- Page 1 EVB-PCI12000 Evaluation Kit User’s Guide 2023-2024 Microchip Technology Inc. and its subsidiaries DS50003597B...
- Page 2 The Adaptec logo, Frequency on Demand, Silicon Storage Technology, and Symmcom are registered trademarks of Microchip Technology Inc. in other countries. GestIC is a registered trademark of Microchip Technology Germany II GmbH & Co. KG, a subsidiary of Microchip Technology Inc., in other countries. All other trademarks mentioned herein are property of their respective companies.
-
Page 3: Table Of Contents
Development Systems Customer Change Notification Service ......7 Customer Support ....................8 Document Revision History ................... 8 Chapter 1. Overview 1.1 EVB-PCI12000 Evaluation Kit Overview ............9 1.2 Features ......................9 1.3 Block Diagram ....................10 1.4 References ....................10 1.5 Definitions/Acronyms .................. - Page 4 EVB-PCI12000 Evaluation Kit User’s Guide NOTES: 2023-2024 Microchip Technology Inc.and its subsidiaries DS50003597B-page 4...
-
Page 5: Preface
• Customer Support • Document Revision History DOCUMENT LAYOUT This document describes how to use the EVB-PCI12000 Evaluation Kit as a demonstration platform optimized for portable applications. The manual layout is as follows: • Chapter 1. “Overview” – This chapter shows a brief description of the EVB-PCI12000 Evaluation Kit. -
Page 6: Conventions Used In This Guide
Choice of mutually exclusive errorlevel {0|1} character: { | } arguments; an OR selection Ellipses... Replaces repeated text var_name [, var_name...] Represents code supplied by void main (void) user { ... 2023-2024 Microchip Technology Inc.and its subsidiaries DS50003597B-page 6... -
Page 7: Warranty Registration
MPLAB REAL ICE in-circuit emulator, MPLAB ICD 3 in-circuit debugger and MPLAB PM3 device programmers. Also included ® are non-production development programmers such as PICSTART Plus and PICkit 2 and 3. 2023-2024 Microchip Technology Inc. and its subsidiaries DS50003597B-page 7... -
Page 8: Customer Support
DOCUMENT REVISION HISTORY Revisions Section/Figure/Entry Correction DS50003597B Section 2.2 “Kit Con- Removed "PCI retention clip (installed)" (11-11-24) tent” from the list. Removed the “Preliminary - NDA” marker. DS50003597A Initial release (11-24-23) 2023-2024 Microchip Technology Inc.and its subsidiaries DS50003597B-page 8... -
Page 9: Chapter 1. Overview
USER’S GUIDE Chapter 1. Overview EVB-PCI12000 EVALUATION KIT OVERVIEW The EVB-PCI12000 is a demonstration and evaluation platform that provides the nec- essary requirements and interface options for evaluating the PCI12000, a single-chip PCIe switch with programmable I/O options (I C/SPI/UART/GPIO), on a six-layer RoHS-compliant Printed Circuit Board (PCB). -
Page 10: Block Diagram
EVB-PCI12000 Evaluation Kit User’s Guide BLOCK DIAGRAM Figure 1-1 shows the block diagram of the EVB-PCI12000. FIGURE 1-1: EVB-PCI12000 BLOCK DIAGRAM REFERENCES Concepts and materials available in the following documents may be helpful when reading this document. Visit www.microchip.com for the latest documentation. -
Page 11: Chapter 2. Getting Started
1. EVB-PCI12000 Evaluation Board RECOMMENDED EQUIPMENT The following are the recommended hardware for the EVB-PCI12000 Evaluation Kit: • 12V DC Power Supply: The EVB-PCI12000 includes a 5.5x2.5x12 mm DC barrel jack, which is compatible with AC/DC adapters, including the Cincon TRH70A120-12E01-Level-VI. - Page 12 7. Power on the Host PC. Note: With Power Mode Select Switch SW1 in position [1-2], the EVB-PCI12000 becomes powered, in sync with Host PC. 8. If not already installed, install the following drivers for your OS (See AN5190 PCI1xxxx Windows Driver Installation Guide.): Microchip PCI12000...
-
Page 13: Chapter 3. Hardware Configuration
EVB-PCI12000 REV B (TOP-SIDE) 3.1.1 Power Input Options The EVB-PCI12000 is intended to be powered from one of three (3) external +12 VDC power supply connections: 1. J15 – 4-pin ATX Peripheral Power connector 2. J30 – AC/DC barrel jack 3. -
Page 14: Power Mode Select Switch
EVB-PCI12000 Evaluation Kit User’s Guide 3.1.2 Power Mode Select Switch The EVB-PCI12000 has a Power Mode Select switch SW1 with two (2) modes, which must be chosen prior to applying power to the board. See Table 3-1. TABLE 3-1: POWER MODE SELECT OPTIONS... -
Page 15: Board Reset
Host PC’s PCIe slot is not supported. There- fore, all intentional Reset actions shall occur via installation of jumper J19. When the EVB-PCI12000 is reset via J19 during runtime operation, the PCIe-depen- dent functions of the PCI12000 are not expected to function normally afterwards. - Page 16 Install [1-2] to connect 1.1V power (1V1_BRD) to Power Measure- [1-2] the PCI12000 ASIC 1.1V power pins (1V1_ASIC). ment Open [1-2] to connect an ammeter across the jumper pins and measure the PCI12000 ASIC 1.1V power consumption. 2023-2024 Microchip Technology Inc.and its subsidiaries DS50003597B-page 16...
- Page 17 SMBus target interface. C EEPROM Install Install [1-2] to connect 3.3V power to the I VCC Power [1-2] EEPROM device. Enable Open [1-2] to disconnect 3.3V power to the I EEPROM device. 2023-2024 Microchip Technology Inc. and its subsidiaries DS50003597B-page 17...
- Page 18 Lane Width Selec- [1-2] 2-lane/x2 add-in-card. tion Install [2-3] in to identify the EVB-PCI12000 as a 1-lane/x1 add-in-card. Note that leaving this EVB jumper position open may cause host system not to detect the pres- ence of the EVB-PCI12000. It is recommended to always keep jumper installed in J32 into one of its positions.
-
Page 19: Interface Connectors
The “upstream” connection towards the PCIe Root Complex is implemented as a stan- dard 4-lane/x4 PCIe add-in-card male edge connector (64 positions). Note: The upstream P1 connector is a 4-lane/x4 (64 positions) connector, but PCI12000 only uses two (2) PCIe lanes 2023-2024 Microchip Technology Inc. and its subsidiaries DS50003597B-page 19... - Page 20 0.25m to 0.5m PCIe riser cable is strongly recommended to be connected between connector P1 and the upstream platform's PCIe add-in-card slot. The upstream platform's 12V and 3.3V power rails are routed to the EVB-PCI12000 via this P1 connector. However, EVB-PCI12000 is designed not to substantially load these power rails as it includes options for external 12V power supplies to become “self-pow-...
- Page 21 Test mode by installing R21, depopulating R22, and resetting the evalua- tion board. An optional 1x6 header position is provided in order to fly-wire into any JTAG adapter of choice. See Figure 3-4. 2023-2024 Microchip Technology Inc. and its subsidiaries DS50003597B-page 21...
- Page 22 JTAG_TDI 3.1.5.8 J25 – MULTI-FUNCTION HEADER This header provides access to the majority of the communication specific signals used on EVB-PCI12000. Each pin is labeled in silkscreen adjacent to its probe pin. See Table 3-3. TABLE 3-3: PINOUT OF J25 MULTI-FUNCTION HEADER...
-
Page 23: Led Indicators On Evb-Pci12000
Hardware Configuration 3.1.6 LED Indicators on EVB-PCI12000 Table 3-4 describes the LED indicators included in the EVB-PCI12000. TABLE 3-4: LED INDICATOR DESCRIPTIONS Reference Signal Name Description RESET# Lit when PCI12000 Reset pin is asserted. 12VIN_SW Lit when there is voltage present upon one of the 12V input power connectors. - Page 24 PCIe device at J2 (differential) PCIE_REF- PCIe REFCLK output from clock buffer U14, which inputs CLK_P2_N to external PCIe device at J2 (differential) TP32 Ground reference near to U3 TP22 Ground reference near to J27 2023-2024 Microchip Technology Inc.and its subsidiaries DS50003597B-page 24...
-
Page 25: Appendix A. Schematics
EVB-PCI12000 EVALUATION KIT USER’S GUIDE Appendix A. Schematics INTRODUCTION This appendix shows the EVB-PCI12000 Evaluation Kit Schematics. 2023-2024 Microchip Technology Inc. and its subsidiaries DS50003597B-page 25... - Page 26 74AHC1G07 SPI-C_DO Mick Davis R13=0R 100k SPI-C_DI STBY# C11=DNP SPI-C_CEN PartNumber: Project Title Variant: Standard Yellow 0.1uF C15=DNP EVB-PCI12000 Twin Bridge EV05J17A C12=0.1uF PROGx Sheet Title Designed with PCI12000 Size SCH #: 02-00698 Rev: Date: 8/21/2023 Tabloid PCB #: 04-11782...
- Page 27 R157 R176 PCIE_WAKE_P0_N Project Owner: Arnaldo Cruz "WAKE0#" 74LVC1G17 PCB Layout Contact: Mick Davis PartNumber: Project Title Variant: Standard EVB-PCI12000 Twin Bridge EV05J17A Designed with Sheet Title PCIe Upstream Port Size SCH #: 02-00698 Rev: Date: 8/21/2023 Tabloid PCB #:...
- Page 28 SGND3 OKR-T/3-W12-C Project Owner: PM-LV2 Rtrim=1.182kΩ/(Vout-0.591) 432R Arnaldo Cruz PCB Layout Contact: Mick Davis PartNumber: Project Title Variant: Standard EVB-PCI12000 Twin Bridge EV05J17A Designed with Sheet Title PCIe Downstream Port Size SCH #: 02-00698 Rev: Date: 8/21/2023 Tabloid PCB #:...
- Page 29 Remove [10-11-12] -> leave PROG65 unterminated, use as GPIO Project Owner: Arnaldo Cruz PCB Layout Contact: Mick Davis PartNumber: Project Title Variant: Standard EVB-PCI12000 Twin Bridge EV05J17A Sheet Title Designed with UART Size SCH #: 02-00698 Rev: Date: 8/21/2023 Tabloid...
- Page 30 5VDC (NC) R171 PCB Layout Contact: OKR-T/6-W12 255R Mick Davis Alternate 5V/6A PartNumber: Project Title Variant: Standard Module EVB-PCI12000 Twin Bridge EV05J17A Designed with Sheet Title HDR-5.08 Male 1x4 Power Size SCH #: 02-00698 Rev: Date: 8/21/2023 Tabloid PCB #:...
-
Page 31: Appendix B. Bill Of Materials
EVB-PCI12000 EVALUATION KIT USER’S GUIDE Appendix B. Bill of Materials INTRODUCTION This appendix contains the EVB-PCI12000 Evaluation Kit Bill of Materials. 2023-2024 Microchip Technology Inc. and its subsidiaries DS50003597B-page 31... - Page 32 TABLE B-1: BILL OF MATERIALS (INSTALLED COMPONENTS) Item Qty. Reference Description Manufacturer Manufacturer Part Number C1, C2, C3, C4, C9, C51, C52, C54, C55, CAP CER 0.1uF 35V 10% X7R SMD 0402 TDK Corporation CGA2B3X7R1V104K050BB C56, C57, C58, C64, C66, C67, C75, C76, C77, C80, C81, C85, C86, C91, C93, C98, C99, C100, C101, C103, C108, C112, C116, C129, C133, C136, C137, C141,...
- Page 33 TABLE B-1: BILL OF MATERIALS (INSTALLED COMPONENTS) Item Qty. Reference Description Manufacturer Manufacturer Part Number C201, C202, C204, C206, C207, C208 CAP CER 0.1uF 35V 10% X7R SMD 0402 TDK Corporation CGA2B3X7R1V104K050BB D1, D2, D3 DIO LED GREEN 2V 30mA 35mcd Clear SMD 0603 Lite-On Inc LTST-C191KGKT D4, D6, D7, D8, D9, D11, D12, D13, D14,...
- Page 34 TABLE B-1: BILL OF MATERIALS (INSTALLED COMPONENTS) Item Qty. Reference Description Manufacturer Manufacturer Part Number RES TKF 0R 1/8W SMD 0805 Panasonic ERJ-6GEY0R00V TRANS FET P-CH SI4435 30V 12.6A 4.8W 0.019R SOIC-8 Vishay / Siliconix SI4435FDY-T1-GE3 Q2, Q5, Q7, Q10, Q11, Q12, Q13 TRANS FET N-CH 2N7002-7-F 60V 170mA 370mW SOT-23-3 Diodes Inc 2N7002-7-F...
- Page 35 TABLE B-1: BILL OF MATERIALS (INSTALLED COMPONENTS) Item Qty. Reference Description Manufacturer Manufacturer Part Number RES TKF 30k 1% 1/10W SMD 0603 Stackpole Electronics Inc RMCF0603FT30K0 R48, R58 RES TKF 680R 1% 1/10W SMD 0603 Panasonic ERJ-3EKF6800V RES TF 8.98k 0.5% 1/10W SMD 0603 AEC-Q200 KOA Speer RN73R1JTTD8981D100 RES TKF 2.7k 1% 1/10W SMD 0603...
- Page 36 Item Qty. Reference Description Manufacturer Manufacturer Part Number MCHP INTERFACE USB TYPE-C PORT PROTECT UCS4002 QFN-20 AECQ100 Microchip Technology UCS4002-E/6N U2, U3 MCHP INTERFACE USB PWR Controller with Auto Discharge UCS2113-1C-V/G4 QFN-20 Microchip Technology UCS2113-1C-V/G4 MCHP INTERFACE KSZ9131RNX 10/100/1000BASE-T QFN-48...
- Page 37 TABLE B-3: BILL OF MATERIALS (DO-NOT-POPULATE COMPONENTS) Item Qty. Reference Description Manufacturer Manufacturer Part Number R70, R71, R117, RES TKF 0R 1/10W SMD 0603 Stackpole Electronics Inc RMCF0603ZT0R00 R124, R127, R128, R129, R130, R132, R133, R134, R136, R137, R139, R140, R142, R153, R155, R156, R157, R158, R176, R177, R203,...
- Page 38 EVB-PCI12000 Evaluation Kit User’s Guide NOTES: 2023-2024 Microchip Technology Inc.and its subsidiaries DS50003597B-page 38...
-
Page 39: Appendix C. Pcb Silk Screens
EVB-PCI12000 EVALUATION KIT USER’S GUIDE Appendix C. PCB Silk Screens INTRODUCTION This appendix shows the top and bottom silk screens of the EVB-PCI12000 Evaluation Kit. 2023-2024 Microchip Technology Inc. and its subsidiaries DS50003597B-page 39... - Page 40 FIGURE C-1: EVB-PCI12000 TOP SILK SCREEN IMAGE...
- Page 41 FIGURE C-2: EVB-PCI12000 BOTTOM SILK SCREEN IMAGE...
-
Page 42: Worldwide Sales And Service
Tel: 46-31-704-60-40 Tel: 631-435-6000 Sweden - Stockholm San Jose, CA Tel: 46-8-5090-4654 Tel: 408-735-9110 UK - Wokingham Tel: 408-436-4270 Tel: 44-118-921-5800 Canada - Toronto Fax: 44-118-921-5820 Tel: 905-695-1980 Fax: 905-695-2078 2023-2024 Microchip Technology Inc. and its subsidiaries DS50003597B-page 42 04/15/24...
