Installing the Out-Front Mount
You can use the out-front mount to install the headlight and your Edge bike computer. Garmin recommends that
you adjust the mount for the viewing angle of the Edge bike computer before you install and adjust the headlight
angle.
1 Select a secure location to mount the Edge bike computer and headlight where they do not interfere with the
safe operation of your bike.
2 Use the 2.5 mm hex key to remove the screw
3 Place a rubber pad around the handlebar:
• If the handlebar diameter is 25.4 mm, use the thicker pad.
• If the handlebar diameter is 31.8 mm, use the thinner pad.
• If the handlebar diameter is 35 mm, do not use a rubber pad.
4 Place the handlebar connector around the rubber pad.
NOTE: You should align the contours on the rubber pad with the grooves on the inside of the handlebar
connector.
5 Replace the screw, and use the 2.5 mm hex key to tighten the screw.
NOTE: You should check the tightness of the screw periodically. Garmin recommends a torque specification
of 7 lbf-in. (0.8 N-m).
6 Install the Edge bike computer, and adjust the mount (optional).
2
from the handlebar connector .
