Page 2
SQTP is a service mark of Microchip Technology Incorporated in the U.S.A. Silicon Storage Technology is a registered trademark of Microchip Technology Inc. in other countries. GestIC is a registered trademark of Microchip Technology Germany II GmbH & Co. KG, a subsidiary of Microchip Technology Inc., in other countries.
Page 3
Object of Declaration: UTC2000 2015 Microchip Technology Inc. DS50002399B-page 3...
– Includes information about the hardware configuration of the UTC2000 Evaluation Kit. • Appendix A. “UTC2000 Schematics” • Appendix B. “EVK-UTC2000 BOM” • Appendix C. “EVK-UTC2000 PCB Silk Screens” Note: USB Type-C™ USB-C™ are trademarks of USB Implementation Forum. 2015 Microchip Technology Inc.
Curly brackets and pipe Choice of mutually exclusive errorlevel {0|1} character: { | } arguments; an OR selection Ellipses... Replaces repeated text var_name [, var_name...] Represents code supplied by void main (void) user { ... 2015 Microchip Technology Inc. DS50002399B-page 8...
(FAE) for support. Local sales offices are also available to help customers. A listing of sales offices and locations is included in the back of this document. Technical support is available through the website at: http://www.microchip.com/support 2015 Microchip Technology Inc. DS50002399B-page 9...
Figure 3-7 Replaced incorrect image. Figure 3-8 Added trademark symbol to USB Type-C™. Appendix A. “UTC2000 Updated all images to remove extraneous informa- Schematics” tion. Appendix B. “EVK-UTC2000 Fixed inconsistent text size. BOM” 2015 Microchip Technology Inc. DS50002399B-page 10...
Section 1.2 “Features” for more infor- mation. Note: EVK-UTC2000 is enabled with a USB 3.1 Gen 1 switch. USB 3.1 Gen 2 can be supported by using a compliant USB 3.1 Gen 2 switch. FIGURE 1-1: UTC2000 EVALUATION KIT FEATURES •...
5V@4A PPC_EN Port Power VBUS OCS# Controller VBUS 3.3V VMON USB 3.1 USB 3.1 Gen 1 Gen 1 Type-A Plug Switch PLUG_ORIENTATION# ENABLE VCONN1_OUT# VCONN2_OUT# UTC2000 3.3V (DFP Mode) 5V to 3.3V Regulator 2015 Microchip Technology Inc. DS50002399B-page 12...
3. Set SW1 to the “1.5A” position. 4. Remove R3 to isolate the 5V domain on the EVB-UTC200-DFP from the 5V domain on your host PC. 5. Connect an external power supply as shown in Section 3.1.1 “Power Source”. 2015 Microchip Technology Inc. DS50002399B-page 15...
5. Connect an external power supply as shown in Section 3.1.1 “Power Source”. When connecting the EVB-UTC2000-DFP board to the EVB-UTC2000-UFP while in 3.0A charging mode, the “3.0A” charging capability LED indicator (D2) on the EVB-UTC2000-UFP will be illuminated. 2015 Microchip Technology Inc. DS50002399B-page 16...
2. External 5V Supply: An external 5V supply may be connected to TP1 to test 1.5A and 3.0A charging. Be sure to remove the R3 zero-ohm resistor to prevent voltage back drive to the host/hub port, as shown in Figure 3-3. 2015 Microchip Technology Inc. DS50002399B-page 17...
Indicates an overcurrent event is occurring. This signal is driven by the 5V port power controller. “PLUG ORIENT” Indicates the state of the PLUG_ORIENTATION# signal. When illu- minated, PLUG_ORIENTATION is being driven low by the UTC2000. 2015 Microchip Technology Inc. DS50002399B-page 18...
The EVB-UTC2000-DFP is configured for Legacy mode of operation by default. See Section 2.2.3 “1.5A Charging Operation”/Section 2.2.4 “3.0A Charging Operation” for information on testing 1.5A/3.0A modes respectively. Figure 3-5 shows their location on the PCB. FIGURE 3-5: EVB-UTC2000-DFP SWITCH LOCATIONS 2015 Microchip Technology Inc. DS50002399B-page 19...
Indicates when a 3.0 A capable DFP connection is detected. “1.5A” Indicates when a 1.5 A capable DFP connection is detected. “Legacy” Indicates when legacy 500 mA (USB 2.0)/900 mA (USB 3.1) capa- ble DFP connection is detected. 2015 Microchip Technology Inc. DS50002399B-page 20...
(internal Microchip use only) USB 3.1 USB Type-A receptacle Type-A Plug USB 3.1 USB Type-C™ receptacle Type-C Receptacle Load Loop An external load may be connected between this load loop and GND (pin 3 of J1) 2015 Microchip Technology Inc. DS50002399B-page 21...
UTC2000 Evaluation Kit User’s Guide FIGURE 3-8: EVB-UTC2000-UFP CONNECTOR LOCATIONS 1x5 Debug Header 1x5 Debug Header Type‐A Type‐A Receptacle Receptacle Type‐C™ Type‐C™ External Load Loop External Load Loop 3.1.9 Test Points on EVB-UTC2000-UFP There are no test points available on the EVB-UTC2000-UFP. 2015 Microchip Technology Inc. DS50002399B-page 22...
UTC2000 EVALUATION KIT USER’S GUIDE Appendix B. EVK-UTC2000 BOM INTRODUCTION This appendix shows the EVK-UTC2000 Evaluation Bill of Materials. 2015 Microchip Technology Inc. DS50002399B-page 27...
Page 28
TABLE B-1: EVK-UTC2000-DFP BILL OF MATERIALS Reference Manufacturer Item Description Manufacturer Pop'd Designator(s) Part Number CAP CER, 47uF, 16V, 20%, X5R, 1206 TDK Corporation C3216X5R1C476M160AB C2, C3, C6, C8, CAP CER, 0.1uF, 16V, 80%, SMD, 0402 Yageo CC0402ZRY5V7BB104 C9, C10, C12,...
Page 29
TABLE B-1: EVK-UTC2000-DFP BILL OF MATERIALS (CONTINUED) Reference Manufacturer Item Description Manufacturer Pop'd Designator(s) Part Number MISC, TEST POINT MULTI PURPOSE MINI RED Keystone 5000 MISC, TEST POINT MULTI PURPOSE MINI BLACK Keystone 5001 IC REG LDO 3.3V 0.3A SOT23-5...
Page 30
TABLE B-2: EVK-UTC2000-UFP BILL OF MATERIALS (CONTINUED) Reference Manufacturer Item Description Manufacturer Pop'd Designator(s) Part Number RES TKF 0R 1/3W SMD 1210 Vishay CRCW12100000Z0EA R15, R16 RES TKF 330R 1% 1/10W SMD 0603 ROHM MCR03EZPFX3300 RES TKF 100k 1% 1/10W SMD 0603...
Page 31
UTC2000 EVALUATION KIT USER’S GUIDE Appendix C. EVK-UTC2000 PCB Silk Screens INTRODUCTION This appendix shows the EVK-UTC2000 Top and Bottom Silk Screen Images. FIGURE C-1: EVB-UTC2000-DFP TOP AND BOTTOM SILK SCREEN IMAGES 2015 Microchip Technology Inc. DS50002399B-page 31...
Page 32
UTC2000 Evaluation Kit User’s Guide FIGURE C-2: EVB-UTC2000-UFP TOP AND BOTTOM SILK SCREEN IMAGES 2015 Microchip Technology Inc. DS50002399B-page 32...
