- Page 1 E231B Series LED Monitor User’s Manual ZHEJIANG DAHUA VISION TECHNOLOGY CO., LTD. V1.0.0...
- Page 2 User’s Manual Foreword General This manual introduces the installation, functions and operations of the E231B device (hereinafter referred to as the "Device"). Read carefully before using the device, and keep the manual safe for future reference. Models DHI-LM25-E231B、DHI-LM27-E231B Safety Instructions The following signal words might appear in the manual.
- Page 3 User’s Manual Interface Declaration This manual mainly introduces the relevant functions of the device. The interfaces used in its manufacture, the procedures for returning the device to the factory for inspection and for locating its faults are not described in this manual. Please contact technical support if you need information on these interfaces.
- Page 4 User’s Manual Important Safeguards and Warnings This section introduces content covering the proper handling of the device, hazard prevention, and prevention of property damage. Read carefully before using the device, and comply with the guidelines when using it. Transportation Requirements Transport the device under allowed humidity and temperature conditions.
- Page 5 User’s Manual ○ The voltage must meet the SELV (Safety Extra Low Voltage) requirements and not exceed ES-1 standards. ○ When the power of the device does not exceed 100 W, the power supply must meet LPS requirements and be no higher than PS2. ◇...
- Page 6 User’s Manual ● Use the power cords that are recommended for the region and conform to the rated power specifications. ● In a domestic environment this may cause radio interference in which case you may be required to take adequate measures. ●...
- Page 7 User’s Manual Table of Contents Foreword - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - Important Safeguards and Warnings - - - - - - - - - - - - - - - - - - - - - - - - - - Product Information...
- Page 8 Product Information 1. Packing List Figure 1-1 Packing List DHI-LM25-E231B ① ② ③ ④ E231B Series LED Monitor User’s Manual ZHEJIANG DAHUA VISION TECHNOLOGY CO., LTD. V1.0.0 ⑤ ⑥ Table 1-1 Packing List Meaning ① Display screen ② Stand Base ③...
- Page 9 User’s Manual Figure 1-2 Packing List DHI-LM27-E231B ① ② ③ ④ E231B Series LED Monitor User’s Manual ZHEJIANG DAHUA VISION TECHNOLOGY CO., LTD. V1.0.0 ⑤ ⑥ Table 1-2 Packing List Meaning ① Display screen Stand ② Base ③ ④ DP signal cable ⑤...
- Page 10 User’s Manual 2. Monitor Adjustments The adjustment functions of the display include tilt angle adjustment, screen vertical rotation angle adjustment, left and right rotation angle adjustment, and height adjustment, as shown in the figure below. Different types of displays have different adjustment functions, and the specific adjustment functions are subject to the actual model adjustment functions.
- Page 11 User’s Manual 3. Button Description Figure 3-1 Indicator and button display Table 3-1 Indicator description Name Description Steady white light indicates the power is on and the monitor runs normally. Red light indicates no video source and no horizontal or vertical signal LED indicator light detected or low voltage.
- Page 12 User’s Manual 4. Cable Connection Figure 4-1 Input and output interface HDMI Table 4-1 Input and output ports Port Function x1/ Use the HDMI cable to connect the HDMI IN interface of the product to the HDMI OUT HDMI interface of a PC. x1/ Use the DP cable to connect to a desktop PC.
- Page 13 User’s Manual 5. Menu Description The color and shape of the OSD menu of the actual computer may be slightly different from that shown in the figure, and everything that has been actually displayed shall prevail. Specifications of the OSD menu may change with improvements of functions without prior notice. Press the menu button on the control panel to access the monitor menu.
- Page 14 User’s Manual 6. Operation Menu(OSD) Function Descriptions Table 6-1 OSD Menu description Main Menu Sub Menu Option Standard Mode Off/On RTS/RPG Mode Off/On FPS Mode Off/On MOBA Mode Off/On Picture Mode Movie Mode Off/On Reading Mode Off/On Night Mode Off/On Eye Care Mode Off/On Brightness...
- Page 15 User’s Manual Main Menu Sub Menu Option Super Resolution: Off/Level 1-3 Dynamic OD: Off/Level 1-3/Topspeed Picture Enhancement HDR: Off/HDR Standard/HDR Movie MPRT: Off/On Reset Picture Enhancement: Off/On Refresh Rate: Game+ Off/On/Position(Top Right/Top Left/Bottom Right/Bottom Left) Game Crosshair: Off/Crosshair1/Crosshair2…… Crosshair Color: Red/Yellow/Green/Cyan/Blue/Purple/White Stop Watch: Off/15:00/30:00/45:00/60:00/ Game Aid Position(Top Right/Top Left/Bottom Right/Bottom Left)
- Page 16 User’s Manual Main Menu Sub Menu Option OSD Lock Off/On Energy Saving Power LED: Off/Level 1/Level 2/Level 3 Power Saving: Off/Level 1/Level 2 System Settings InputSource/Resolution/Picture Mode/HDR State: Information Restore Factory Yes/No Settings NOTE The OSD features in the table above are for reference only and may differ from the actual display, so the OSD features of the actual display shall prevail.
- Page 17 Dahua encourages users, partners, suppliers, government agencies, industry organizations and independent researchers to report any potential risks or vulnerabilities discovered on Dahua devices to Dahua PSIRT, for specific reporting methods, please refer to the cyber security section of Dahua's official website.
- Page 18 User’s Manual Dahua device supports password reset function. To reduce the risk of this function being used by threat actors, if there is any change in the information, please modify it in time. When setting security questions, it is recommended not to use easily guessed answers.
- Page 19 User’s Manual 4.1 Check online users It is recommended to check online users regularly to identify illegal users. 4.2 Check device log By viewing logs, you can learn about the IP addresses that attempt to log in to the device and key operations of the logged users.
- Page 20 E N AB L IN G A S MART ER SOCIET Y AND BET TER LIVIN G ZHEJIANG DAHUA VISION TECHNOLOGY CO., LTD. Address: No.1399, Binxing Road, Binjiang District, Hangzhou, P. R. China | Website: www.dahuasecurity.com | Postcode: 310053 Email: dhovereas@dhvisiontech.com | Tel: +86-571-87688888 28933188...
