Models :
HYDRA09
HYDRA15
HYDRA18
HYDRA20
HYDRA24
HYDRA29
C
Manufactured by:
Dettson Industries Inc
3400, Industrial Boulevard
Sherbrooke, QC, Canada, J1L 1V8
www.dettson.ca
Attention
Do not tamper with the unit
or its controls.
qualified service technician.
Printed in Canada on 100% recycled paper
Installation Instructions
and Homeowner's Manual
INSTALLER / SERVICE TECHNICIAN :
Use the information in this manual for the installation / servicing of the
furnace and keep the document near the unit for future reference.
HOMEOWNER :
Call a
Please keep this manual near the furnace for future reference.
ELECTRIC BOILER
(3 wires 120/240 - 60 - 1)
2012-08-22
X40156 Rev. H
Advertisement
Table of Contents
Related Manuals for Dettson HYDRA09
Summary of Contents for Dettson HYDRA09
- Page 1 HYDRA09 HYDRA15 HYDRA18 HYDRA20 HYDRA24 HYDRA29 Manufactured by: Dettson Industries Inc 3400, Industrial Boulevard Sherbrooke, QC, Canada, J1L 1V8 www.dettson.ca INSTALLER / SERVICE TECHNICIAN : Use the information in this manual for the installation / servicing of the Attention furnace and keep the document near the unit for future reference.
-
