BUILD-IN COOKING HOB
FOR USE WITH LIQUIFIED PETROLEUM GAS
TOPLINE HOB
INSET SERIES 160, 162, 164, 167
TOP MOUNT SERIES 910, 920, 922, 930, 960
USER AND INSTALLATION INSTRUCTIONS
READ AND RETAIN FOR FUTURE REFERENCE
FOR USE IN: GB, IE, FR, NL, BE, LU, ES, IT, NO, DE, DK, SE
THETFORD LIMITED, 19 Oakham Drive, Parkwood Industrial Estate
Rutland Road, Sheffield S3 9QY, ENGLAND.
TEL: + 44 (0) 114 273 8157
FAX: + 44 (0) 114 275 3094
Advertisement
Table of Contents
Related Manuals for Thetford Inset 160
Summary of Contents for Thetford Inset 160
- Page 1 READ AND RETAIN FOR FUTURE REFERENCE FOR USE IN: GB, IE, FR, NL, BE, LU, ES, IT, NO, DE, DK, SE THETFORD LIMITED, 19 Oakham Drive, Parkwood Industrial Estate Rutland Road, Sheffield S3 9QY, ENGLAND. TEL: + 44 (0) 114 273 8157...
-
Page 5: Appliance Location
CONTROL POSITIONS – ALL MODELS FIG. 1 FULL RATE LOW RATE APPLIANCE LOCATION For either Inset or Top mounted appliances the minimum allowable distance to combustible materials is as shown below. FIG. 2 A = 200mm unless B = 500mm minimum to Protected by a fitment above appliance Non-combustible... - Page 6 FIG. 3 Series 160 – Worktop cutout for flush mount seal Series 160 – Worktop cutout for surface mount seal = Intersection of radi points...
- Page 7 FIG. 4 Series 167 worktop cutout details Series 164 worktop cutout details...
-
Page 8: Worktop Cutout Details
WORKTOP CUTOUT DETAILS FIG. 5... - Page 9 WORKTOP CLAMPING METHODS FIG. 6 SERIES 160, 162, 164 & 167 INSET HOBS (Top Mount Seal) FIG. 7 SERIES 160,162,164 & 167 INSET HOBS (Flush Mount Seal) FIG. 8 SERIES 910, 920, 921, 922, 930 & 960 HOBS (Hidden Seal)
- Page 10 INTRODUCTION This appliance is designed for cooking food, any other use is incorrect and dangerous. Failure to install the appliance correctly or improper use could invalidate any warranty or liability claims and lead to prosecution. This appliance must be installed in accordance with the local, national and European regulations in force.
-
Page 11: Maintenance And Servicing
OPERATION 1. Ensure gas supply is connected and turned on. 2. Push in the control knob and turn anticlockwise to full rate – large flame ( ) Fig. 1. 3. Continue holding the knob depressed whilst the automatic ignition lights the burner. For manual models hold a lighted match or taper to the burner. -
Page 12: Installation
INSTALLATION In your own interest of safety, it is law that all gas appliances be installed by an approved competent person who will undertake to work to safe and satisfactory standards. Failure to install the appliance correctly could invalidate any warranty or liability claims and lead to prosecution. - Page 13 INSTALLATION On completion of the installation a warning notice complying to EN721 Annex A should be affixed adjacent to the appliance. If other appliance/s are located below the hob we recommend conducting a temperature verification test to confirm any rise in temperature of the cabinet materials are within allowable limits and meet requirements specified in EN30-1-1, EN1949, EN1645-1, EN1646-1, EN1647, EN721.
