DUSK . COM
LIVING BEDROOM DINING
THIS INSTRUCTION BOOKLET CONTAINS IMPORTANT SAFETY INFORMATION
PLEASE READ AND KEEP FOR FUTURE REFERENCE.
60 minutes approx
assembly time
This product is intended for domestic use only , not for commercial purposes.
Hideaway Desk
Two adults
assembly required
Range Name:ISLA
Product Dimensions:L80 x W39 x H112(cm)
Page 1
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for DUSK ISLA
Summary of Contents for DUSK ISLA
- Page 1 DUSK . COM Range Name:ISLA Product Dimensions:L80 x W39 x H112(cm) LIVING BEDROOM DINING Hideaway Desk THIS INSTRUCTION BOOKLET CONTAINS IMPORTANT SAFETY INFORMATION PLEASE READ AND KEEP FOR FUTURE REFERENCE. 60 minutes approx Two adults assembly time assembly required This product is intended for domestic use only , not for commercial purposes.
- Page 2 Important Assembly Tip Before you begin, we advise laying everything out on a clean and soft level surface to avoid damaging the unit or your floor, It's best to identify all of the parts and fittings to build your dressing table, and to familiarise yourself with all of the parts and fittings before building. Top Tip We recommend that you build your new cabinet In the room you'd like it to be located.
- Page 3 Parts check list Please check you have all the parts listed below with your product: Do not discard any of the packaging until you have checked that you have all the parts and the pack of fixings. Page 3...
- Page 4 Fittings check list Please check you have all the fittings listed below with your product: 36mm cam bolt x19pcs （ ） M15x9.5mm cam x19pcs （ ） M6x30mm Wood dowel x24pcs （ ） +2 extra +2 extra +2 extra M4x35mm Screw x10pcs （ ）...
- Page 5 Fittings check list Please check you have all the fittings listed below with your product: Hinge x1pc Hinge x1pc Shelf support x4pcs Hinge x4pcs M4x10mm Screw x4pcs Bolt Length Ruler: Tool required Crosshead Screwdriver (not provided) Page 5...
- Page 6 Step 1 5pcs Fix cam bolt(A) to the board 4 and board 7 as shown. Step 2 Attach board 5 to the board 4 with wooden dowel(C),put the cam(B) into 2pcs board 5 then turn clockwise to tighten 4pcs as shown,stick the cam hole with 2pcs sticker(T).
- Page 7 Step 3 Attach board 7 to board 6 with wooden dowel(C) and put cam(B) to board 6 3pcs then turn clockwise to tighten,stick the 2pcs cam hole with sticker(T) as shown. 3pcs Step 4 Attach board 6 to board 5 with wooden dowel(C) then use screw(D) fix the board 6 to the board(5) 2pcs as shown.
- Page 8 Step 5 Fix cam bolt(A) to the board 2 and board 3 as shown. 10pcs Step 6 5pcs 4pcs 5pcs Attach board 3 to the board 4 and board 6 and board 7 with wooden dowel(C),put the cam(B) into the board 4 and board 6 and board 7.
- Page 9 Step 7 5pcs 4pcs 5pcs Attach board 2 to the board 4 and board 6 and board 7 with wooden dowel(C),put the cam(B) into the board 4 and board 6 and board 7. Connect the 2 back board 14 with 15 then put them into Step 8 the cabinet as shown.
- Page 10 Step 9 4pcs 4pcs Attach the board 9 to the board 2 and board 3 with wooden dowel(C) then use screw D to fix them. Step 10 Connect leg 16 to the frame on the board 9,put metal plate(L) and (M) onto the screw rod(K) at first then tighten 4pcs the screw rod(K) with an Allan wrench,finally stick the 4pcs...
- Page 11 Step 11 Put the board 13 into cabinet as shown. Step 12 Fix cam bolt into board(A) as shown. Fix magnetic catch(J) to the board 1 with screw(E) 4pcs as shown. 2pcs Fix L wall fixing(F) with screw(G) as shown. 2pcs 2pcs Page 11...
- Page 12 Step 13 4pcs 4pcs 4pcs Attach board 1 to board 2 and board 3 with wooden dowel(C), put cam(B) into board 2 and board 3 then turn clockwise to tighten,stick the cam holes with sticker(T) as shown. Step 14 4pcs 2pcs 4pcs 8pcs...
- Page 13 Step 15 Fix board 11 to board 2 with screw(S). Fix board 12 to board 3 with screw(S). 16pcs As shown. Page 13...
- Page 14 Step 16 4pcs Insert the shelf support to the board 2 and board 3 then put the board 8 into the cabinet as shown. Step 17 Fix hinge(Y) to the board 10 with screw(E). Fix metal plate to the board 10 with screw(E). 13pcs Fix hinge W and X to the board 10 with screw(Z) 4pcs...
- Page 15 Step 18 16pcs 2pcs Fix board 10 to the cabinet with screw(E) as shown, then fix handle Q to the board 10 with screw(I). Page 15...
- Page 16 Step 19 12pcs 12pcs Fix back bracket(P) to the cabinet with screw(E) as shown. Page 16...
- Page 17 Step 20 2pcs 2pcs Drill holes on your wall and install anti-tipping device as shown. Page 17...
