- Page 1 ® Gold Standard Toaster Model GST-2H Int’l Owner’s Manual Manufacturing Numbers: 9210961, 9210962, 9211004 P/N 1012011 Rev. F 03/21 www.antunes.com...
-
Page 2: Table Of Contents
Contents Overview Service/Technical Assistance Overview The Antunes Gold Standard Toaster Before Use is an energy-efficient toaster designed If any parts are missing or damaged, with a dual belt feed for toasting In Case of Damage contact Antunes Customer Service crowns, heels, and clubs. The elec-... -
Page 3: Safety Information
Contact y Install and locate the equipment if it has a damaged cord or plug, Antunes Technical Service only for its intended use as or if it is not working properly. for adjustment or repair. -
Page 4: Specifications
Specifications Depth Model & Width Height Mfg. No. GST-2H 22" (559 mm) 21" (533 mm) 17” (432 mm) 9210961 GST-2H 22" (559 mm) 21" (533 mm) 17” (432 mm) 9210962 GST-2H 22” (559 mm) 21” (533 mm) 17” (432 mm) 92110004 Model &... -
Page 5: Installation
Press the LIGHTER or DARKER or damaged, contact lane on the Bun Feeder according buttons to change the light/dark Antunes Customer Service to Bun Feeder labels. Insert buns value. The adjustment range is L1- IMMEDIATELY at +1-877-392- with the cut side facing down. -
Page 6: User Mode
Platen Thermocouple Press the PROGRAM button to the toaster on. If the error repeats, is disconnected or open. procedure to the Motor Speed contact Antunes Technical Service for y “CHEC” flashes when the Setpoint. assistance. control compartment ambient... -
Page 7: Daily Cleaning
Daily Cleaning Clean Toaster and Belt Wraps Press and release the Power button to turn the unit off. The unit enters a 45 minutes cool-down mode and automatically shuts down when complete. NOTE: The belt rollers will continue turning while in cool-down mode. -
Page 8: Quarterly Cleaning
Quarterly Cleaning Figure 3. Conveyor locks Tense Carefully remove the two top belts Remove Belt Wraps and Clean and one bottom belt. Rollers Upper Belt Wraps Turn the toaster’s power switch to the off position. The toaster Tense enters a cool-down mode and will automatically shut down when complete. -
Page 9: Annual Cleaning
Annual Cleaning Clean Cooling Fans and Electrical Housings Turn the toaster’s power switch to the off position. The toaster enters a cool-down mode and will automatically shut down when complete. Unplug the power cord. Remove the push knob and top six screws on the left side of the toaster and set aside. -
Page 10: Troubleshooting
Allow the unit to warm up for 30 minutes and then PLt continuously. Buns not recheck. If the Control Display still flashes PLt, contact °C). toasting properly. your maintenance person or Antunes Technical Service for service. Failed Platen Thermocouple. Contact your maintenance person or Antunes Technical Service for service. - Page 11 Clean fans as described in the Cooling Fan is dirty and needs to be Maintenance section of this manual. If problem persists, cleaned. contact your maintenance person or Antunes Technical Service for service. Control Display flashes HL Hi-Limit Control is tripped.
-
Page 12: Exploded Diagram 1
Exploded Diagram 1 NOTE: Use only genuine Antunes replacement parts in this unit. Use of parts other than those supplied by the manufacturer will void the warranty. P/N 1012011 Rev. F 03/21 ®... - Page 13 Exploded Diagram 2 NOTE: Use only genuine Antunes replacement parts in this unit. Use of parts other than those supplied by the manufacturer will void the warranty. P/N 1012011 Rev. F 03/21 ®...
-
Page 14: Exploded Diagram 3
Exploded Diagram 3 NOTE: See Next Page for Parts List related to this graphic. NOTE: Use only genuine Antunes replacement parts in this unit. Use of parts other than those supplied by the manufacturer will void the warranty. P/N 1012011 Rev. F 03/21... -
Page 15: Replacement Parts
Replacement Parts Item Item Part # Description Qty. Part # Description Qty. 0012913 Insulator Assembly 0506864 Bun Ramp 0012961 Door Assembly 0507092 Insulation Plate Platen Assembly (Mfg. No. 9210962 & 0507140 Alum Washer 0013024 9211004) 0600143 Spring, Compression Setting 0013234 Platen Assembly (Mfg. - Page 16 Replacement Parts Item Part # Description Qty. 0200343 Gasket 20" 7000913 Replacement Fan Kit 7000984 Main Belt 7000991 Crown & Heel Belt Line Filter 10 A (Mfg. No. 9210961 7001428 only) 206P130* Nut, HEX KEPS #6-32 (Small Pttrn) 304P105* Nut, Hex KEPS #4-40 306P130* Nut, Hex Keps #6-32 (Small Pattern) 308P124*...
-
Page 17: Wiring Diagram
Wiring Diagram Mfg No. 9210961 P/N 1012011 Rev. F 03/21 ®... - Page 18 Wiring Diagram Mfg No. 9210962 & 9211004 P/N 1012011 Rev. F 03/21 ®...
-
Page 19: Notes
Notes P/N 1012011 Rev. F 03/21 ®... -
Page 20: Limited Warranty
Travel Time & Mileage in excess of 2 hours (100 miles/160 km) round trip from the nearest authorized service agency. Antunes reserves the right to make changes in design or add any improvements on any product. The right is always reserved to modify equipment because of factors beyond our control and government regulations. Changes to update equipment do not constitute a warranty charge.
