OBJECT SCAN 6 The operation of RAYDENT Converter
6.4.9.2 Alignment of Bites
It is recommended to align from partial bites, separately made for left and right, than with
full bites using 3~4 teeth.
No.
1
2
3
6.4.9.2.1 Alignment of Full Bites
Figure
Open maxilla/mandible/bite scan data or
select three objects (maxilla, mandible,
bite) from the object list. If editing is
needed for the object, please do so
before the alignment.
Pressing the [
Align mode and is set to maxilla
alignment step.
Alignment step provides 3 windows. The
window on the top displays the result,
and two windows on the bottom can be
used to set alignment points.
76
Description
] button enters the Bite
