Kanguru KanguruClone 4 NVMe Quick Start Manual

This is a Quick Start Guide only. For detailed information about your KanguruClone NVMe Duplicator, please refer to the User Guide.
A digital copy of the User Guide can be found on our website at: support.kanguru.com
To connect an NVMe solid state drive to the KangurClone 4 NVMe:
1.
Make sure all Drive Locking Pins are pushed all the way
to the end of the duplicator.
3.
Insert the drive into one of the duplicator's M.2 ports at
about a 300 angle. Note: you can identify the Source port
location by the blue LED indicator.
5.
Slide the Drive Locking Pin into the notch located at the
rear of the NVMe drive.
It is OK to connect and disconnect Master or Target drives while the KanguruClone is powered on. However, do NOT connect or
disconnect drives while any operation is running or is in progress.
The KanguruClone NVMe Duplicator is guaranteed to be free from defect in materials and workmanship for one year. If you experience
any problems using your KanguruClone Hard Drive Duplicator or have any technical questions, please call our technical support
department. Our tech support is free and available Monday through Friday, 9am to 5pm EST.
Call 1-508-376-4245 or visit our website at www.Kanguru.com
09.25.24 v1.0 © 2024 Kanguru Solutions
KanguruClone 4 NVMe Duplicator Quick Start Guide
Secure. Anytime. Anywhere.
Models: KCLONE-4NVMe
2.
Hold the drive with the M-key notch aligned to the right
side.
4.
Press down on the back of the drive so that it lies parallel
with the duplicator. There should be a few mm space
between the drive and the duplicator.
6.
Repeat for Target drives until all drives are connected.
