6.4.9 Aligning Objects
6.4.9.1 Alignment of Two Objects
No.
1
2
3
4
OBJECT SCAN 6 The operation of RAYDENT Converter
Figure
Open or select two objects from the list to
align.
Editing can be done if needed.
Pressing the [
Objects Align mode, and the initially
selected object is set as the fixed
reference.
Alignment step provides 3 windows. The
window on the top displays the result,
and two windows on the bottom can be
used to set alignment points.
Users can use the scroll bar to adjust the
opacity of the moving target and the fixed
reference.
73
Description
] button enters Two
