BC
50 IR WIRELESS BACKUP CAMERA
™
INSTALLATION INSTRUCTIONS
Introduction
WARNING
See the Important Safety and Product Information guide in the product box for product warnings and other
important information.
Garmin
®
strongly recommends having an experienced installer with the proper knowledge of electrical systems
install the device. Incorrectly wiring the power cable can result in damage to the vehicle or the battery and can
cause bodily injury.
This device is intended to enhance your situational awareness when used properly. If used improperly, you
could become distracted by the display.
When connecting the power cable, do not remove the in-line fuse holder. To prevent the possibility of injury or
product damage caused by fire or overheating, the appropriate fuse must be in place as indicated in the product
specifications. In addition, connecting the power cable without the appropriate fuse in place voids the product
warranty.
CAUTION
To avoid possible personal injury, always wear safety goggles, ear protection, and a dust mask when drilling,
cutting, or sanding.
NOTICE
When drilling or cutting, always check what is on the opposite side of the surface to avoid damaging the vehicle.
These installation instructions do not apply to a specific vehicle type, and are meant as a guide when
installing this product on your vehicle. For questions specific to your vehicle, you should contact the vehicle
manufacturer.
Getting the Owner's Manual
The owner's manual includes instructions for using device features and accessing regulatory information.
Go to garmin.com/manuals/BC50IR.
June 2022
GUID-1C33CFFD-55D8-4B45-B3A8-79D0C0A7E83C v2

Advertisement

Table of Contents
loading

Related Manuals for Garmin BC 50

Summary of Contents for Garmin BC 50
