Firewall Ports
Table 1-2. What Ports Need to be Open for Echo Functionality
Port Protocol
80 TCP
443 TCP
5500 & TCP
5999
50000 TCP
Check Connectivity
Using the latest version of Firefox, enter http://<hostname or IP of
your Echo Server> into your web browser address bar. You may have to
bypass some security warnings to access the login page. If the installation and setup
was performed successfully, then you will be presented with the Welcome to Echo
Page.
24 | Virtual Appliance Installation & Setup
Components
Echo Server
Echo Server
Echo Server
Echo Server,
Hosts, and
Terminals
Purpose
HTTP – Standard web port for the
Echo Web UI
HTTPS – Secure (SSL)
communication over http protocol
Needed for VNC Shadowing
Used by SOAP. This port needs to
be open on ALL devices within the
Echo environment.
