E330C Series Gaming Monitor
User's Manual
ZHEJIANG DAHUA VISION TECHNOLOGY CO., LTD.
V1.0.0

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the E330C Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Dahua E330C Series

Summary of Contents for Dahua E330C Series

  • Page 1 E330C Series Gaming Monitor User’s Manual ZHEJIANG DAHUA VISION TECHNOLOGY CO., LTD. V1.0.0...
  • Page 2 User’s Manual Foreword General This manual describes the functions, operations, and precautions of the E330C Series Gaming Monitor Devices (hereinafter referred to as the "Devices"). Please read the device carefully before using it, and keep the instruction manual for future reference.
  • Page 3 User’s Manual There might be errors in the print or deviations in the description of the functions, operations and technical data. If there is any doubt or dispute, we reserve the right of final explanation. Upgrade the reader software or try other mainstream reader software if the manual (in PDF format) cannot be opened.

  • Page 4: Important Safeguards And Warnings

    User’s Manual Important Safeguards and Warnings This section introduces content covering the proper handling of the device, hazard prevention, and prevention of property damage. Read carefully before using the device, and comply with the guidelines when using it. Operation Requirements WARNING Do not tread on or squeeze the power line, especially the plug or connection point of the power line to the product.
  • Page 5 User’s Manual Do not hang or lean on the product. Doing so can cause the product to fall or become damaged. It may also cause injury to people. Pay special attention when children are nearby. If the product is installed on the wall, please make sure the wall's load bearing capacity is sufficient.
  • Page 6 User’s Manual CAUTION Do not adjust, maintain or modify if you do not have appropriate qualifications. Do not open or remove the rear cover, box or cover board of the product. Please contact the dealer or after-sales service center when in need of adjustment or maintenance. Only qualified service people can maintain.

  • Page 7: Table Of Contents

    User’s Manual Table of Contents Foreword - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - Ⅰ...

  • Page 8: Product Information

    User’s Manual Product Information 1. Packing List DHI-LM30-E330C Figure 1-1 Packing List ① ② ③ ④ ⑤ ⑪ ⑥ ⑦ ⑧ ⑨ ⑩ Table 1-1 Packing List Meaning ① Display screen Base/Stand ② Power cable ③ ④ Power adapter ⑤ DP signal cable ⑥...
  • Page 9 User’s Manual DHI-LM30-E330CA Figure 1-2 Packing List ① ② ③ ④ ⑤ ⑥ ⑦ ⑧ ⑨ Table 1-2 Packing List Meaning ① Display screen Base/Stand ② Power cable ③ ④ Power adapter ⑤ DP signal cable ⑥ Mount stud ⑦ ⑧...
  • Page 10 User’s Manual DHI-LM34-E330C Figure 1-3 Packing List ⑤ ① ② ③ ④ ⑪ ⑥ ⑦ ⑧ ⑨ ⑩ Table 1-3 Packing List Meaning ① Display screen Base/Stand ② Power cable ③ ④ DP signal cable ⑤ VESA connector ⑥ PM4*12 Screw bolts ⑦...
  • Page 11 User’s Manual DHI-LM34-E330CA Figure 1-4 Packing List ① ② ③ ④ MONITOR INSTALLATION GUIDE ⑤ ⑥ ⑦ ⑧ ⑨ Table 1-4 Packing List Meaning ① Display screen Base/Stand ② Power cable ③ ④ VESA connector ⑤ DP signal cable ⑥ PM4x16 Screw bolts ⑦...

  • Page 12: Monitor Adjustments

    User’s Manual 2. Monitor Adjustments The adjustment functions of the display include tilt angle adjustment, screen vertical rotation angle adjustment, left and right rotation angle adjustment, and height adjustment, as shown in the figure below. Different types of displays have different adjustment functions, and the specific adjustment functions are subject to the actual model adjustment functions.
  • Page 13 User’s Manual DHI-LM30-E330CA Figure 2-2 Monitor adjustments -5° 20° 115mm Tilting angle Height adjustment -5.0°(±2.0°) ~ +20°(±2.0°) 115mm(±5.0mm) Rotation angle ±25°(±2.5°) NOTE When adjusting the angle of the monitor, be sure not to touch or press the area of the screen. The above figure is for reference only, and everything is subject to the actual adjustment function.
  • Page 14 User’s Manual DHI-LM34-E330C Figure 2-3 Monitor adjustments -5° 15° Tilting angle -5.0°(±2.0°)- +15°(±2.0°) NOTE When adjusting the angle of the monitor, be sure not to touch or press the area of the screen. The above figure is for reference only, and everything is subject to the actual adjustment function.
  • Page 15 User’s Manual DHI-LM34-E330CA Figure 2-4 Monitor adjustments -5° 20° 100mm Tilting angle Height adjustment -5.0°(±2.0°) ~ +20°(±2.0°) 100mm(±5.0mm) Rotation angle ±20°(±2.0°) NOTE When adjusting the angle of the monitor, be sure not to touch or press the area of the screen. The above figure is for reference only, and everything is subject to the actual adjustment function.

  • Page 16: Button Description

    User’s Manual 3. Button Description DHI-LM30-E330C Figure 3-1 Indicator and button display Table 3-1 Indicator description (1) Name Description The blue light indicates that the power supply is normal and the monitor is running normally . Blinking red and blue lights indicate no video source, no LED indicator light horizontal or vertical signal or low voltage is detected.
  • Page 17 User’s Manual DHI-LM30-E330CA Figure 3-2 Indicator and button display Table 3-2 Indicator description (1) Name Description The blue light indicates that the power supply is normal and the monitor is running normally . Blinking red and blue lights indicate no video source, no LED indicator light horizontal or vertical signal or low voltage is detected.
  • Page 18 User’s Manual DHI-LM34-E330C Figure 3-3 Indicator and button display Table 3-3 Indicator description (1) Name Description The blue light indicates that the power supply is normal and the monitor is running normally. The red light indicates no video source, no horizontal or LED indicator light vertical signals, or too low a voltage.
  • Page 19 User’s Manual DHI-LM34-E330CA Figure 3-4 Indicator and button display Table 3-4 Indicator description (1) Name Description Solid blue light indicates that the power supply is normal and the monitor is running normally . Flashing blue light indicates no video source, no LED indicator light horizontal or vertical signal or low voltage is detected.

  • Page 20: Cable Connection

    User’s Manual 4. Cable Connection DHI-LM30-E330C Figure 4-1 Input and output interface HDMI 2 HDMI 1 DP 2 DP 1 Table 4-1 Input and output ports Port Function x2/ Use the HDMI cable to connect the HDMI IN interface of the product to the HDMI OUT HDMI interface of a PC.
  • Page 21 User’s Manual DHI-LM30-E330CA Figure 4-2 Input and output interface HDMI 2 HDMI 1 DP 2 DP 1 Table 4-2 Input and output ports Port Function x2/ Use the HDMI cable to connect the HDMI IN interface of the product to the HDMI OUT HDMI interface of a PC.
  • Page 22 User’s Manual DHI-LM34-E330C Figure 4-3 Input and output interface HDMI HDMI AUDIO Table 4-3 Input and output ports Port Function x2/ Use the HDMI cable to connect the HDMI IN interface of the product to the HDMI OUT HDMI interface of a PC. x2/ Use the DP cable to connect to a desktop PC.
  • Page 23 User’s Manual DHI-LM34-E330CA Figure 4-4 Input and output interface HDMI 2 HDMI 1 DP 2 DP 1 AUDIO Table 4-4 Input and output ports Port Function x2/ Use the HDMI cable to connect the HDMI IN interface of the product to the HDMI OUT HDMI interface of a PC.

  • Page 24: Menu Description

    User’s Manual 5. Menu Description The color and shape of the OSD menu of the actual computer may be slightly different from that shown in the figure, and everything that has been actually displayed shall prevail. Specifications of the OSD menu may change with improvements of functions without prior notice. DHI-LM30-E330C/E330CA The On-Screen Display (OSD) menu allows you to adjust the settings of your display, turn on the monitor and move the joystick to the right to display the navigation interface.
  • Page 25 User’s Manual DHI-LM34-E330C/E330CA The screen display (OSD) menu can be used to adjust settings of the monitor and is shown on the screen after the monitor is powered on and the M button is pressed. Step 1. Press the button M to activate the browser screen. Figure 5-2 OSD screen 3440 165hz...

  • Page 26: Operation Menu(Osd) Function Descriptions

    User’s Manual 6. Operation Menu(OSD) Function Descriptions DHI-LM30-E330C/E330CA Table 6-1 OSD Menu description Main Menu Sub Menu Option Standard Mode Off/On RTS/RPG Mode Off/On FPS Arena Mode Off/On MOBA Arena Mode Off/On Adaptive-Sync Off/On Shadow Balance 0-100 Game Settings Response Time Off/Normal/Fast/Ultrafast Refresh Rate Off/On/Position...
  • Page 27 User’s Manual Main Menu Sub Menu Option User3 Off/On:0-100(R/G/B) Color Settings 0-100(R/G/B/C/M/Y) Saturation 0-100(R/G/B/C/M/Y) PIP/PBP Mode Off/PIP Mode/PBP 2Win 1:1 Sub-Signal Source DP1/DP2/HDMI1/HDMI2 Audio Source Auto/DP1/DP2/HDMI1/HDMI2 PIP/PBP PIP Position TopRight/TopLeft/BottomRight/BottomLeft PIP Size Small/Medium/Large Window Swap Off/On 简体中文 /English/한국어 / /Portugues do Brasilazil/Deutsch/Nederland/ 日本語...
  • Page 28 User’s Manual DHI-LM34-E330C/E330CA Table 6-2 OSD Menu description Main Menu Sub Menu Option Standard Mode Off/On RTS/RPG Mode Off/On FPS Arena Mode Off/On MOBA Arena Mode Off/On Adaptive-Sync Off/On Shadow Balance 0-100 Game Settings Response Time Off/Normal/Fast/Ultrafast Refresh Rate Off/On/Position Game Crosshair Off/Crosshair1/Crosshair2/Crosshair3/Crosshair4/Crosshair5/Crosshair6 Game Time...
  • Page 29 User’s Manual Main Menu Sub Menu Option PIP/PBP Mode Off/PIP Mode/PBP 2Win 1:1 Sub-Signal Source DP1/DP2/HDMI1/HDMI2 Audio Source Auto/DP1/DP2/HDMI1/HDMI2 PIP/PBP PIP Position TopRight/TopLeft/BottomRight/BottomLeft Small/Medium/Large PIP Size Window Swap Off/On 简体中文 /English/한국어 / /Portugues do Brasilazil/Deutsch/Nederland 日本語 /Suomi/Français/Eλληvικά/Indonesia/Italiano/ /Malaysia/Polskie/ Language 繁体中文 Português/Русский/Español/ไทย/Українська/Tiếng Việt/ /Türkçe OSD Time Out...

  • Page 30: Product Specifications

    User’s Manual 7.Product Specifications Table 7-1 Product specifications DHI-LM30- DHI-LM30- DHI-LM34- DHI-LM34- Product model E330C E330CA E330C E330CA Screen Size 30" 34" Aspect Ratio 21:9 21:9 Viewing Angle 178°(H) / 178°(V) 178°(H) / 178°(V) Contrast ratio 3000:1 (TYP) 3000:1(TYP) Colors 16.7M 16.7M Resolution...

  • Page 31: Appendix 1 Troubleshooting

    User’s Manual Appendix 1 Troubleshooting Appendix Table 1-1 FAQ Faults occurring Possible solutions Check if the power is on. The power indicator light is not on Check if the power cord is connected. Check if the function of plug-and-play of the device is compatible with PC.

  • Page 32: Appendix 2 Cybersecurity Recommendations

    IP video surveillance is not immune to cyber risks, but taking basic steps toward protecting and strengthening networks and networked appliances will make them less susceptible to attacks. Below are some tips and recommendations from Dahua on how to create a more secured security system.
  • Page 33 Establish the 802.1x access authentication system to reduce the risk of unauthorized access to private networks. Enable IP/MAC address filtering function to limit the range of hosts allowed to access the device. More information Please visit Dahua official website security emergency response center for security announcements and the latest security recommendations.
  • Page 34 E N A B LI NG A S A FER S OCI ET Y AND S MAR T ER LIVIN G ZHEJIANG DAHUA VISION TECHNOLOGY CO., LTD. Address: No.1399, Binxing Road, Binjiang District, Hangzhou, P. R. China | Website: www.dahuasecurity.com | Postcode: 310053...
