Garmin VARIA VUE Owner's Manual page 19

Viewing the Status Widget
The status widget on your Edge bike computer displays the status of the GPS, sensors, and wireless
connections. See your Edge owner's manual for more information.
Select an option:
• If your Edge bike computer uses a touchscreen, swipe down from the top of the home screen or a data
screen.
• If your Edge bike computer uses device buttons, press
The status widget appears. A flashing icon means the device is searching. A solid icon means the signal was
found or the sensor is connected.
Customizing Headlight Settings with Your Edge Bike Computer
The headlight can be programmed to emit light at varying degrees of brightness and flash at various intervals.
Contact your healthcare provider if you have epilepsy or are sensitive to bright or flashing lights.
Before you can customize Varia device settings with your Edge bike computer, you must pair the devices
(Pairing the Varia Vue with a Compatible Edge Bike Computer,
1 From the Sensors menu, select Lights.
2 Select an option:
• Select Enable to enable the light network.
• Select Network Options > Light Mode to set the light intensity mode for all lights in your network
Mode Settings, page 16).
• Select Network Options > Light Beam Activated to turn on the headlight automatically when the timer
starts or when the Edge bike computer turns on.
• Select Network Options > Test Lights to check that each light in your network is set up correctly
the Light Network, page 16).
• Select Network Options > Auto Beam Adjustment to adjust the headlight intensity automatically based
on the rate of speed. A high intensity is used at high speeds, and a low intensity is used at low speeds
(Automatic Beam Intensity,
• Select a light to view device information and customize each light in your network
page 16).
Edge Bike Computer Settings
WARNING
page 16).
or from the widgets screen.
page 14).
(Light
(Testing
(Light Network Settings,
15
