ELECTRIC VEHICLE CHARGER
EVC04 Ser�es
User Manual
© 2025 VESTEL MOBILITY - All rights reserved
English - 1
Table of
Contents
Previous
Page
Next
Page
1
2
3
4
5
Advertisement
Table of Contents
Need help?
Do you have a question about the EVC04 Series and is the answer not in the manual?
Ask a question
Questions and answers
Subscribe to Our Youtube Channel
Related Manuals for VESTEL EVC04 Series
Battery Charger VESTEL MOBILITY EVC04 Series Installation Manuallines
Electric vehicle charger (182 pages)
Automobile Accessories VESTEL EVC04 Series Installation Manuallines
Electric vehicle charger (137 pages)
Battery Charger VESTEL EVC04 Series Assembly & Installation Manuallines
Electric vehicle charger (120 pages)
Battery Charger VESTEL EVC04 Series Installation Manualline
Electric vehicle charger (105 pages)
Automobile Accessories VESTEL EVC04 Series Installation Manualline
Electric vehicle charger (94 pages)
Battery Charger VESTEL EVC04 Series Installation Manuallines
Electric vehicle charger (88 pages)
Battery Charger VESTEL EVC04 Series Installation Manual
Electric vehicle charger (81 pages)
Automobile Accessories VESTEL EVC04 Series Installation Manuallines
Electric vehicle charger (81 pages)
Battery Charger VESTEL EVC04 Series User Manual
Electric vehicle charger (72 pages)
Battery Charger VESTEL EVC04 Series User Manual
Electric vehicle charger (72 pages)
Automobile Accessories VESTEL EVC04 Series User Manual
Electric vehicle charger (71 pages)
Battery Charger VESTEL MOBILITY EVC04 Series User Manual
Electric vehicle charger (59 pages)
Battery Charger VESTEL EVC04 Series User Manual
Electric vehicle charger (54 pages)
Automobile Accessories VESTEL EVC04 Series Installation Manuallines
Electric vehicle charger (35 pages)
Automobile Accessories VESTEL BASE EVC04 Series User Manual
Electric vehicle charger (23 pages)
VESTEL EVC04 / EVC04-AC / EVC04-AC22 Series Manual
(article)
Summary of Contents for VESTEL EVC04 Series
Page 1
ELECTRIC VEHICLE CHARGER EVC04 Ser�es User Manual © 2025 VESTEL MOBILITY - All rights reserved English - 1...
Page 2: Table Of Contents
5.1.3.3 - VEHICLE CONNECTION & CHARGING ............26 5.1.3.3.1 - SOCKET EQUIPPED MODEL ............... 26 5.1.3.3.1.1 - VEHICLE CONNECTION & CHARGING ........26 5.1.3.3.1.2 - STOP CHARGING ............... 28 5.1.3.3.2 - ATTACHED CABLE MODEL ..............29 © 2025 VESTEL MOBILITY - All rights reserved English - 1...
Page 3
8.3.2 - DC 6mA LEAKAGE CURRENT SENSOR BEHAVIOR ............55 9 - CLEANING AND MAINTENANCE ....................... 56 10 - UK REGULATION CHANGES ACCORDING TO SMART CHARGING (OPTIONAL) .......... 57 © 2025 VESTEL MOBILITY - All rights reserved English - 2...
Page 4: Safety Information
• Do not touch end terminals, electric vehicle connector and other hazardous live parts of the charging station with sharp metallic objects. © 2025 VESTEL MOBILITY - All rights reserved English - 3...
Page 5: Ground Connection Warnings
To avoid a risk of fire or electric shock, do not use this device with an extension cable. If the mains cable or vehicle cable is damaged it must be replaced by the manufacturer, its service agent, or similarly qualified persons in order to avoid a hazard. © 2025 VESTEL MOBILITY - All rights reserved English - 4...
Page 6: Wall Mounting Warnings
This unit is rated for indoor or outdoor installation. If this unit is mounted outdoors, the hardware for connecting the conduits to the unit must be rated for outdoor installation and be installed properly to maintain the proper IP rating on the unit. © 2025 VESTEL MOBILITY - All rights reserved English - 5...
Page 7: General Information
Charging station connection Charging station Ethernet cable union nut connection cable gland nut Charging station Ethernet Charging Cable (Optional) or connection cable gland nut Out of use Charging cable © 2025 VESTEL MOBILITY - All rights reserved English - 6...
Page 8: Mid Models
Status indicator LED MID Meter Display (Optional) Socket Outlet Product Label Charging station connection cable union nut Charging station Ethernet connection cable gland nut Charging Cable (Optional) or Out of use © 2025 VESTEL MOBILITY - All rights reserved English - 7...
Page 9: Plug Charging Cable
Press the button on top of the charging plug holder in order to release charging plug from the charger, and unplug the charging plug. Then plug the charging plug to the vehicle to start charging. © 2025 VESTEL MOBILITY - All rights reserved English - 8...
Page 10: Behaviour Of The Status Information Led
2 seconds OFF Charging station is reserved. Blinks red and Charging station is waiting for Eco blue Time interval and Waiting in Peak Hours Mode. 1 sec Constant Red Firmware update © 2025 VESTEL MOBILITY - All rights reserved English - 9...
Page 11
Start/stop charging attemption with times unauthorised RFID card Three Times Constant Yellow Altered Firmware Blinking Yellow Tamper switch is activated 3 sec Blinks Green Randomized Delay (Only UK) 500msec ON 500msec OFF © 2025 VESTEL MOBILITY - All rights reserved English - 10...
Page 12: Description
-T1PUL : Case C Connection with Type-1 UL vehicle connector 6th Asterisk (*) can be one of the following: Blank : EVC04 standard cabinet ZEN : Zenith Cabinet LIB : Libra Cabinet Cabinet EVC04 © 2025 VESTEL MOBILITY - All rights reserved English - 11...
Page 13: Technical Specification
LTE: B1 (2100 MHz), B3 (1800 MHz), B7 (2600 MHz), B8 (900 MHz), B20 (800 MHz), B28A (700 MHz) WCDMA: B1 (2100 MHz), B8 (900 MHz) GSM: B3 (1800 MHz), B8 (900 MHz) © 2025 VESTEL MOBILITY - All rights reserved English - 12...
Page 14: Mechanical Specifications
-35 °C to 55 °C (without direct sunlight) -25 °C to 50 °C (optionaly product has RCCB) Humidity 5% - 95% (relative humidity, without condensation) Altitude 0 - 4,000m © 2025 VESTEL MOBILITY - All rights reserved English - 13...
Page 15: Charging
If you delete the last RFID card from the local RFID card list, then your charger starts to behave as autostart mode. © 2025 VESTEL MOBILITY - All rights reserved English - 14...
Page 16: Socket Equipped Model
No LED Indication No LED Indication Charging starts and status indicator LED Charging starts automatically, and status glows in blue. indicator LED glows in blue. © 2025 VESTEL MOBILITY - All rights reserved English - 15...
Page 17: Stop Charging
No LED No LED Indication Indication Unplug the charging cable from the station. Unplug the charging cable from the station. No LED Indication No LED Indication © 2025 VESTEL MOBILITY - All rights reserved English - 16...
Page 18: Attached Cable Model
No LED Indication No LED Indication Charging starts automatically, and status Charging starts automatically, and status indicator LED glows in blue. indicator LED glows in blue. © 2025 VESTEL MOBILITY - All rights reserved English - 17...
Page 19: Stop Charging
No LED Indication No LED Indication NOTE : If you delete the last RFID card from the local RFID card list, then your charger starts to behave as autostart mode. © 2025 VESTEL MOBILITY - All rights reserved English - 18...
Page 20: Rfid Authorized Mode
Insert the charging plug to the vehicle inlet Insert the charging plug to the vehicle inlet and charging station socket outlet. and charging station socket outlet. No LED Indication No LED Indication © 2025 VESTEL MOBILITY - All rights reserved English - 19...
Page 21
NOTE : Charging operation is rejected by the charging station when you want to start charging with an unauthorized card. It takes around one minute to reboot your charging station after it resets. © 2025 VESTEL MOBILITY - All rights reserved English - 20...
Page 22: Stop Charging
No LED No LED Indication Indication Unplug the charging cable from the station. Unplug the charging cable from the station. No LED Indication No LED Indication © 2025 VESTEL MOBILITY - All rights reserved English - 21...
Page 23: Attached Cable Model
Insert the charging plug to the vehicle inlet. No LED Indication No LED Indication Tap the RFID card to the RFID reader. Tap the user RFID card to the reader. 4 sec 4 sec © 2025 VESTEL MOBILITY - All rights reserved English - 22...
Page 24
NOTE: Charging operation is rejected by the charging station when you want to start charging with an unauthorized card. It takes around one minute to reboot your charging station after it resets. © 2025 VESTEL MOBILITY - All rights reserved English - 23...
Page 25: Stop Charging
Insert the charging plug to the dummy socket Insert the charging plug to the charging plug of the station. holder of the station. No LED Indication No LED Indication © 2025 VESTEL MOBILITY - All rights reserved English - 24...
Page 26: Smart Application Authorized Mode (Optional With Wi-Fi)
Internet remotely, you need to configure Internet connection settings of your EV charger from “Connectivity” tab in “Device Settings” menu. You can either use Ethernet LAN connectivity or WiFi WLAN connectivity option. © 2025 VESTEL MOBILITY - All rights reserved English - 25...
Page 27: Vehicle Connection & Charging
Insert the charging plug to the vehicle inlet Insert the charging plug to the vehicle inlet and charging station socket outlet. and charging station socket outlet. No LED Indication No LED Indication © 2025 VESTEL MOBILITY - All rights reserved English - 26...
Page 28
NOTE : Charging operation is rejected by the charging station when you want to start charging with an unauthorized card. It takes around one minute to reboot your charging station after it resets. © 2025 VESTEL MOBILITY - All rights reserved English - 27...
Page 29: Stop Charging
You may stop charging by unplugging Method3.You may stop charging by unplugging the charging from the vehicle first. the charging cable from the vehicle. No LED Indication No LED Indication © 2025 VESTEL MOBILITY - All rights reserved English - 28...
Page 30: Attached Cable Model
No LED Indication No LED Indication Insert the charging plug to the vehicle inlet. Insert the charging plug to the vehicle inlet. No LED Indication No LED Indication © 2025 VESTEL MOBILITY - All rights reserved English - 29...
Page 31
NOTE: Charging operation is rejected by the charging station when you want to start charging with an unauthorized card. It takes around one minute to reboot your charging station after it resets. © 2025 VESTEL MOBILITY - All rights reserved English - 30...
Page 32: Stop Charging
You may stop charging by unplugging Method3.You may stop charging by unplugging the charging from the vehicle first. the charging cable from the vehicle. No LED Indication No LED Indication © 2025 VESTEL MOBILITY - All rights reserved English - 31...
Page 33: Application Modes
• When the charger starts to wait the eco charge interval, in the first 5 minutes, indication LED blinks blue and red colours. After 5 minutes the LED stops blinking blue and red colours. Similarly when © 2025 VESTEL MOBILITY - All rights reserved English - 32...
Page 34: 4.2- Delay Charge Function
For socket equipped models, it is possible to fix the charging cable to the charging station by locking the socket interlock permanently. This feature can be activated from lockable cable function in the “Advanced Settings” tab in “Device Settings” menu. © 2025 VESTEL MOBILITY - All rights reserved English - 33...
Page 35: Master And User Rfid Card Reset
“Power Optimizer” setting in “Advanced Settings” tab in “Device Settings” menu. RCCB MCBs Power Optimizer Meter Household Main Switch Appliances RCCB Grid Utility Meter EVC04 Communication (ModBUS) Visual representation is provided © 2025 VESTEL MOBILITY - All rights reserved English - 34...
Page 36: Rfid Local List Authorized Mode & Accept All Rfids Mode
No LED Indication No LED Indication Tap the user RFID card to the reader. Tap the RFID card to the RFID reader. 4 sec 4 sec © 2025 VESTEL MOBILITY - All rights reserved English - 35...
Page 37
NOTE : Charging operation is rejected by the charging station when you want to start charging with an unauthorized card. It takes around one minute to reboot your charging station after it resets. © 2025 VESTEL MOBILITY - All rights reserved English - 36...
Page 38: Stop Charging
No LED Indication No LED Indication Unplug the charging cable from the station. Unplug the charging cable from the station. No LED Indication No LED Indication © 2025 VESTEL MOBILITY - All rights reserved English - 37...
Page 39: Attached Cable Model
Insert the charging plug to the vehicle inlet. No LED Indication No LED Indication Tap the RFID card to the RFID reader. Tap the RFID card to the RFID reader. 4 sec 4 sec © 2025 VESTEL MOBILITY - All rights reserved English - 38...
Page 40
NOTE : Charging operation is rejected by the charging station when you want to start charging with an unauthorized card. It takes around one minute to reboot your charging station after it resets. © 2025 VESTEL MOBILITY - All rights reserved English - 39...
Page 41: Stop Charging
Insert the charging plug to the charging plug Insert the charging plug to the charging plug holder of the station. holder of the station. No LED Indication No LED Indication © 2025 VESTEL MOBILITY - All rights reserved English - 40...
Page 42: Ocpp Central System Connected Mode (Optional)
Tap the RFID card to the RFID reader you may start charging with a card which is provided by start charging with a card which is provided by your charging operator. your charging operator. 4 sec 4 sec © 2025 VESTEL MOBILITY - All rights reserved English - 41...
Page 43
NOTE : Charging operation is rejected by the charging station when you want to start charging with an unauthorized card. It takes around one minute to reboot your charging station after it resets. © 2025 VESTEL MOBILITY - All rights reserved English - 42...
Page 44: Stop Charging
No LED No LED Indication Indication Unplug the charging cable from the station. Unplug the charging cable from the station. No LED Indication No LED Indication © 2025 VESTEL MOBILITY - All rights reserved English - 43...
Page 45: Attached Cable Model
Tap the RFID card to the RFID reader. You may start charging with a card which is provided by start charging with a card which is provided by your charging operator. your charging operator. 4 sec 4 sec © 2025 VESTEL MOBILITY - All rights reserved English - 44...
Page 46
NOTE : Charging operation is rejected by the charging station when you want to start charging with an unauthorized card. It takes around one minute to reboot your charging station after it resets. © 2025 VESTEL MOBILITY - All rights reserved English - 45...
Page 47: Stop Charging
Insert the charging plug to the dummy socket Insert the charging plug to the charging plug of the station. holder of the station. No LED Indication No LED Indication © 2025 VESTEL MOBILITY - All rights reserved English - 46...
Page 48: Ocpp 1.6 Json Additional Features
There are two types of restart. Software or hardware reset may be selected. 5.2.3.4 - UNLOCKING THE SOCKET If the charging cable is locked at the station, the service provider may unlock the cable via this feature. © 2025 VESTEL MOBILITY - All rights reserved English - 47...
Page 49: Plug & Charge (Optional)
No LED Indication No LED Indication Charging starts and status indicator LED Charging starts automatically, and status glows in blue. indicator LED glows in blue. © 2025 VESTEL MOBILITY - All rights reserved English - 48...
Page 50: Stop Charging
No LED No LED Indication Indication Unplug the charging cable from the station. Unplug the charging cable from the station. No LED Indication No LED Indication © 2025 VESTEL MOBILITY - All rights reserved English - 49...
Page 51: Attached Cable Model
No LED Indication No LED Indication Charging starts automatically, and status Charging starts automatically, and status indicator LED glows in blue. indicator LED glows in blue. © 2025 VESTEL MOBILITY - All rights reserved English - 50...
Page 52: Stop Charging
Insert the charging plug to the charging plug Insert the charging plug to the charging plug holder of the station. holder of the station. No LED Indication No LED Indication © 2025 VESTEL MOBILITY - All rights reserved English - 51...
Page 53: Locked Cable Function (Model With Socket)
Turn on the power to your charging station. plug the charging cable to the socket outlet. The cable becomes locked and the charging station starts behaving as an attached cable model. © 2025 VESTEL MOBILITY - All rights reserved English - 52...
Page 54: Mid Meter Models (Optional)
If the status information LED is constant red, turn off the charging station and turn on again. if the LED is still constant red then call an authorized service. © 2025 VESTEL MOBILITY - All rights reserved English - 53...
Page 55: Other Error Conditions
10 meters - stay inside the range. NOTE : If you face a Wi-Fi connection problem in controlling the charger please restart your router and check the connections. © 2025 VESTEL MOBILITY - All rights reserved English - 54...
Page 56: Tripping Relay On Products With Residual Current Device (Optional)
If the charging station goes to error state due to DC leakage current, charging cable must be unplugged from vehicle and then from the charging station to reset this error. © 2025 VESTEL MOBILITY - All rights reserved English - 55...
Page 57: Cleaning And Maintenance
• Do not use abrasive cloths and detergents. Microfiber cloth is recommended. Failure to follow these warnings may result in death and serious injuries. Also, it may cause damage to your device. © 2025 VESTEL MOBILITY - All rights reserved English - 56...
Page 58: Regulation Changes According To Smart Charging (Optional)
“Waiting for random delay, Charging will start at hh:mm” will be shown on the screen as below while OCPP mode and random delay mode are active sync of the time information from the server. © 2025 VESTEL MOBILITY - All rights reserved English - 57...
Page 59
Continue charging at the end of off-peak interval (Enabled / Disabled) vi. Continue charging without re-authentication after power loss (Enabled / Disabled) Off-peak charging function will be active if and only if device is connected to the central system. © 2025 VESTEL MOBILITY - All rights reserved English - 58...
Page 60
For the unit in standalone mode the settings will be as above. For Standalone modes, off peak charging will be hidden because of the time sync issue. Randomised Delay Maximum Duration, can take values between 0 and 1800. © 2025 VESTEL MOBILITY - All rights reserved English - 59...
Page 61
Material recycling helps reduce waste and conserve resources. Ensuring that old devices are collected and recycled separately will help prevent damage to the environment and human health. © 2025 VESTEL MOBILITY - All rights reserved English - 60...
Page 62
© 2025 VESTEL MOBILITY - All rights reserved English - 61...
This manual is also suitable for:
Evc04-ac22 series
Evc04-ac11 series
Evc04-ac7 series
Table of Contents
Print
Rename the bookmark
Delete bookmark?
Delete from my manuals?
Login
Sign In
OR
Sign in with Facebook
Sign in with Google
Upload manual
Upload from disk
Upload from URL
Need help?
Do you have a question about the EVC04 Series and is the answer not in the manual?
Questions and answers
