Summary of Contents for Growatt MIN 3000-11400TL-XH-US

  • Page 1 MIN 3000-11400TL-XH-US Commissioning Guide...
  • Page 2: About This Document

    Before installing and operating the system, ensure that you are familiar with the product features, functions, and safety precautions provided in this document. Symbol Description Indicates a potentially hazardous situation, if not avoided, could result in serious injury or death. WARNING Copyright © Shenzhen Growatt New Energy Co., Ltd.
  • Page 3: Record Of Changes

    Instructions: Use the table below to record information regarding changes made to the document over time. Table 1 - Record of Changes Version Number Date Author/Owner Description of Change <V01> 14-MAY-2024 Initial Version Copyright © Shenzhen Growatt New Energy Co., Ltd.
  • Page 4: Table Of Contents

    6.2.2 AC Couple Setting ............................24 6.2.3 AC Charging Setting ............................24 6.2.4 Off-Grid Setting ...............................25 6.2.5 TOU Schedule Setting ..........................26 6.2.6 Quick Battery Mode Setting ........................28 6.2.7 Power Sensor Setting ...........................29 Copyright © Shenzhen Growatt New Energy Co., Ltd.
  • Page 5 8.1 Register an Account ............................32 8.2 Create a power plant ............................33 8.3 Add Data Logger to power plant ........................33 ..............35 9 Shinephone Introduction 9.1 APP Download ..............................35 9.2 APP Introduction ..............................35 Copyright © Shenzhen Growatt New Energy Co., Ltd.
  • Page 6: List Of Figures

    Figure 9 Inverter Box Wiring Diagram ...................6 Figure 10 ShineTools App QR code ..................7 Figure 11 ShineTools App icon ..................... 7 Figure 12 ShinePhone downloading QR code ..............35 Figure 13 ShinePhone App icon ..................35 Copyright © Shenzhen Growatt New Energy Co., Ltd.
  • Page 7: System Overview

    1 System Overview 1.1 Overview There are two types of configurations of MIN 3000-11400TL-XH-US, PHB (Partial Home Backup) and WHB (Whole Home Backup Version). For PHB, inverter has two AC ports, one is for grid connected and the other is for load connected. For WHB, inverter shares the common grid and load ports.
  • Page 8: Phb Energy Management System Introduction

    MIN 3000-11400TL-XH-US Commissioning Guide 1 System Overview 1.3 PHB Energy Management System Introduction MIN 3000-11400TL-XH-US PHB energy storage system diagram is shown in the figure below: Note: When installing the emergency stop switch, please refer to its Quick Guide. Figure 1 Residential Critical Load Backup System(DC Coupled)
  • Page 9: Figure 3 Residential Critical Load Backup System(Ac Coupled)

    MIN 3000-11400TL-XH-US Commissioning Guide 1 System Overview MIN 3000-11400TL-XH-US AC Couple system diagram is shown in the figure below: Figure 3 Residential Critical Load Backup System(AC Coupled) The AC Couple system wiring diagram is as follows: Figure 4 Residential Critical Load Backup System Wiring Diagram(AC Coupled)
  • Page 10: Whb Energy Management System Introduction

    MIN 3000-11400TL-XH-US Commissioning Guide 1 System Overview 1.4 WHB Energy Management System Introduction MIN 3000-11400TL-XH-US WHB energy storage system diagram is shown in the figure below: Note: When installing the emergency stop switch, please refer to its Quick Guide. Figure 5 Residential Whole Home Backup System(DC Coupled)
  • Page 11: Figure 7 Residential Whole Home Backup System (Ac Coupled)

    MIN 3000-11400TL-XH-US Commissioning Guide 1 System Overview MIN 3000-11400TL-XH-US AC Couple system diagram is shown in the figure below: Figure 7 Residential Whole Home Backup System (AC Coupled) The AC Couple system wiring diagram is as follows: Figure 8 Residential Whole Home Backup System Wiring Diagram(AC Coupled)
  • Page 12: Power On The System

    2 Power on the system All components were installed according to the installation guides, please check the following installation locations: Power on the system according to the MIN 3000-11400TL-XH-US Quick Guide which is included in the inverter package/box. Figure 9 Inverter Box Wiring Diagram ARO Battery Wiring Diagram please refer to ARO 6.6-19.8H-C1-US Quick Guide QR...
  • Page 13: Shinetools App Setup

    Shinetools is the app designed for commissioning and troubleshooting. It facilitates communication with the inverter via a built-in Wi-Fi, enabling real-time status monitoring, alarm queries, parameter configuration, diagnosis and other routine maintenance functions. Copyright © Shenzhen Growatt New Energy Co., Ltd.
  • Page 14: Connecting To Local Wi-Fi Network

    5. You can also take a 6. Select the SN label add the inverter serial photo in advance ,and recorded in the photo number then select it from album taken in the previous step Copyright © Shenzhen Growatt New Energy Co., Ltd.
  • Page 15 Serial Number on the label The label is on the left side of the inverter. The Wi-Fi password is 12345678. 11. Select to upgrade or 10. Tap in Carry on 12. Tap in Refresh skip Copyright © Shenzhen Growatt New Energy Co., Ltd.
  • Page 16: Quick Site Setup

    When installing the inverter for the first time, you need to add the inverter to the power station (O&M User only). 1.Tap in Quick Site Setup 2.Fill in the account 3.Fill in the plant information and click information and click Copyright © Shenzhen Growatt New Energy Co., Ltd.
  • Page 17 8. Click "OK" to allow recorded in the photo again. After confirmation, ShineTools to connect to taken in the previous please click "Yes" to add it devices over the network. step to the monitoring portal Copyright © Shenzhen Growatt New Energy Co., Ltd.
  • Page 18 13. Enter the device 14. If you choose to upgrade page, you can upgrade, it will enter the 15.Click "Go to upgrade" choose to upgrade or following page, click skip. "Upgrade" Copyright © Shenzhen Growatt New Energy Co., Ltd.
  • Page 19 "Yes" "Next" to proceed complete 21. If you choose WiFi, 19.Click "Network 20.You can choose WiFi or enter WiFi username and configuration method" password, click "Connect to Network" Copyright © Shenzhen Growatt New Energy Co., Ltd.
  • Page 20 27. On this page, you can page, and wait until the "Configuration successful". confirm and change the network configuration is Wait for 3 seconds to system information, then successful. move on. click "Next". Copyright © Shenzhen Growatt New Energy Co., Ltd.
  • Page 21: Local Commissioning Main Interface Introduction

    Screenshot to enter 3.5 Local Commissioning Main Interface Introduction The main interface of local commissioning consists of three parts: Internal information Power generation Fault and Warning message viewing and parameter information setting Copyright © Shenzhen Growatt New Energy Co., Ltd.
  • Page 22: Network Configuration

    Note: If the network configuration has failed, please carefully check the Wi-Fi name, password and antenna installation connection, and then try again. Notice: The inverter does not support 5GHz Wi-Fi network. Copyright © Shenzhen Growatt New Energy Co., Ltd.
  • Page 23 “Connect to Network” 5.Prompt “ Configuring, 6.Prompt indicating a 4.Prompt “ SIM service is please be patient . ..” is successful configuration is searching ...” is displayed displayed displayed Copyright © Shenzhen Growatt New Energy Co., Ltd.
  • Page 24: Grid Code Mapping Table

    Note: The different grid codes can be changed according to local regulation in the Grid Code icon. Do not change the grid code during grid connection. It takes about 300 seconds for reconnection to the grid after changing the grid code. Copyright © Shenzhen Growatt New Energy Co., Ltd.
  • Page 25: Energy Management System(Ems)

     The fastest method to charge the battery (if allowed by the utility) is to connect the AC output of the inverter to the grid without any PV input, turn on the AC charging function (6.2.3) and set the EMS mode of the system to TOU Charging (6.2.5). Copyright © Shenzhen Growatt New Energy Co., Ltd.
  • Page 26: Management System Mode Introduction

    6 Energy Management System(EMS) MIN 3000-11400TL-XH-US Commissioning Guide 6.1 Management System Mode Introduction The MIN 3000-11400TL-XH-US system provides seven energy storage modes to choose. Storage Mode Description Use PV production for self-consumption, then charge/discharge battery as needed to maximize self-consumption.
  • Page 27 Charge battery from PV production and grid power (if needed) until it is full. Only then use PV production for self-consumption and grid. Battery First (TOU Charging) PHB Battery First Mode Diagram WHB Battery First Mode Diagram Copyright © Shenzhen Growatt New Energy Co., Ltd.
  • Page 28 The battery will not charge or discharge during on-grid. The TOU Idle system runs as if it were PV only, with the battery backup available for outages. Copyright © Shenzhen Growatt New Energy Co., Ltd.
  • Page 29: Energy Management System Setting

    The Battery type setting is to choose ARO Battery or LG Battery. Factory Default is ARO/APX Battery. 3. Tap in ARO/LG/APX 1.Tap in Quick Setting icon 2.Tap in Battery type Battery button Copyright © Shenzhen Growatt New Energy Co., Ltd.
  • Page 30: Ac Couple Setting

    The AC charging is used to set whether to allow charging the battery from the Grid. Factory Default is Disabled. 1.Tap in Charge and 2.Find Enable AC Charging 3.Tap in ON/OFF button. Discharge Management Copyright © Shenzhen Growatt New Energy Co., Ltd.
  • Page 31: Off-Grid Setting

    MIN 3000-11400TL-XH-US Commissioning Guide 6.2.4 Off-Grid Setting Note: Off-grid settings only apply for the WHB system. Default: Disabled 1.Tap in Charge and 2.Find Enable AC Charging 3.Tap in ON/OFF button. Discharge Management Copyright © Shenzhen Growatt New Energy Co., Ltd.
  • Page 32: Tou Schedule Setting

    EMS Mode 07:00-15:59 Maximum Self- consumption (Load First) 16:00-17:59 TOU Idle 18:00-19:59 TOU Discharging (Grid First) 20:00-06:59 TOU Idle 2.Tap in Time of Use 1.Tap in EMS 3.Tap in Quarter 3 (e.g.) Setting Copyright © Shenzhen Growatt New Energy Co., Ltd.
  • Page 33 7.Select the required 8.Click Read to check 9. If you need to set other setting items in turn, save whether the settings are time periods, please do after confirmation correct similar operations Copyright © Shenzhen Growatt New Energy Co., Ltd.
  • Page 34: Quick Battery Mode Setting

    3.Select the mode that 1.Tap in EMS Setting needs to be set 4.Select Confirm in the 5.After a few seconds it 6. Battery Mode Setting pop- up prompt will prompt success will display the current Copyright © Shenzhen Growatt New Energy Co., Ltd.
  • Page 35: Power Sensor Setting

    If an electric meter is installed in the system, please set. Factory Default is Disabled. Note: Power Sensor: IOS = Electric meter Android = Meter 1.Tap in Quick Setting icon 2.Choose Power Sensor 3.Select Electric Meter 4.Prompt message for successful setting Copyright © Shenzhen Growatt New Energy Co., Ltd.
  • Page 36: Export Limitation Setting

    6. Click Default Power % 5. Click Export Limitation Setting to Enable via after Power Export Power Ratio %. Enter the RS485 to enable the Limitation Failure and set percentage of power. function. the percentage. accordingly. Copyright © Shenzhen Growatt New Energy Co., Ltd.
  • Page 37: Battery Life Maintenance(Important)

    The installation is not completed.  No PV and AC power can charge the battery.  b) Charge the battery SOC above 60% or higher after installation is complete and pending for AHJ/city review and approval. Copyright © Shenzhen Growatt New Energy Co., Ltd.
  • Page 38: Shineserver Operation

    Account and plant information will be the same in both the web browser version and on the ShinePhone App. 8.1 Register an Account a) Log in to our monitoring website http://server- us.growatt.com and click Register an Account. b) Fill in the appropriate information on the registration interface and log into the account after the registration is completed.
  • Page 39: Create A Power Plant

    Click on the power plant just created, enter the power plant page, and then add a data logger. The SN number of the collector is on the barcode on the side of the inverter, starting with VC. A power plant can contain multiple data loggers. Copyright © Shenzhen Growatt New Energy Co., Ltd.
  • Page 40 8 ShineServer Operation MIN 3000-11400TL-XH-US Commissioning Guide b) When you have completed these steps, you will be able to view the inverter system remotely through the ShinePhone APP and through any browser. Copyright © Shenzhen Growatt New Energy Co., Ltd.
  • Page 41: Shinephone Introduction

    ShinePhone app is a tool designed for the system owner to monitor the status of the Growatt system 24/7. It displays real-time and historical data and provides reports, alarms and various notifications of the system. ShinePhone can remotely monitor the inverter system information, which has the same function as ShineServer, and the two information are shared.
  • Page 42 2. Dashboard: Overview of 3. Plant: Plant lists and ShineServer account inverters and generation information etc. 4.GroHome: Home Energy 5.Service:Help 6. Me: Account Information information information, customer and other tools service and more Copyright © Shenzhen Growatt New Energy Co., Ltd.
  • Page 43 Download Manual Growatt USA,Inc. 9227 Reseda Blvd, #435 Northridge, CA 91324, USA. +1-866-686-0298 usaservice@ginverter.com us.growatt.com GR-UM-251-A-02 (PN: 044.0093602)
