CSM Series Hardware Manual 1 Introduction The CSM series DC speed control stepper motors integrate driver and motor perfectly, revolutionary to create an integrated motion control terminal with new and excellent performance. 1.1 Features • DC speed control stepper motor. •...
CSM Series Hardware Manual 2 Getting Started Please read the section below entitled “Choosing a Power Supply” for help you choosing right one. 2.1 Choosing a Power Supply When choosing a power supply,the most important thing is consider the demand for voltage and current in practical application.
CSM Series Hardware Manual 2.1.2 Current The power input current required by the CSM series motor under different supply voltages is indicated on the curve below. Normally, the input current of the CSM series motor power supply is smaller than that of the driving motor. Because the CSM series motor has a built-in driver, which realizes the power conversion function, and the driver will amplify a high-voltage and low-voltage current signal into a low-voltage and high-current signal through the power switch.
Page 6
CSM Series Hardware Manual Rated Torque 60V Peak Torque 60V Full Load Current 60V CSM34X3L-A No Load Current 60V Rated Torque 24V Peak Torque 24V Full Load Current 24V CSM34X5L-A No Load Current 24V 0.5 1 2 3 4 5 6 7 8 9 10 15 20 25 30 35 40 45 50 Rev.
Page 7
CSM Series Hardware Manual Rated Torque 48V Peak Torque 48V Full Load Current 48V CSM34X5L-A No Load Current 48V 0.5 1 2 3 4 5 6 7 8 9 10 15 20 25 30 35 40 45 50 Rated Torque 60V Peak Torque 60V Full Load Current 60V CSM34X5L-A...
CSM Series Hardware Manual 2.2 Operating Panel The CSM has an LED display panel. Indicator Status Mode Up Down Set Menu ■ The following figure explains the menu of the CSM: Parameter code The default display The default display Short press “ ”...
X3 can be used as clear alarm and disable signal. X4 can switch second gear speed. The following figure lists the common wiring modes for X1, X2, X3 and X4 input: XCOM 12-24V CSM34 Switch or Relay Power Supply (Closed: logic low) X1/X2/X3/X4...
The following figure lists the common wiring modes for Y1 and Y2 input: 12 - 24V Power Supply – Y1/Y2 Load CSM34 YCOM Connecting a sourcing output to load 12 - 24V Power Supply – Y1/Y2...
CSM Series Hardware Manual 4 Driver Installation The CSM series motor can be installed through the narrow side of the radiator using M3 or M4 screws. If possible, the motor is best secured to a smooth, flat metal surface, which helps to dissipate heat from the motor.
