ray RAYSCAN OBJECT SCAN User Manual page 31

5-2 Face Viewer
5-3 3D Viewer
5-4 R2Gate
5-2 [Convert to STL]
5-2 [Edit STL]
5.1.2 Configuration screen
1
2
3
OBJECT SCAN 5 How to use RAYDENT Connect
Run the program to check and edit Smile or Scout pictures of
selected patients.
Run the 3D Viewer of the selected patient image.
Run the R2Connector of the selected patient image and you can
run the R2Gate program.
The selected object image can be converted to STL by RAYDENT
Converter program.
The selected STL file can be edited with the RAYDENT Converter
program.
31
