- Page 1 FEBRUARY 2024 Installation instructions s[16]D4 Freestanding FOR PROFESSIONALS This guide is available in digital format at : www.stuv.com Find us also on: 93109234...
- Page 2 Welcome to the world of Stûv You have just opted for an eco-friendly, high-performance heating system. We hope that you enjoy using it from this moment on. You will find advice and the installation instructions in this document. The operating instructions, which are on an additional leaflet, will guide you on the use and maintenance of your Stûv.
-
Page 4: Table Of Contents
1. CONTENT 1. G ENERAL 1.1. Recommandations 1.2. Precautions regarding surrounding materials 1.3. Load-bearing capacity of the structure 1.4. Recommandations for recycling 1.5. Legal terms and conditions for use 1.6. CE labeling 1.7. Safety distances to combustible materials 2. PRESENTATION 2.1. -
Page 6: G Eneral
G ENERAL – 1.1. RECOMMANDATIONS 1. G ENERAL 1.1. Recommandations Please read the installation and usage Once the cladding has been installed, hand Any change made to the cladding may instructions before installing and using the over these instructions to the user. be dangerous. -
Page 7: Ce Labeling
G ENERAL – 1.6. CE LABELING 1.6. CE labeling Stûv sa Stûv sa Stûv sa B-5170 Bois-de-Villers (Belgique) B-5170 Bois-de-Villers (Belgique) B-5170 Bois-de-Villers (Belgique) QA161322918 QA161322918 QA161322918 13240 : 2001 / A2 : 2004 EN 13240 : 2001 / A2 : 2004 EN 13240 : 2001 / A2 : 2004 Stûv 1678 D4-freestanding Stûv 1658 D4-freestanding Stûv 1668 D4-freestanding... -
Page 8: Presentation
PRESENTATION – 2.1. UNPACkING THE PRODUCT 2. PRESENTATION 2.1. Unpacking the product The Stûv 16D4 free-standing stove consists of two kits: [ 1 ] your Stûv 16in kit including the stove and its support plate. [ 2 ] your D4-freestanding cladding kit includding: - the cube cladding, - the... -
Page 9: Overview
PRESENTATION – 2.2. OvERvIEW 2.2. Overview kit S16D4 FS: [ 1 ] Ø 180 mm flange for tubing [ 2 ] cube cladding [ 3 ] S16-in stove [ 4 ] Magnetic spacers x2 [ 5 ] Wood log storage [ ... -
Page 10: Dimensions
PRESENTATION – 2.3. DIMENSIONS 2.3. Dimensions 2.3.1. Dimensions (with optional wooden base) Ø 60 outside air admission 1658 1668 1678 1250 1450 1650 B = C 1330 smoke outlet Ø 80 The Stûv 16D4 free-standing stove is available in the 3 formats of the original Stûv 16 range. -
Page 11: Dimensions For Custom Installations
Ø 60 PRESENTATION – 2.3. DIMENSIONS 2.3.2. Dimensions for custom installations (order without optional wooden base) Ø 60 Ø 60 Ø 60 outside air admission 1658 1668 1678 1250 1450 1650 B = C 1218 1418 1618 Ø 80 IT IS IMPERATIVE TO RESPECT smoke outlet Ø... -
Page 12: Installation
INSTALLATION – 3.1. AIR INTAkE INSTALLATION 3. INSTALLATION Stûv recommends that each installation complies with installation standards EN 15287-1 or -2 and that a calculation note is drawn up in accordance with standard 13384-1 and its appendix to ensure that the appliance does not operate in a condensation regime. -
Page 13: Wood Base Preparation
3.2. Wood base preparation 3.2.1. Hole saw cutting (rear air intake only) If your installation requires a rear air intake, please make the cut-out as described below. Note: the cut is made in 2 passes [diagrams 1 and 3]. Created by Adrien Coquet from the Noun Project Cut-out stove on the left... -
Page 14: Placement Of The Metal Base And The Support Plate
INSTALLATION - 3.3. PLACEMENT OF THE METAL BASE AND THE SUPPORT PLATE [ 3 ] [ 4 ] 3.3. Placement of the metal base and the support plate 3.3.1. Definition of the niche side FIXING THE 4 THREADED INSERTS WILL DETERMINE THE FUTURE POSITION OF THE NICHE! (NICHE ON THE LEFT OR ON THE RIGHT). -
Page 15: Placement
3.3.2. Placement Refer to the Stûv logo to identify the niche side when placing the metal base! [ 1 ] [ 2 ] [ 3 ] M5x20 [ 4 ] [ 5 ] M5x8 INSTALLATION INSTRUCTIONS S[16]D4 FREESTANDING – [ EN ]... -
Page 16: Configuration For Outside Air Supply
INSTALLATION - 3.4. CONFIGURATION FOR OUTSIDE AIR SUPPLY [ 6 ] [ 7 ] 3.4. Configuration for outside air supply For further help, please refer to the If you wish to take the combustion air from outside, instructions supplied with the stove. install the air intake sleeve before installing your appliance! Created by Adrien Coquet from the Noun Project... -
Page 17: Placement Of The Stove On Its Support Plate
3.5. Placement of the stove on its support plate [ 1 ] [ 2 ] [ 3 ] [ 4 ] [ 5 ] INSTALLATION INSTRUCTIONS S[16]D4 FREESTANDING – [ EN ]... - Page 18 INSTALLATION – 3.6. PLACEMENT OF THE STOvE ON ITS SUPPORT PLATE [ 6 ] [ 7 ] [ 8 ] [ 9 ] M5x6 [ 1 0 ] [ 1 1 ] [ 1 2 ] M5x8 INSTALLATION INSTRUCTIONS S[16]D4 FREESTANDING –...
-
Page 19: Placement Of The Niche
INSTALLATION – 3.6. PLACEMENT OF THE NICHE 3.6. Placement of the niche [ 1 ] [ 2 ] [ 3 ] [ 4 ] [ 5 ] INSTALLATION INSTRUCTIONS S[16]D4 FREESTANDING – [ EN ]... - Page 20 INSTALLATION – 2.7. PLACEMENT OF THE NICHE [ 6 ] [ 7 ] [ 8 ] [ 9 ] INSTALLATION INSTRUCTIONS S[16]D4 FREESTANDING – [ EN ]...
-
Page 21: Positioning Of Flue Outlet
INSTALLATION – 3.7. POSITIONING OF FLUE OUTLET 3.7. Positioning of flue outlet [ 1 ] [ 2 ] M6x20 3.8. Maintenance Please note Wait for the stove to cool down completely before carrying out maintenance. Clean with a dry cloth. To clean your stove finishing surfaces, use traditional, non-abrasive household detergent. - Page 22 INSTALLATION INSTRUCTIONS S[16]D4 FREESTANDING – [ EN ]...
-
Page 23: Contacts
CONTACTS 4. CONTACTS Stûv stoves are designed and manufactured in Belgium by: Stûv S.A. Rue Jules Borbouse 4, B-5170 Bois-de-villers (Belgium) info@stuv.com - www.stuv.com INSTALLATION INSTRUCTIONS S[16]D4 FREESTANDING – [ EN ]... - Page 24 [NL] [DE] [IT] [ES] [PT] [CZ] [EN] [FR] [Sv] changes without prior notice. This document is available in several languages: Contact your distributor or visit www.stuv.com These instructions have been produced with the greatest of care. However, we do not accept responsibility for any...
