ray RAYSCAN OBJECT SCAN User Manual page 23

4.2.4 Object Scan Acquisition
Refer to "4.1 Object Positioning" to accurately acquires images. The RAYSCAN Studio UI
screen is sky blue.
No.
1
2
3
4
OBJECT SCAN 4 How to use RAYSCAN Object Scan
Figure
Select the modality work list (MWL) and
then select the [New] button to register a
new patient.
On the MWL screen, select the scan type
as [CT] and click the [OK] button.
Select the created information in the list
and click the [Scan] button on the lower
right corner.
Confirm patient information and select
[OK] button to go to acquisition step.
23
Description
