HOMEOWNER'S MANUAL
SERVICING
AND
KEEP
ELECTRIC BOILER
MECHANICAL CONTROL
Models:
HYDRAR15-M2401M
HYDRAR18-M2401M
HYDRAR20-M2401M
HYDRAR24-M2401M
HYDRAR27-M2401M
HYDRAR29-M2401M
Caution:
THE
Do not tamper with the unit or
its controls. Call a qualified
service technician.
Manufactured by:
Dettson Industries Inc.
Sherbrooke, Qc, Canada
www.dettson.com
2018-02-16
X40246 Rev.E
Advertisement
Table of Contents
Related Manuals for Dettson HYDRAR15-M2401M
Summary of Contents for Dettson HYDRAR15-M2401M
- Page 1 DOCUMENT NEAR THE UNIT FOR FUTURE REFERENCE. its controls. Call a qualified service technician. HOMEOWNER: Manufactured by: PLEASE KEEP THIS MANUAL NEAR THE FURNACE FOR Dettson Industries Inc. FUTURE REFERENCE. Sherbrooke, Qc, Canada www.dettson.com Printed in Canada on 2018-02-16 X40246 Rev.E...
-
Page 2: Table Of Contents
Table of Contents List of Figures Figure 1: Mounting Configurations ..SAFETY Figure 2: Boiler Components ..11 1.1 DANGER, WARNING AND CAUTION . . . Figure 3: Boiler Dimensions . -
Page 3: Safety
WARNING Installation and repairs performed by unqualified persons can result in hazards to them and to SAFETY others. Installations must conform to local codes or, in the absence of such codes, to codes of the country having jurisdiction. The information contained in this manual is intended for use by a qualified technician, familiar 1.1 DANGER, WARNING AND with safety procedures and who is equipped with... -
Page 4: Installation
If the heater is left unattended during the cold weather Upon completion of the installation, this manual should season, take the following precautions: be placed back into its original envelope and kept near the boiler for future reference. a) Close the main water valve in the house and purge the pipes if possible. -
Page 5: Figure 1: Mounting Configurations
Figure 1 – Mounting Configurations Table 1 – Minimum Clearances to Combustible Material Location Clearance Top (access to elements) 13 ¼" (34 cm) Sides 4" (10 cm) Bottom Front Back... -
Page 6: Distribution System
Table 2 – Circulating Pump Flow Rates Model Minimal flow 10°F 20°F USGPM (L/min) USGPM (L/min) USGPM (L/min) HYDRAR15-M2401M 5.1 (19.3) 10.2 (38.7) 5.1 (19.3) HYDRAR18-M2401M 6.1 (23.2) 12.3 (46.4) 6.1 (23.2) HYDRAR20-M2401M 6.8 (25.8) 13.6 (51.6) 6.8 (25.8) HYDRAR24-M2401M 8.2 (30.9) -
Page 7: Boiler Installation
2.5 BOILER INSTALLATION Make sure to turn off all electrical circuits when working in the appliance. At the time of installation, the following steps should be WARNING followed. Refer to Figure 4, Figure 5 and Figure 6. 1. Choose an appropriate location. Mount the boiler IRE HAZARD securely on the wall with the help of the mounting The conductor sizing must conform to the last... -
Page 8: Operation
See Figure 5 and Figure 6. flammable material; 2. To ensure that the ambient air at the boiler is not excessively dusty or humid; 3 OPERATION 3. To have all water leaks repaired in the system as they arise. 3.1 ADJUSTMENTS AND 4. -
Page 9: Information
INFORMATION Model: ..........Serial number: . -
Page 10: Technical Data
6 TECHNICAL DATA Table 3 – Technical Specifications 15 / 11,3 63 / 54 6 / 4 HYDRAR15-M2401M 18 / 13,5 75 / 65 4 / 2 HYDRAR18-M2401M 20 / 15,0 83 / 72 3 / 2 HYDRAR20-M2401M 24 / 18,0... -
Page 11: Figure 2: Boiler Components
Figure 2 – Boiler Components... -
Page 12: Figure 3: Boiler Dimensions
Figure 3 – Boiler Dimensions ELECTRONIQUE CHAUDIERE ELECTRIQUE. SCHEMA D'INSTALLATION GÉNÉRAL ELECTRIC BOILER - GENERAL INSTALLATION DIAGRAM Figure 4 – Typical Diagram of a Single Zone Installation... -
Page 13: Figure 5: Multi-Zone Diagram With More Than One Circulator
Figure 5 – Multi-zone Diagram with more than one Circulator Figure 6 – Multi-zone Diagram with Motorized Valves... -
Page 14: Figure 7: Electrical Diagram 4 Elements
Figure 7 – Electrical Diagram 4 elements... -
Page 15: Figure 8: Electrical Diagram 6 Elements
Figure 8 – Electrical Diagram 6 elements... -
Page 16: Figure 9: Exploded View
Figure 9 – Exploded View... -
Page 17: Table 4: Parts List
Table 4 – Parts list 15-20 kW 24-29 kW Description Note B04460 B04447 Cover assembly Cover, cosmetic and wiring diagram R02L006 Tridicator L01J001 Breaker 15A G08F005 G08F010 Reducer 3/4 G11Z002 Drain faucet 3/4m B04481 B04495 Jacket B04201 Machine bracket B03970 Wall bracket L99G006 Terminal block... -
Page 18: Notes
7 NOTES...
