- Page 1 LM32-U400P Smart Monitor User’s Manual V1.0.0...
- Page 2 Foreword General This manual introduces the functions, operations, and precautions of the LM32-U400P smart monitor (hereinafter referred to as "the Device"). Read carefully before using the device, and keep the manual safe for future reference. Safety Instructions The following signal words might appear in the manual.
- Page 3 The manual will be updated according to the latest laws and regulations of related jurisdictions. For detailed information, see the paper user's manual, use our CD-ROM, scan the R code or visit our official website. The manual is for reference only. Slight differences might be found between the electronic version and the paper version.
-
Page 4: Important Safeguards And Warnings
Important Safeguards and Warnings This section introduces content covering the proper handling of the device, hazard prevention, and prevention of property damage. Read carefully before using the device, and comply with the guidelines when using it. Operation Requirements WARNING Do not tread on or squeeze the power line, especially the plug or connection point of the power line to the product. - Page 5 Do not hang or lean on the product. Doing so can cause the product to fall or become damaged. It may also cause injury to people. Pay special atlention when children are nearby. If the product is installed on the wall, please make sure the wall's load bearing capacity is sufficient.
- Page 6 CAUTION Do not adjust, maintain or modify if you do not have appropriate qualifications. Do not open or remove the rear cover, box or cover board of the product. Please contact the dealer or after-sales service center when in need of adjustment or maintenance. Only qualified service people can maintain.
-
Page 7: Table Of Contents
Table of Contents Foreword - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - Ⅰ... -
Page 8: Packing List
1. Packing List The packing list varies depending on the model you purchase. The packing lists in this section are for reference only. The components that come with the Device might be slightly different from those in the figures. Figure 1-1 Packing list ①... -
Page 9: Monitor Adjustments
2. Monitor Adjustments The adjustment functions of the display include tilt angle adjustment, screen vertical rotation angle adjustment, left and right rotation angle adjustment, and height adjustment, as shown in the figure below. Different types of displays have different adjustment functions, and the specific adjustment functions are subject to the actual model adjustment functions. -
Page 10: Button Description
3. Button Description Figure 3-1 Indicator and buttons Buttons description volume down Volume Up Power on/off Indicator description Blue Power on and work normally Green Fully charged (charging state, and power level>98%) Low power (charging state, and power<10%) Low power Red and Blue (power<10%) No light... -
Page 11: Cable Connection
4. Cable Connection Figure 4-1 Input and output ports Mobile phone/tablet/notebooks DC in Notebooks/PC The above ports are for reference only, the actual ports of different types of monitors may be slightly different from the ports in the figure, and everything is subject to the ports and functions of the actual product. -
Page 12: Product Specifications
5. Product Specifications Table 5-1 Product specifications Product model LM32-U400P Screen Size 31.5" Aspect Ratio 16:9 Viewing Angle 178°(H) / 178°(V) Contrast ratio 3000:1 (TYP) Colors 16.7M Resolution 3840x2160 Maximum refresh rate 60Hz Touch technology OGM+AF System Android 11 MT8195... -
Page 13: Appendix 1 Troubleshooting
Appendix 1 Troubleshooting Appendix Table 1-1 FAQ Faults occurring Possible solutions Check if the power is on. The power indicator light is not on Check if the power cord is connected. Check if the function of plug-and-play of the device is compatible with PC.
