P0CKETED REAR WINDOW MOLLE PANELS
21+ 2 DOOR FORD BRONCO
MPBR-12
TOOLS
REQUIRED
- 5mm Allen Tool
- T50 Torx Tool (Provided)
WARNINGS/CAUTIONS BEFORE STARTING INSTALLATION
Before you install this kit —
instructions, warnings, cautions, and notes contained in
this installation instruction guide. Consult your vehicle
owner's manual for proper disconnection of electrical and
lifting of vehicle if required for installation of this product.
This install may require some technical skills and
knowledge of basic mechanical work. If you do not feel that
you are capable of performing this install please take this
product to a trained professional.
After reading this guide please contact us with any
questions or concerns before installing product.
Customer Service: 855-680-9595
DV8 Offroad is not responsible for any bodily injury or harm to you
or your vehicle as a result of an improper install.
555 E Queen Creek Rd
Bldg A
Chandler, AZ 85286
WWW.DV8OFFROAD.COM
SKILL
LEVEL
- Novice/Intermediate
- 1 (you) to 2 persons
Little skill level required, you can
easily install it by yourself however,
additional help will be useful
Read and understand all
INSTALLATION
PRODUCT
TIME
- 1.5 Hours
Time to install this should only
take about an hour and a half.
Proper installation of this kit required knowledge of the factory
recommended procedures for removal and installation of original
equipment components. We recommend that the factory shop manual
and any special tools needed to service your vehicle be on hand during
the installation. Installation of this kit without proper knowledge of the
factory recommended procedures may affect the performance of these
components and the safety of the vehicle
• Always wear eye protection when operating power tools
Inspect all contents of this package to make sure product is not damaged
and all installation hardware has been included. If parts are missing from
kit, please be prepared to provide the following information
1. Name of purchase location
2. Bar Code on side of box
3. Date above bar code
4. Date inside box cover
NEED HELP?
MANUAL
REQUIRED
855-680-9595
Advertisement
Related Manuals for DV8 OFFROAD MPBR-12
Summary of Contents for DV8 OFFROAD MPBR-12
- Page 1 1. Name of purchase location Customer Service: 855-680-9595 2. Bar Code on side of box DV8 Offroad is not responsible for any bodily injury or harm to you 3. Date above bar code or your vehicle as a result of an improper install.
- Page 2 INSTALLATION MANUAL Begin by unpacking all items and inspecting for missing pieces or damage. If you have any concerns, please contact the company the product was purchased from. Extra hardware may be included with the product. HARDWARE INCLUDED (20) M8x30mm Bolts (20) M8 Split Washer (20) M8 Flat Washers STEP 1 |...
- Page 3 INSTALLATION MANUAL STEP 2 | Use the provided T50 torx tool remove the (3) hard top mounting bolts circled. STEP 3 | Using the factory hardtop hardware, molle panels rear base bracket. Ensure that the bracket is adjusted toward the vehicles cargo area fully before securing the factory hardware with the provided T50 torx tool.
- Page 4 INSTALLATION MANUAL STEP 4 | Loosely mount the molle panels front base bracket behind the vehicles “B” pillar using the factory hardware. STEP 5 | Using the provided M8 hardware and a #5 Allen tool, loosely secure the roll-bar mounting bracket as shown.
- Page 5 INSTALLATION MANUAL STEP 6 | Lay the molle panel against the mounting brackets as shown to align the all (7) mounting holes. Before securing mounting brackets in place ensure that the molle panel does not hit/rub on factory interior trim panels with all (7) panel mounting holes aligned With the (7) mounting holes align set the molle panel off to the side and secure the...
- Page 6 INSTALLATION MANUAL STEP 8 | If you wish to remove your factory hard top and keep molle panels in place. First remove the (3) base bracket M8 Allen head bolts on each Molle panel using a #5 Allen tool. STEP 9 | Loosen but do not remove the (4) roll-bar brackets M8 Allen head bolts on each Molle panel using a #5 Allen...
- Page 7 INSTALLATION MANUAL STEP 11 | With the factory hardtop removed, reinstall the (2) base mounting brackets using the factory hardware ensuring the brackets align with the molle panel that was left in place. STEP 12 | Use the molle panels M8 allen head hardware and a #5 Allen tool to secure the panel back to the mounting bracket.
- Page 8 INSTALLATION MANUAL STEP 13 | Mounting with hardtop removed (passenger side shown): Begin by loosely mounting the roll-bar mounting bracket as shown using the provided M8 hardware and a #5 Allen tool. STEP 14 | Mount the rear base bracket using the factory hardware ensuring the bracket is fully adjusted towards the vehicles trunk area.
- Page 9 INSTALLATION MANUAL STEP 16 | Loosely mount the molle panel to the mounting brackets using the provided M8 hardware. Adjust the mounting brackets as needed. Before securing mounting brackets in place ensure that the molle panel does not hit/rub on factory interior trim panels. Secure the factory hardtop hardware using a the provided T50 torx tool and molle panels M8 hardware using a #5...
