ELECTRIC VEHICLE CHARGER
EVC06-DCHC60 Ser es
Installat�on Gu�de
© 2025 VESTEL MOBILITY - All rights reserved
English - 1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the EVC06-DCHC60 Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for VESTEL EVC06-DCHC60 Series

  • Page 1 ELECTRIC VEHICLE CHARGER EVC06-DCHC60 Ser es Installat�on Gu�de © 2025 VESTEL MOBILITY - All rights reserved English - 1...
  • Page 2: Table Of Contents

    10.6.7 - GENERAL SETTINGS PAGE IN WEB CONFIG UI ........ 30 10.6.7.1 - Default Interface Languages ..........30 10.6.7.2 - Display Settings ............. 30 10.6.7.3 - Display Logo ..............31 10.6.7.4 - Boot Logo ..............31 © 2025 VESTEL MOBILITY - All rights reserved English - 1...
  • Page 3 10.6.10.5 - Administration Password ..........48 10.6.10.6 - Factory Default Configuration ...........48 10.7 - CLOSING THE COVER ................49 11- PERIODIC MAINTENANCE LIST ................50 12 - WIRELESS LAN TRANSMITTER SPECIFICATIONS .............52 © 2025 VESTEL MOBILITY - All rights reserved English - 2...
  • Page 4: 1- Safety Information

    • The device location should be consciously selected in order to prevent the charging station from overheating. High temperature caused by direct sunlight or heating sources during use may cause the charging current to decrease or the charging process to be temporarily interrupted. © 2025 VESTEL MOBILITY - All rights reserved English - 3...
  • Page 5 CAUTION: This vehicle charger is designed only for charging the electric vehicles that do not require ventilation during charging. © 2025 VESTEL MOBILITY - All rights reserved English - 4...
  • Page 6: Fire Fighting Instructions For Electrip Global Electric Vehicle Charging Station

    • A damaged charging cable may cause a fire or electrical shock conditions. Do not use this product if the Flexible Charging cable or vehicle cable is worn, has frayed insulation, or shows any different signs of damage. © 2025 VESTEL MOBILITY - All rights reserved English - 5...
  • Page 7: Protections Required Before System

    Minimum cable cross-sections are provided for maximum AC input current. The final cross- sections of the installation conductors should be calculated by the installer, taking into account the distances and mounting location conditions. © 2025 VESTEL MOBILITY - All rights reserved English - 6...
  • Page 8: Introduction

    Third Star (*) : DC output combination 2 C : CCS Output Blank : No CCS output Fourth Star (*) : Blank : No DC Meter EICH : Eichrecht Meter Cabinet EVC06HC © 2025 VESTEL MOBILITY - All rights reserved English - 7...
  • Page 9: General Information

    DC CCS Output Plug Payment Terminal Option Emergency Stop Button(Optional) Access Cover for CTB, PLC Card and HMI Fan Access Cover All products images are given for representative purpose only. © 2025 VESTEL MOBILITY - All rights reserved English - 8...
  • Page 10: Dimensional Drawings

    DIMENSIONAL DRAWINGS 3.2 - Front, Side and Top View © 2025 VESTEL MOBILITY - All rights reserved English - 9...
  • Page 11: Required Equipment, Instruments And Accessories

    Special Switch M50 x M40 M12 Flange Bolt x2 M12 special anchor bolt set (4 pcs) Anchor plate (1 pc) Product control with internet connection(Optional) 1 set (x2) Lock Key © 2025 VESTEL MOBILITY - All rights reserved English - 10...
  • Page 12: Recommended Equipment And Tools

    13(M8) , 17(M10), Cat5e or cat6 RJ45 crimping tool Hammer 19(M12) Wrench ethernet cable T25 Screwdriver 20 - 200 Nm M20 Steel Dowel x4 RJ45 Male Connector D:40mm H:43mm © 2025 VESTEL MOBILITY - All rights reserved English - 11...
  • Page 13: Electrical Properties

    Residual current detection/Insulation supervision/Overcurrent Internal Precautions / Overvoltage / Undervoltage / Short circuit / Over Temperature / Overvoltage Protection Supported Charging Modes Mode 4 (22kW AC Optional) - Mode 3 © 2025 VESTEL MOBILITY - All rights reserved English - 12...
  • Page 14: User Interface And Authentication

    1754 mm (Length), 683 mm (Width), 458 mm (Depth) Dimensions (packed version) 2000 mm (Length), 950 mm (Width), 590 mm (Depth) Weight (Product) 263 kg. Packed Weight 363 kg with package © 2025 VESTEL MOBILITY - All rights reserved English - 13...
  • Page 15: Environmental Specifications

    WARNING : TO PREVENT INJURIES OR DAMAGE TO THE CHARGING STATION, MAKE SURE THE INSTALLATION AREA IS SUITABLE AND THAT THE FLOOR CAN RESIST THE WEIGHT OF THE CHARGING STATION. © 2025 VESTEL MOBILITY - All rights reserved English - 14...
  • Page 16: Unpack The Charging Station

    Unpack the charging station as shown in the figure below. Note that the front and top covers are marked as shown in the figures. All products images are given for representative purpose only. © 2025 VESTEL MOBILITY - All rights reserved English - 15...
  • Page 17: Contents Of The Charging Station Packaging

    10.2 - CONTENTS OF THE CHARGING STATION PACKAGING 1 Master RFID Card + 2 User RFID Card ELECTRIC VEHICLE CHARGER EVC06-DCHC60 Ser es All products images are given for representative purpose only. © 2025 VESTEL MOBILITY - All rights reserved English - 16...
  • Page 18: Establishment Of The Station By Preparing The Concrete And Anchor

    Allow the concrete to solidify, note that the surface remains firm and flat during the process. Place the charging station on the anchor plate as shown in the figure. Pass the cables through the cable glands. © 2025 VESTEL MOBILITY - All rights reserved English - 17...
  • Page 19 Tighten the cable glands. The base part of the Charging Station should be at least 100mm above the ground. 30mm All products images are given for representative purpose only. © 2025 VESTEL MOBILITY - All rights reserved English - 18...
  • Page 20: Foundation, Alignment, Layout

    During lifting, there should be a minimum angle of 60 degrees at both rope ends, as shown in the image. Using a shorter sling will cause damage to the product. © 2025 VESTEL MOBILITY - All rights reserved English - 19...
  • Page 21 Figure. Tighten the expansion bolts with the nuts. The type of the expansion bolts is shown in the Figure. © 2025 VESTEL MOBILITY - All rights reserved English - 20...
  • Page 22 Hole Drilling Diameter: Ø20 mm, Drilling Depth: 155mm (Torque: 200Nm) All products images are given for representative purpose only. © 2025 VESTEL MOBILITY - All rights reserved English - 21...
  • Page 23 Remove the eye bolts after placing the charging station. Tighten the screws with setscrews as shown in the figure. All products’ images are given for representative purpose only © 2025 VESTEL MOBILITY - All rights reserved English - 22...
  • Page 24: Opening The Front Covers

    Turn the key to the right. After turning the key, pull the cover lock apparatus towards you. Turn the opened cover lock apparatus counterclockwise. This way, the cover will open. © 2025 VESTEL MOBILITY - All rights reserved English - 23...
  • Page 25: Cable Assembly

    The surface contact of the clamping shoes and cable glands is shown in brown in the figure. The mounting surface of the clamping shoes corresponds to 92% of the surface data shown in the clamping shoe data sheet compatible with a cable cross-section. © 2025 VESTEL MOBILITY - All rights reserved English - 24...
  • Page 26 (“Line 1”, “Line 2”, “Line 3”) as shown in the figure: Phase sequence is counterclockwise. Line 3 Line 2 Line 1 Tighten the cable glands with an adjustable wrench. (25Nm) © 2025 VESTEL MOBILITY - All rights reserved English - 25...
  • Page 27: Sim Card Connection (Optional)

    SIM card into the Ghost OCPP card and sends it to the field after activating. The management of the Ghost OCPP card is in the charge of the manufacturer. OCPP Connection GSM Module Remote monitoring GSM Module © 2025 VESTEL MOBILITY - All rights reserved English - 26...
  • Page 28: Connecting Ocpp Through Ethernet Network

    Pass the cable through the cable gland. Pass the cables through the cable clamps as shown by the arrows in the figure below. Insert the RJ45 connector into the socket as shown in the figure. © 2025 VESTEL MOBILITY - All rights reserved English - 27...
  • Page 29: Connecting To The Same Network With The Ethernet Port

    Forcing Refresh or Clearing (depending on your operating system and browser) them fixes certain problems, like loading or formatting issues on web page. © 2025 VESTEL MOBILITY - All rights reserved English - 28...
  • Page 30: Main Page

    You can also change the language and log out of the web config with the buttons in the upper right corner of the page. Figure Representation © 2025 VESTEL MOBILITY - All rights reserved English - 29...
  • Page 31: General Settings Page In Web Config Ui

    • Sensor Based - Display brightness is changed based on given sensor value thresholds. • medium threshold interval : 0 - 65536 • high threshold interval : 0 - 65536 Another option is Reduced Brightness In Inactive Mode. © 2025 VESTEL MOBILITY - All rights reserved English - 30...
  • Page 32: Display Logo

    10.6.7.4 - Boot Logo The details of Boot loader Logo • File format should be BMP. • Image dimensions should be 1024 X 768. © 2025 VESTEL MOBILITY - All rights reserved English - 31...
  • Page 33: Tilt Threshold

    The user can update the QR Code Settings for each connector on the device. QR Code can be enabled/disabled and if enabled, a limiting value for the QR Code String can be set. © 2025 VESTEL MOBILITY - All rights reserved English - 32...
  • Page 34: Customer Service Number

    10.6.7.7 - Customer Service Number You can reach customer service number from web UI screen. © 2025 VESTEL MOBILITY - All rights reserved English - 33...
  • Page 35: Ocpp Settings

    10.6.8 - OCPP SETTINGS 10.6.8.1 - OCPP Connection © 2025 VESTEL MOBILITY - All rights reserved English - 34...
  • Page 36: Ocpp Version

    No OCPP connection. OCPP is enabled. Only accepts the IdTags that are preset; rejects others. False Authorize-All No OCPP connection. Requires an IdTag to be presented, however does not check its integrity; it accepts all IdTags. © 2025 VESTEL MOBILITY - All rights reserved English - 35...
  • Page 37: Connection Settings

    10.6.8.3 - Connection Settings Central System Adress and Charge Point ID is required. 10.6.8.4 - OCPP Configuration Parameters All OCPP configurations can be configured here. © 2025 VESTEL MOBILITY - All rights reserved English - 36...
  • Page 38 © 2025 VESTEL MOBILITY - All rights reserved English - 37...
  • Page 39 © 2025 VESTEL MOBILITY - All rights reserved English - 38...
  • Page 40 © 2025 VESTEL MOBILITY - All rights reserved English - 39...
  • Page 41: Switching Auto Charge On/Off (Optional)

    “Auto Charge” feature is enabled (activated) by enabling “Auto Charge Support” from the OCPP Settings tab and entering and saving the vehicle MACid information. To deactivate, the “Auto Charge Support” tab is disable (deactivated). © 2025 VESTEL MOBILITY - All rights reserved English - 40...
  • Page 42: Network Interfaces Settings

    10.6.8.6 - NETWORK INTERFACES SETTINGS CELLULAR Cellular settings can be configured such as APN and pin number. © 2025 VESTEL MOBILITY - All rights reserved English - 41...
  • Page 43 WLAN © 2025 VESTEL MOBILITY - All rights reserved English - 42...
  • Page 44: Power Management

    DC Output Configuration(deprecated-will be renamed as Model Code). 10.6.9.2 - Charge Point Maximum Power Maximum Power value is used to set the maximum output power delivered from charging station. © 2025 VESTEL MOBILITY - All rights reserved English - 43...
  • Page 45: Fail Safe Power

    Fail Safe Power Limiting feature is used to limit the station output power when the OCPP Server connection is lost. When feature is enabled, the user can set output power value. The default value is 10 kW. © 2025 VESTEL MOBILITY - All rights reserved English - 44...
  • Page 46: Power Module Configurations

    Unavailable. - Connector Settings 10.6.9.5 Connector type and corresponding maximum output power is displayed under Connector Settings menu. © 2025 VESTEL MOBILITY - All rights reserved English - 45...
  • Page 47: System Maintenance

    10.6.10.1 - Log Files You can download the logs about the device from here. 10.6.10.2 - Firmware Updates The firmware file of device can uploaded then the software of device can upgraded. © 2025 VESTEL MOBILITY - All rights reserved English - 46...
  • Page 48: Configuration Backup/Restore

    10.6.10.3 - Configuration Backup/Restore The configurations related to device can backuped and restored here. 10.6.10.4 - System Reset Hard or soft reset can applied to device here. © 2025 VESTEL MOBILITY - All rights reserved English - 47...
  • Page 49: Administration Password

    10.6.10.5 - Administration Password The administrator password can changed here. 10.6.10.6 - Factory Default Configuration Factory reset can applied to device here. © 2025 VESTEL MOBILITY - All rights reserved English - 48...
  • Page 50: Closing The Cover

    As shown in the “Opening the front covers” section, close the front cover of the product with the keys provided by turning the handle clockwise at a wide angle. © 2025 VESTEL MOBILITY - All rights reserved English - 49...
  • Page 51: 11- Periodic Maintenance List

    The AC input terminals should be checked and tightened when going for maintenance These terminals should be tightened with a torque of 8 Nm for metric 8 bolts and 10 Nm for metric 10 bolts. © 2025 VESTEL MOBILITY - All rights reserved English - 50...
  • Page 52 During lifting, there should be a minimum angle of 60 degrees at both rope ends as shown in the image. Using a shorter sling will cause damage to the product. © 2025 VESTEL MOBILITY - All rights reserved English - 51...
  • Page 53: Wireless Lan Transmitter Specifications

    2.4 GHz and 5 GHz wireless LANs. Hereby, Vestel Mobilite SAN. VE TİC. A.Ş., declares that the radio equipment type EVC is in compliance with Directive 2014/53/EU and Radio Equipment Regulations 2017. The full text of the EU declaration of conformity is available at the following address: doc.vosshub.com.
  • Page 54 Zafer SB Mah. Ayfer Sok. No:22 İç Kapı No:1 Gaziemir, İzmir/ TÜRKİYE Telefon (pbx) : 90 (232) 251 72 90 Fax : 90 (232) 251 73 13 Gaziemir V.D. : 837 001 0241 © 2025 VESTEL MOBILITY - All rights reserved English - 53...
