- Page 1 EVB-PCI11400 Evaluation Kit User’s Guide 2023-2024 Microchip Technology Inc. and its subsidiaries DS50003570B...
- Page 2 The Adaptec logo, Frequency on Demand, Silicon Storage Technology, and Symmcom are registered trademarks of Microchip Technology Inc. in other countries. GestIC is a registered trademark of Microchip Technology Germany II GmbH & Co. KG, a subsidiary of Microchip Technology Inc., in other countries. All other trademarks mentioned herein are property of their respective companies.
-
Page 3: Table Of Contents
Appendix A. Schematics A.1 Introduction ....................27 Appendix B. Bill of Materials B.1 Introduction ....................35 Appendix C. PCB Silk Screens C.1 Introduction ....................43 Worldwide Sales and Service ..................46 2023-2024 Microchip Technology Inc. and its subsidiaries DS50003570B-page 3... - Page 4 EVB-PCI11400 Evaluation Kit User’s Guide NOTES: 2023-2024 Microchip Technology Inc. and its subsidiaries DS50003570B-page 4...
-
Page 5: Preface
• Customer Support • Document Revision History DOCUMENT LAYOUT This document describes how to use the EVB-PCI11400 Evaluation Kit as a demonstration platform optimized for portable applications. The manual layout is as follows: • Chapter 1. “Overview” – This chapter shows a brief description of the EVB-PCI11400 Evaluation Kit. -
Page 6: Conventions Used In This Guide
Choice of mutually exclusive errorlevel {0|1} character: { | } arguments; an OR selection Ellipses... Replaces repeated text var_name [, var_name...] Represents code supplied by void main (void) user { ... 2023-2024 Microchip Technology Inc. and its subsidiaries DS50003570B-page 6... -
Page 7: Warranty Registration
MPLAB REAL ICE in-circuit emulator, MPLAB ICD 3 in-circuit debugger and MPLAB PM3 device programmers. Also included ® are non-production development programmers such as PICSTART Plus and PICkit 2 and 3. 2023-2024 Microchip Technology Inc. and its subsidiaries DS50003570B-page 7... -
Page 8: Customer Support
Revisions Section/Figure/Entry Correction DS50003570B Section 2.2 “Kit Con- Removed “PCIe slot retention clip (11-14-24) tents” (installed)” from the list. Removed the “Preliminary - NDA Required” marking. DS50003570A Initial release (11-24-23) 2023-2024 Microchip Technology Inc. and its subsidiaries DS50003570B-page 8... -
Page 9: Chapter 1. Overview
EVALUATION KIT USER’S GUIDE Chapter 1. Overview EVALUATION BOARD OVERVIEW The EVB-PCI11400 is a demonstration and evaluation platform that provides the nec- essary requirements and interface options for evaluating the PCI11400, a single-chip ® PCIe switch with an integrated USB 3.2 Gen 2 host controller and programmable I/O... -
Page 10: Block Diagram
2. 4-pin ATX peripheral power connector 3. 2-pin screw terminal block for use with external 12V bench supply BLOCK DIAGRAM Figure 1-1 shows the block diagram of the EVB-PCI11400. FIGURE 1-1: EVB-PCI11400 BLOCK DIAGRAM REFERENCES Concepts and materials available in the following documents may be helpful when reading this document. -
Page 11: Chapter 2. Getting Started
EVALUATION KIT USER’S GUIDE Chapter 2. Getting Started INTRODUCTION The Microchip EVB-PCI11400 is designed for flexible configuration solutions. It can be configured via external EEPROM (the EVB-PCI11400 configuration resides in EEPROM), internal One-Time-Programmable (OTP) memory, and/or external I C/SPI controller (optional). -
Page 12: Quick Start
7. Power ON the Host PC. Note: With Power Mode Select Switch SW1 in position [1-2], the EVB-PCI11400 becomes powered, in sync with the Host PC. 8. If not already installed, install the following drivers for your OS (See AN5190 PCI1xxxx Windows Driver Installation Guide.):... -
Page 13: Chapter 3. Hardware Configuration
EVB-PCI11400 REV B (TOP-SIDE) 3.1.1 Power Input Options The EVB-PCI11400 is intended to be powered from one of three (3) external +12 VDC power supply connections: 1. J15 – 4-pin ATX Peripheral Power connector 2. J30 – AC/DC barrel jack 3. -
Page 14: Power Mode Select Switch
EVB-PCI11400 Evaluation Kit User’s Guide 3.1.2 Power Mode Select Switch The EVB-PCI11400 has a Power Mode Select switch SW1 with two (2) modes, which must be chosen prior to applying power to the board. See Table 3-1. TABLE 3-1: POWER MODE SELECT OPTIONS... -
Page 15: Board Reset
Host PC’s PCIe slot is not supported. There- fore, all intentional Reset actions shall occur via installation of jumper J19. When the EVB-PCI11400 is reset via J19 during runtime operation, the PCIe-depen- dent functions of the PCI11400 are not expected to function normally afterwards. - Page 16 SMBus target interface. C EEPROM Install Install [1-2] to connect 3.3V power to the I VCC Power [1-2] EEPROM device. Enable Open [1-2] to disconnect 3.3V power to the I EEPROM device. 2023-2024 Microchip Technology Inc. and its subsidiaries DS50003570B-page 16...
- Page 17 JUMPER SETTINGS AND DEFAULTS (CONTINUED) Default Reference Jumper Function Description Position PCIe PRSNT# Install Install [1-2] to identify the EVB-PCI11400 as a Lane Width Selec- [1-2] 4-lane/x4 add-in-card. tion Install [2-3] to identify the EVB-PCI11400 as a 1-lane/x1 add-in-card. Leaving this EVB jumper position open may cause host system not to detect the presence of the EVB-PCI11400.
- Page 18 “Y” and “Z” RS-485 bus signals. Open [1-2] to disconnect 120Ω termination between the “A” and “B” RS-485 bus signals. Open [3-4] to disconnect 120Ω termination onto the “Y” and “Z” RS-485 bus signals. 2023-2024 Microchip Technology Inc. and its subsidiaries DS50003570B-page 18...
- Page 19 Open [5-6] to configure MAX3161 into RS-485 mode. Open [7-8] to configure MAX3161 into Full-duplex mode. Consult the Analog Devices MAX3161 Data Sheet for complete details on these settings. 2023-2024 Microchip Technology Inc. and its subsidiaries DS50003570B-page 19...
-
Page 20: Interface Connectors
0.25m to 0.5m PCIe riser cable is strongly recommended to be connected between connector P1 and the upstream platform's PCIe add-in-card slot. The upstream platform's 12V and 3.3V power rails are routed to the EVB-PCI11400 via this P1 connector. However, EVB-PCI11400 is designed not to substantially load these power rails as it includes options for external 12V power supplies to become “self-pow-... - Page 21 Hardware Configuration Both the PCIe 3.3V and 3.3 Vaux power pins are sourced from the EVB-PCI11400 3V3_BRD regulator. ® 3.1.5.3 J6 – USB 3.2 (10 GBPS) USB TYPE-C (PORT 1) ® J6 is a USB-IF certified (TID=5200000514) USB Type-C receptacle associated with Port 1 of the PCI11400’s xHCI Host Controller.
- Page 22 • J9 must be open in position [5-6] to configure MAX3161 into RS-485 mode. • J9 must be jumpered according to the RS-485 bus topology’s requirements. Figure 3-3 shows the J8 the signal pinout. 2023-2024 Microchip Technology Inc. and its subsidiaries DS50003570B-page 22...
- Page 23 When J18 is configured to enable SMBus Target, J34 signal pinout appears as illus- trated in Figure 3-4. FIGURE 3-4: J34 SIGNAL PINOUT (SMBUS TARGET) When J18 is configured to enable SPI Target, J34 signal pinout becomes the one shown in Figure 3-5. 2023-2024 Microchip Technology Inc. and its subsidiaries DS50003570B-page 23...
- Page 24 3-6. FIGURE 3-6: J31 SIGNAL PINOUT 3.1.5.13 J35 – JTAG An optional 1x6 header position is provided in order to fly-wire into any JTAG adapter of choice. See Figure 3-7. 2023-2024 Microchip Technology Inc. and its subsidiaries DS50003570B-page 24...
-
Page 25: Evaluation Board Led Indicators
J35 SIGNAL PINOUT 3V3_BRD JTAG_TCK JTAG_TMS JTAG_TDO JTAG_TDI 3.1.6 Evaluation Board LED Indicators Table 3-3 describes the LED indicators included on the EVB-PCI11400. TABLE 3-3: LED INDICATOR DESCRIPTIONS Reference Signal Name Description RESET# Lit when PCI11400 Reset pin is asserted 12VIN_SW... -
Page 26: Evaluation Board Test Points
Lit when the USB-C protection + VCONN source UCS4002 FAULT# (Port 1) has experienced a Fault condition 3.1.7 Evaluation Board Test Points Table 3-4 describes the test points available on EVB-PCI11400. TABLE 3-4: EVB-PCI11400 TEST POINTS Reference Signal Name Remarks... -
Page 27: Appendix A. Schematics
EVB-PCI11400 EVALUATION KIT USER’S GUIDE Appendix A. Schematics INTRODUCTION This appendix shows the EVB-PCI11400 Evaluation Kit’s schematics. 2023-2024 Microchip Technology Inc. and its subsidiaries DS50003570B-page 27... - Page 28 FIGURE A-1: EVB-PCI11400 SCHEMATICS PCI11400 PCIe_TX_L0_P0_N 0.1uF PCIe_TXC_L0_P0_N PCIe_TXC_L0_P1_N 0.1uF PCIe_TX_L0_P1_N PCIe_TX_L0_P0_N PCIE_TXM_L0_P0 PCIE_TXM_L0_P1 PCIe_TX_L0_P1_N PCIe_TX_L0_P0_P 0.1uF PCIe_TXC_L0_P0_P PCIe_TXC_L0_P1_P 0.1uF PCIe_TX_L0_P1_P PCIe_TX_L0_P0_P PCIE_TXP_L0_P0 PCIE_TXP_L0_P1 PCIe_TX_L0_P1_P PCIe_RX_L0_P0_N PCIe_RX_L0_P1_N PCIe_RX_L0_P0_N PCIE_RXM_L0_P0 PCIE_RXM_L0_P1 PCIe_RX_L0_P1_N PCIe_RX_L0_P0_P PCIe_RX_L0_P1_P PCIe_RX_L0_P0_P PCIE_RXP_L0_P0 PCIE_RXP_L0_P1 PCIe_RX_L0_P1_P PCIe_TX_L1_P0_N 0.1uF PCIe_TXC_L1_P0_N...
- Page 29 47pF SGND3 OKR-T/3-W12-C Rtrim = 5.76kΩ/[(Vout/0.7V)-1] PCB Layout Contact: Rtrim=1.182kΩ/(Vout-0.591) 432R Mick Davis PartNumber: Project Title Variant: Standard EVB-PCI11400 Bridgeport EV96N38A Designed with Sheet Title PCIe x4 edge, PCIe x1 slot Size SCH #: 02-00611 Rev: Date: 8/21/2023 Tabloid PCB #:...
- Page 30 CC2_C_P1 VCONN1_EN_P1 VCONN2_EN_P1 100k 100k Project Owner: Arnaldo Cruz PCB Layout Contact: Mick Davis PartNumber: Project Title Variant: Standard EV96N38A EVB-PCI11400 Bridgeport Sheet Title Designed with USB-C Port Size SCH #: 02-00611 Rev: Date: 8/21/2023 Tabloid PCB #: 04-11706 Rev:...
- Page 31 0.1uF UCS2-I2C UCS2113-2C I2C Addr = 56h Project Owner: Arnaldo Cruz PCB Layout Contact: Mick Davis PartNumber: Project Title Variant: Standard EVB-PCI11400 Bridgeport EV96N38A Designed with Sheet Title USB-A Ports Size SCH #: 02-00611 Rev: Date: 8/21/2023 Tabloid PCB #:...
- Page 32 0.1uF UART2_RXD SPI-P_CEN Project Owner: Arnaldo Cruz PCB Layout Contact: Mick Davis RESET tree connection PartNumber: Project Title Variant: Standard EV96N38A EVB-PCI11400 Bridgeport SHDN_N0 UART_RESETS_N Sheet Title Designed with SHDN_N1 UART, mikroBUS Size SCH #: 02-00611 Rev: Date: 8/21/2023 Tabloid...
- Page 33 Enable PCB Layout Contact: 5VDC (NC) R171 Mick Davis OKR-T/6-W12 255R Alternate PartNumber: Project Title Variant: Standard 5V/6A Module EVB-PCI11400 Bridgeport EV96N38A Designed with Sheet Title HDR-5.08 Male 1x4 Power Size SCH #: 02-00611 Rev: Date: 8/21/2023 Tabloid PCB #:...
- Page 34 NOTES:...
-
Page 35: Appendix B. Bill Of Materials
EVB-PCI11400 EVALUATION KIT USER’S GUIDE Appendix B. Bill of Materials INTRODUCTION This appendix contains the EVB-PCI11400 Evaluation Kit’s Bill of Materials. 2023-2024 Microchip Technology Inc. and its subsidiaries DS50003570B-page 35... - Page 36 TABLE B-1: BILL OF MATERIALS (INSTALLED COMPONENTS) Item Qty. Reference Description Manufacturer Manufacturer Part Number C1, C2, C3, C4, C9, C51, C52, C54, C55, CAP CER 0.1μF 35V 10% X7R SMD 0402μ TDK Corporation CGA2B3X7R1V104K050BB C56, C57, C58, C64, C66, C67, C75, C76, C77, C80, C81, C86, C91, C93, C98, C99, C100, C101, C103, C108, C112, C116, C129, C133, C136, C137, C141, C142,...
- Page 37 TABLE B-1: BILL OF MATERIALS (INSTALLED COMPONENTS) Item Qty. Reference Description Manufacturer Manufacturer Part Number C199 CAP CER 10UF 25V 20% X5R SMD 0603 Murata Electronics North America GRM188R61E106MA73D C200 CAP CER 47μF 6.3V 20% X5R SMD 0805 Taiyo Yuden JMK212BJ476MG-T C201, C202, C204, C206, C207, C208 CAP CER 0.1μF 35V 10% X7R SMD 0402...
- Page 38 TABLE B-1: BILL OF MATERIALS (INSTALLED COMPONENTS) Item Qty. Reference Description Manufacturer Manufacturer Part Number CON HDR-5.08 Male 1x4 Tin SHROUD 12.32MH TH R/A TE Connectivity 641737-1 CON POWER 2.5mm 5.5mm TH R/A CUI Inc. PJ-063BH CON TERMINAL 5.08mm 1X2 Female 16-30AWG 13.5A TH RA TE Connectivity 282836-2 INDUCTOR 4.7uH 1.1A 20% SMD 0805...
- Page 39 TABLE B-1: BILL OF MATERIALS (INSTALLED COMPONENTS) Item Qty. Reference Description Manufacturer Manufacturer Part Number R48, R58 RES TKF 680R 1% 1/10W SMD 0603 Panasonic ERJ-3EKF6800V R59, R66, R67, R68, R69, R86, R87, R88, RES TF 100k 1% 1/8W SMD 0603 Vishay MCT06030C1003FP500 R111, R125, R171, R197, R199, R202,...
- Page 40 Qty. Reference Description Manufacturer Manufacturer Part Number U2, U3 MCHP INTERFACE USB PWR Controller with Auto Discharge UCS2113-1C-V/G4 Microchip Technology Inc. UCS2113-1C-V/G4 QFN-20 MCHP INTERFACE KSZ9131RNX 10/100/1000BASE-T QFN-48 Microchip Technology Inc. kSZ9131RNXC MCHP MEMORY SERIAL EEPROM 64Kb I2C AT24CS64-SSHM-B SOIC-8 Microchip Technology Inc.
- Page 41 TABLE B-3: BILL OF MATERIALS (DO-NOT-POPULATE COMPONENTS) Item Qty. Reference Description Manufacturer Manufacturer Part Number BKT1 PCI Bracket, Global G5452 Global C32, C34 CAP CER 15pF 5% 50V C0G/NP0 SMD 0402 AEC-Q200 Murata Electronics North America GCM1555C1H150JA16D C41, C85 CAP CER 0.1μF 50V 10% X7R SMD 0402 TDK Corporation C1005X7R1H104K050BB CAP CER 1μF 35V 10% X5R SMD 0402...
- Page 42 EVB-PCI11400 Evaluation Kit User’s Guide NOTES: 2023-2024 Microchip Technology Inc. and its subsidiaries DS50003570B-page 42...
-
Page 43: Appendix C. Pcb Silk Screens
EVB-PCI11400 EVALUATION KIT USER’S GUIDE Appendix C. PCB Silk Screens INTRODUCTION This appendix shows the top and bottom silk screens of the EVB-PCI11400. 2023-2024 Microchip Technology Inc. and its subsidiaries DS50003570B-page 43... - Page 44 FIGURE C-1: EVB-PCI11400 TOP SILK SCREEN IMAGE...
- Page 45 FIGURE C-2: EVB-PCI11400 BOTTOM SILK SCREEN IMAGE...
-
Page 46: Worldwide Sales And Service
Tel: 46-31-704-60-40 Tel: 631-435-6000 Sweden - Stockholm San Jose, CA Tel: 46-8-5090-4654 Tel: 408-735-9110 UK - Wokingham Tel: 408-436-4270 Tel: 44-118-921-5800 Canada - Toronto Fax: 44-118-921-5820 Tel: 905-695-1980 Fax: 905-695-2078 2023-2024 Microchip Technology Inc. and its subsidiaries DS50003570B-page 46 04/15/24...
