ELECTRIC VEHICLE CHARGER
EVC06-DCHC60 Ser es
User Manual
©2025 VESTEL MOBILITY - All rights reserved
English - 1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the EVC06-DCHC60 Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for VESTEL EVC06-DCHC60 Series

  • Page 1 ELECTRIC VEHICLE CHARGER EVC06-DCHC60 Ser es User Manual ©2025 VESTEL MOBILITY - All rights reserved English - 1...
  • Page 2: Table Of Contents

    11 - ERROR AND MALFUNCTION CONDITIONS ............. 19 11.1 - ERROR CONDITIONS ................19 12 - CLEANING AND MAINTENANCE ................ 20 13 - DC DEVICE PERIODIC MAINTENANCE LIST.............20 14 - WIRELESS LAN TRANSMITTER SPECIFICATIONS ............ 22 ©2025 VESTEL MOBILITY - All rights reserved English - 1...
  • Page 3: Safety Information

    • The device location should be consciously selected in order to prevent the charging station from overheating. High temperature caused by direct sunlight or heating sources during use may cause the charging current to decrease or the charging process to be temporarily interrupted. ©2025 VESTEL MOBILITY - All rights reserved English - 2...
  • Page 4 CAUTION: This vehicle charger is designed only for charging the electric vehicles that do not require ventilation during charging. ©2025 VESTEL MOBILITY - All rights reserved English - 3...
  • Page 5: Fire Fighting Instructions For Electrip Global Electric Vehicle Charging Station

    • A damaged charging cable may cause a fire or electrical shock conditions. Do not use this product if the Flexible Charging cable or vehicle cable is worn, has frayed insulation, or shows any different signs of damage. ©2025 VESTEL MOBILITY - All rights reserved English - 4...
  • Page 6: Protections Required Before System

    Minimum cable cross-sections are provided for maximum AC input current. The final cross- sections of the installation conductors should be calculated by the installer, taking into account the distances and mounting location conditions. ©2025 VESTEL MOBILITY - All rights reserved English - 5...
  • Page 7: Introduction

    Third Star (*) : DC output combination 2 C : CCS Output Blank : No CCS output Fourth Star (*) : Blank : No DC Meter EICH : Eichrecht Meter Cabinet EVC06HC ©2025 VESTEL MOBILITY - All rights reserved English - 6...
  • Page 8: Electrical Properties

    Residual current detection/Insulation supervision/Overcurrent Internal Precautions / Overvoltage / Undervoltage / Short circuit / Over Temperature / Overvoltage Protection Supported Charging Modes Mode 4 (22kW AC Optional) - Mode 3 ©2025 VESTEL MOBILITY - All rights reserved English - 7...
  • Page 9: User Interface And Authentication

    1754 mm (Length), 683 mm (Width), 458 mm (Depth) Dimensions (packed version) 2000 mm (Length), 950 mm (Width), 590 mm (Depth) Weight (Product) 263 kg. Packed Weight 363 kg with package ©2025 VESTEL MOBILITY - All rights reserved English - 8...
  • Page 10: Environmental Specifications

    Blue and Green Flashes Initialise EVSE. No LED Indicator Rechargeable. Blue Illuminates Charging. Blue Illuminates Steadily Charging is suspended or finished. Red Illuminates Steadily Error. Green Illuminates Charging process is verified. ©2025 VESTEL MOBILITY - All rights reserved English - 9...
  • Page 11: General Information

    DC CCS Output Plug Payment Terminal Option Emergency Stop Button(Optional) Access Cover for CTB, PLC Card and HMI Fan Access Cover All products images are given for representative purpose only. ©2025 VESTEL MOBILITY - All rights reserved English - 10...
  • Page 12: Plug In The Charger

    On the main screen located on the charging station screen, you can touch the plug you want to use or only connect that plug to your vehicle. CCS + CCS ©2025 VESTEL MOBILITY - All rights reserved English - 11...
  • Page 13: Dc Ccs Plug

    (AutoCharge If it is set in webconfig and vehicle registration is available in the system, charging starts without reading the RFID card) All products images are given for representative purpose only. ©2025 VESTEL MOBILITY - All rights reserved English - 12...
  • Page 14 While charging, the charging status can be viewed in the main menu.(Image is Representative.) Choose your connect�on charg�ng cable to your car All products images are given for representative purpose only. ©2025 VESTEL MOBILITY - All rights reserved English - 13...
  • Page 15: Stop Charging

    Touch the “Stop Charging” button on the screen to stop charging. All products images are given for representative purpose only. Scan your RFID card or the QR Code to stop charging. All products images are given for representative purpose only. ©2025 VESTEL MOBILITY - All rights reserved English - 14...
  • Page 16: Emergency Button (Optional)

    After disconnecting, you will be automatically switched to the main screen. All products images are given for representative purpose only. 9.4 - EMERGENCY BUTTON (Optional) Please follow the screen when the emergency stop is pressed. ©2025 VESTEL MOBILITY - All rights reserved English - 15...
  • Page 17 ©2025 VESTEL MOBILITY - All rights reserved English - 16...
  • Page 18: Door Switch

    Note: The tilt angle is 30 degrees by default, but this value can be changed via WEB UI connection. ©2025 VESTEL MOBILITY - All rights reserved English - 17...
  • Page 19: Circuit Breaker Locations For Charging Outputs

    • If the MCB has been activated only in the versions with CCS output, check the insulation of the related output cable. Then, switch the MCB on as shown in the figure below. ©2025 VESTEL MOBILITY - All rights reserved English - 18...
  • Page 20: Error And Malfunction Conditions

    Please check if there is a power outage. Then check the upstream All outputs are distribution box current switch. If General error unavailable the outputs are still unavailable, please contact the authorized service. ©2025 VESTEL MOBILITY - All rights reserved English - 19...
  • Page 21: Cleaning And Maintenance

    Distribution elements (MCCB, MCB RCCB). Distribution elements (MCCB, MCB RCCB) should be checked and tightened when going for maintenance. These elements can be tightened with a screwdriver with a torque of 2 Nm. ©2025 VESTEL MOBILITY - All rights reserved English - 20...
  • Page 22 During lifting, there should be a minimum angle of 60 degrees at both rope ends as shown in the image. Using a shorter sling will cause damage to the product. ©2025 VESTEL MOBILITY - All rights reserved English - 21...
  • Page 23: Wireless Lan Transmitter Specifications

    2.4 GHz and 5 GHz wireless LANs. Hereby, Vestel Mobilite SAN. VE TİC. A.Ş., declares that the radio equipment type EVC is in compliance with Directive 2014/53/EU and Radio Equipment Regulations 2017. The full text of the EU declaration of conformity is available at the following address: doc.vosshub.com.
  • Page 24 Zafer SB Mah. Ayfer Sok. No:22 İç Kapı No:1 Gaziemir, İzmir/ TÜRKİYE Telefon (pbx) : 90 (232) 251 72 90 Fax : 90 (232) 251 73 13 Gaziemir V.D. : 837 001 0241 ©2025 VESTEL MOBILITY - All rights reserved English - 23...
