Dettson Hydra Compact HYDRAC03-E2401M Installation Instructions And Owner's Manual
Electric boiler electronic control
Hide thumbs
Also See for Hydra Compact HYDRAC03-E2401M:
Table of Contents
Advertisement
HYDRA
COMPACT
Models:
HYDRAC03-E2401M
HYDRAC04-E2401M
HYDRAC05-E2401M
HYDRAC06-E2401M
HYDRAC07-E2401M
HYDRAC08-E2401M
HYDRAC09-E2401M
HYDRAC10-E2401M
HYDRAC11-E2401M
HYDRAC12-E2401M
Manufactured by:
Dettson Industries Inc
Sherbrooke, Qc, Canada
www.dettson.ca
Attention
Do not tamper with the unit
or its controls.
qualified service technician.
Printed in Canada on 100% recycled paper
Installation Instructions
and Homeowner's Manual
INSTALLER / SERVICE TECHNICIAN :
Use the information in this manual for the installation / servicing of the
boiler and keep the document near the unit for future reference.
Call a
HOMEOWNER :
Please keep this manual near the boiler for future reference.
ELECTRIC BOILER
ELECTRONIC CONTROL
2015-06-09
c
X40203 Rev.E
