PRODUCT NAME: Madison Loveseat
ITEM NUMBER: JC025
ASSEMBLED DIMENSIONS: 35 1/4H x 51 3/4"W X 33 1/2"D
Do not over-torque assembly screws!
Over tightening may cause wood to crack,
embedded nuts to pull out or other damage.
Avoid power tools. Hand tighten only.
PRODUCTS ARE NOT INTENDED
FOR COMMERCIAL USE.
UPDATED: 10-4-2022
CAUTION
��P
Scan this QR Code
to learn more
regarding
Cleaning and Care
of
OUTDOOR FURNITURE
Customer Service: 800-367-2810
Online: www.ballarddesigns.com
REQUIRED TOOLS:
Allen Wrench (included)
Hardware Included
Ltr.
Qty.
A
6
B
6
C
1
Ltr. Qty.
D
1
Left Arm (D)
E
1
F
1
Seat (F)
1
G
Back (G)
Seat Cushion (H)
H
1
Back Cushion (I)
1
I
90mm Allen Screws
Wooden Plugs
Allen Wrench
Components
Right Arm (E)
MADE IN VIETNAM
Page 1 of 2
