  • Page 1 Quick Start Guide ProRF...
  • Page 2 Overview 20.60 mm Card Swiping Area Reset Button LED Indicator Magnetic Tamper Switch 80.00 mm Name Description Green flashes once in a second: standby status. Ÿ LED Indicator Green glows continuously for 2 seconds: authentication success Ÿ Red glows continuously for 2 seconds: authentication failure Ÿ...
  • Page 3 Cables and Connectors DESCRIPTION WIRE Orange RJ45-6 RJ45-3 Orange+White RJ45-2 Green 5 6 7 8 9 10 11 12 RJ45-1 Green+White Brown Black BELL- Green+White BELL+ Orange+White Yellow Black Blue 5 6 7 8 5 6 7 1 2 White Purple Input: DC12V Operating Temperature: 20℃~65℃...

  • Page 4: Installation

    Installation 1) Paste the mounting template 2) Fix the back plate on the wall using sticker on the wall, and drill holes wall mounting screws. according to the mounting paper. 3) Attach the device to the back plate. 4) Fix the device to the back plate with a security screw.

  • Page 5: Power Connection

    PowerConnection +12V DC 12V DC Adaptor +12V DC Recommended power supply 1)12V ± 10%, at least 3000mA. 2)To share the power with other devices, use a power supply with higher current ratings.

  • Page 6: Ethernet Connection

    EthernetConnection 1) The device connects to the computer over an Ethernet through a switch. RJ 45 Ethernet Cable Network Cable Adaptor 2) The device directly connects to the computer. Ethernet Cable Default IP address: 192.168.1.201 Subnet mask: 255.255.255.0...

  • Page 7: Lock Relay Connection

    Lock Relay Connection The system supports Normally Opened Lock and Normally Closed Lock. Take Normally Closed Lock as an example below: Device not sharing power with the lock FR107 Diode Normally Closed Lock +12V DC Power +12VDC Power...
  • Page 8 Lock Relay Connection Device sharing power with the lock FR107 Diode Normally Closed Lock +12V DC +12V DC Power Notes: 1.TThe NO LOCK (normally opened at power on) is connected with ‘NO’ and ‘COM’ terminals, and the NC LOCK (normally closed at power on) is connected with ‘NC’ and ‘COM’ terminals. 2.
  • Page 9 Door Sensor, Exit Button,Bell & Alarm Connection Door Sensor ExitButton Alarm's power switch +12V BELL- BELL+ Alarm Bell...
  • Page 10 RS485 Connection 485B 485A 12VOUT RS485 Reader RS232 Connection (Optional) RS232 Cable Serial Printer...

  • Page 11: Wiegand Output Connection

    Wiegand Output Connection After a successful verification, the device will send Wiegand signals to the SRB access controller, then the SRB will output relay signals to trigger the relay to unlock the door. Power supply Lock 12VOUT Exit Button Security Relay Box Wiegand Input Connection IWD0 IWD1...

  • Page 12: Standalone Installation

    Standalone Installation Alarm Smoke Detector Door Sensor Exit Button Doorbell ZKBio CVSecurity Card Reader Lock TCP/IP...

  • Page 13: Quick Start Operations

    Quick Start Operations Login Webserver Open a browser to enter the address to log in the WebServer, the address is the https:// Serial IP Address, for example: https://192.168.1.201. Enter the account ID and password, the default account ID is: admin, password: admin@123. Note: After logging in for the first time, users need to reset their original password and log in again before they can use it.
  • Page 14 On ZKBio CVSecurity software, click [Access] > [Device] > [Search] > [Search], the list and total number of access controllers will be displayed. Click [Add] in operation column, a new window will pop-up. Select Icon type, Area, and Add to Level from each dropdown and click [OK] to add the device.
  • Page 15 Add Personnel Click [Personnel] > [Person] > [New] to add personnel information, register card number and set access levels. Click [OK] to save the user.
  • Page 16 Access Control Setting User can set Time Zones, Holidays, Access Levels, Personnel Access Levels and so on in Access module. For more details, please refer the user manual and the software instruction. Sync All Data to Devices Click [Access] > [Device], check the device you want to operate and click [Control] > [Synchronize All Data to Devices] to synchronize all the data to the device including the new users.
  • Page 17 Tips Forgot the Webserver password/IP address? First remove the back plate of the device and power on the device. Put the magnet on the tamper switch three times after you hear the tamper alarm sound for 30 seconds but no more than 60 seconds.
  • Page 18 ZKTeco Industrial Park, No. 32, Industrial Road, Tangxia Town, Dongguan, China. Phone : +86 769 - 82109991 : +86 755 - 89602394 www.zkteco.com Copyright © 2024 ZKTECO CO., LTD. All Rights Reserved.
