity Connector (not mounted) is a 10-pin, 1.27 mm pitch connector that allows the use of an external debugger such as the one found on a Silicon Labs Wireless Starter Kit mainboard.
- Page 12 Qwiic connector. When inserting a mikroBUS add-on board, refer to the orientation notch on the EFR32xG26 Explorer Kit, shown in the figure below, to ensure correct orientation. Add-on boards have a similar notch that needs to be lined up with the one shown below.
- Page 13 The EFR32xG26 Explorer Kit features a Qwiic connector compatible with Qwiic Connect System hardware. The Qwiic connector pro- vides an easy way to expand the functionality of the EFR32xG26 Explorer Kit with sensors, LCDs, and other peripherals over the I interface.
- Page 14 UG594: EFR32xG26 Explorer Kit User's Guide Hardware 3.6.5 Debug USB Type-C Connector The debug USB port can be used for uploading code, debugging, and as a Virtual COM port. More information is available in section Debugging. silabs.com | Building a more connected world.
- Page 15 4. Debugging The EFR32xG26 Explorer Kit contains an on-board SEGGER J-Link Debugger that interfaces to the target EFR32MG26 using the Seri- al Wire Debug (SWD) interface. The debugger allows the user to download code and debug applications running in the target EFR32MG26.
- Page 16 UG594: EFR32xG26 Explorer Kit User's Guide Schematics, Assembly Drawings, and BOM 5. Schematics, Assembly Drawings, and BOM Schematics, assembly drawings, and Bill of Materials (BOM) are available through Simplicity Studio when the kit documentation pack- age has been installed. They are also available from the kit page on the Silicon Labs website: silabs.com.
- Page 17 UG594: EFR32xG26 Explorer Kit User's Guide Kit Revision History and Errata 6. Kit Revision History and Errata 6.1 Revision History The kit revision can be found printed on the box label of the kit, as outlined in the figure below. The kit revision history is summarized in the table below.
- Page 18 UG594: EFR32xG26 Explorer Kit User's Guide Board Revision History and Errata 7. Board Revision History and Errata 7.1 Revision History The board revision can be found laser printed on the board, and the board revision history is summarized in the following table.
- Page 19 UG594: EFR32xG26 Explorer Kit User's Guide Document Revision History 8. Document Revision History Revision 1.0 November 2024 • Initial document release. silabs.com | Building a more connected world. Rev. 1.0 | 19...
