BUILD IN COOKING HOB
FOR USE WITH LPG
CAUTION – ALL OUTER SURFACES WILL GET HOT WHEN IN USE
Mk3 & Mk4 Triplex Hob
Mk3 & Mk4 Triplex Hob ~ Wide
USER AND INSTALLATION INSTRUCTIONS
READ AND RETAIN FOR FUTURE REFERENCE
FOR USE IN
GB, BE, BG, CH, CY, CZ, DE, DK, EE, ES, FI, FR, GR, HR
HU, IE, IT, LT, LU, LV, MT, NL, NO, PT, RO, SE, SK, SI, TR
THETFORD LIMITED
Unit 6 Brookfields Way, Manvers
Rotherham S63 5DL. ENGLAND.
TEL: + 44 (0) 844 997 1960
FAX: + 44 (0) 844 997 1961
Advertisement
Related Manuals for Thetford Mk3 Triplex Hob
Summary of Contents for Thetford Mk3 Triplex Hob
- Page 1 GB, BE, BG, CH, CY, CZ, DE, DK, EE, ES, FI, FR, GR, HR HU, IE, IT, LT, LU, LV, MT, NL, NO, PT, RO, SE, SK, SI, TR THETFORD LIMITED Unit 6 Brookfields Way, Manvers Rotherham S63 5DL. ENGLAND.
- Page 2 CAUTION • Appliance and accessible parts become hot when in use, young children should be kept away. Avoid touching the heating elements or pan supports when in use. • The use of a gas cooking appliance results in the production of heat, moisture and products of combustion in the room in which it is installed.
- Page 3 CAUTION • Do not allow cooking vessels to overlap the edges of the appliance – use the correct sizes of pans and position them centrally over the burners. • Do not use harsh abrasive cleaners or sharp metal scrapers to clean the glass since they can scratch the surface, which may result in shattering of the glass.
- Page 4 Technical Specifications Gas Categories: BP(30) Butane (G30) 30 mbar Propane (G31) 30 mbar +(28-30/37) Butane (G30) 28-30 mbar Propane (G31) 37 mbar...
- Page 5 Fig.1 – Installation Details Mk3 & Mk4 Triplex Hob Mk3 & Mk4 Triplex Hob ~ Wide S~HB70000 & S~HB75000 S~HB76000 & S~HB78000 A = 120mm A = 120mm B = 445mm B = 496mm C = 493mm Worktop Cutout C = 493mm Worktop Cutout D = 10mm D = 10mm Gas dispersal hole...
- Page 6 Fig. 2 – Allowable Distance to Combustible Material Mk3 & Mk4 Triplex Hob Mk3 & Mk4 Triplex Hob ~ Wide 400mm 400mm 200mm 200mm 500mm 500mm 500mm 550mm Fig. 3 – Control Positions FULL RATE LOW RATE...
-
Page 7: Operation
INTRODUCTION CAUTION: This appliance is for cooking purposes only. It must not be used for other purposes, for example room heating. Any other use is incorrect and dangerous. Failure to install the appliance correctly, or improper use, will invalidate any warranty or liability claims. This appliance must be installed in accordance with the local, national and European regulations in force. -
Page 8: Maintenance
OPERATION Using the Hotplate Gas Burners 1. Ensure gas supply is connected and turned on. 2. Push in the control knob and turn anticlockwise to full rate – large flame ( ), see Fig 5. 3. Continue depressing the knob whilst holding a lighted match or taper to the burner. For models fitted with spark ignition the procedure is similar except that burner is ignited by depressing the ignition button located on the fascia. -
Page 9: Installation
INSTALLATION Regulations And Standards In your own interest of safety, it is law that all gas appliances are installed and serviced by an approved competent person, in accordance with the local and National/European standards in force Failure to install the appliance correctly could invalidate any warranty or liability claims and lead to prosecution. - Page 10 INSTALLATION The appliance should be fixed in place using the fixing screw positions located in each side trim. Make sure the appliance is fully home in the cabinet/aperture before fixing in place. This appliance must be positioned free from draughts, which may affect the combustion, and in a manner that will prevent the accumulation of unburnt gas.
- Page 11 INSTALLATION To ensure correct operation we recommend the following:- • Built into self contained cabinet not connected to externally vented chambers in adjacent furniture, other than correct size gas dropouts. • Holes for cables & pipes have minimum clearance where possible •...
