PRODUCT NAME: Tybee Teak Table
ITEM NUMBER: JM107
ASSEMBLED DIMENSIONS : 30"H x 40"W x 96"D
Ltr.
Qty.
F
1
G
4
H
1
1
I
J
1
PRODUCTS ARE NOT INTENDED
FOR COMMERCIAL USE.
UPDATED: 9-14-2021
Right Leg (H)
Left Leg (I)
Occasionally wipe or hose down to remove dirt and debris.
Do not use harsh chemicals or abrasive cleaners.
Prevent accidentally discarding small parts or
hardware. Retain all carton contents until assembly
and installation are complete.
-Two person assembly suggested.
Qty.
Ltr.
A
10
B
4
C
8
4
D
E
2
Components
Kick Bar (F)
Cleaning and Care
Promptly remove spills.
Customer Service: 800-367-2810
Online: www.ballarddesigns.com
REQUIRED TOOLS:
Allen Wrench (included)
Hardware Included
Allen Screws
Allen Bolt
Allen Screws
M7 x 35mm
Metal L-Bracket
Allen Wrench
Bracket (G)
Top (J)
MADE IN VIETNAM
M7 x 70mm
M8 x 70mm
Page 1 of 2
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Ballard Designs Tybee JM107
Summary of Contents for Ballard Designs Tybee JM107
- Page 1 Customer Service: 800-367-2810 Online: www.ballarddesigns.com PRODUCT NAME: Tybee Teak Table Prevent accidentally discarding small parts or ITEM NUMBER: JM107 hardware. Retain all carton contents until assembly and installation are complete. ASSEMBLED DIMENSIONS : 30”H x 40”W x 96”D REQUIRED TOOLS: Allen Wrench (included) -Two person assembly suggested.
