PRODUCT FITTING INSTRUCTIONS
Nova Pro Scala 90mm Height With Rail
554.32.501/554.32.503/554.32.504/554.32.505/554.32.507/554.32.508/554.32.509/
554.32.510/554.32.901/554.32.903/554.32.904/554.32.905/554.32.907/554.32.908/
554.32.909/554.32.910
> Height 90 mm with rail
> Depth 450 mm
> Width 300 - 1000 mm
> Set consists of:
1. Drawer Set, with rails and clips
2. Runners x 1 pair
3. Front fixing clips x 2 and fixing screw set
Before you start
>
Unpack all items and check you have everything shown below - if you are missing something, please call 0800 1712908.
>
Make sure that you have all the tools as noted below, and a clean, dry area for installing.
>
Installing should be done in the stages shown.
Included in this pack
2
Drawer front not included, for illustration purposes only
Optional items
Runner drilling jig
A
558.18.125
Drawer front marking jig
B
558.18.070
If in doubt, please contact our Technical support team on
alternatively send your query by e-mail to
1
6x 015.31.639 Hospa
screw, Ø 3.5 x 15 mm
2
Touch to open set
C
For drawers up to 600mm
551.91.182
For drawers up to 1200mm
551.91.183
3
Length
Ø 7
Head
Ø
Ø
8x 340.29.724 Varianta screw
length 13.5 mm
Tools to help with installation
D
technicalsupport@hafele.co.uk
FITT_Ref: 105423 Issue-1
Length
Body Ø 4.7
Thread Ø 6.0
2x Front fixing clips
0800 1712908
