GeoVision GV-APOE1612 Installation Manual

GeoVision GV-APOE1612 Installation Manual

Hide thumbs Also See for GV-APOE1612:

Advertisement

Quick Links

Download this manual
Packing List ..................................................................................................................... 1
Front Panel ....................................................................................................................... 2
LED Indicator ................................................................................................................... 2
Rear Panel ........................................................................................................................ 3
Mount Installation ............................................................................................................ 3
Leveled Installation .................................................................................................... 3
Rackmount Installation ............................................................................................... 4
Connecting to GV-IP Camera .......................................................................................... 5
Accessing the Web Interface .......................................................................................... 6
Basic Setup ...................................................................................................................... 7
Assigning an IP Address ................................................................................... 7
Configuring PoE Port Using GV-IP Device Utility .............................................. 9
Enabling the DHCP Server ..............................................................................10
Loading Default Setting ..................................................................................................11
Hardware ..................................................................................................................11
Web Interface ...........................................................................................................11
Updating Firmware .........................................................................................................12
Specifications .................................................................................................................12
GV-APOE1612
Contents

Advertisement

loading
Need help?

Need help?

Do you have a question about the GV-APOE1612 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for GeoVision GV-APOE1612

Summary of Contents for GeoVision GV-APOE1612

  • Page 1: Table Of Contents

    GV-APOE1612 Contents Packing List ........................1 Front Panel ........................2 LED Indicator ........................2 Rear Panel ........................3 Mount Installation ......................3 Leveled Installation ....................3 Rackmount Installation ....................4 Connecting to GV-IP Camera ..................5 Accessing the Web Interface ..................6 Basic Setup ........................

  • Page 2: Packing List

    GV-APOE1612 16-Port Gigabit L2+ Web Management PoE Switch Packing List 1. GV-APOE1612 5. Screw x 8 2. User Guide 6. Rack Mount Kit x 2 3. Download Page 7. Rubber Feet x 4 4. Power Cord Note: If any of these items is found missing or damaged, please contact your local supplier for replacement.

  • Page 3: Front Panel

    Front Panel IMPORTANT: The 2 SFP ports labeled 17S ~ 18S are associated with the 2 RJ-45 ports labeled 17T ~ 18T respectively. When one of the two associated ports is used, the other port will not work. For example, if the Gigabit SFP port labeled 17S is used, the Gigabit RJ-45 port labeled 17T will not function.

  • Page 4: Rear Panel

    Rear Panel Mount Installation Leveled Installation March 14, 2025...

  • Page 5: Rackmount Installation

    Rackmount Installation March 14, 2025...

  • Page 6: Connecting To Gv-Ip Camera

    Connecting to GV-IP Camera The switch can be connected to up to 16 GV-IP Cameras and 1 GV-NVR / VMS System. You can also extend the connection by connecting to another switch. Note: GV-NVR / VMS or a switch can connect to the RJ-45 ports or SFP ports. The maximum cable length for: •...

  • Page 7: Accessing The Web Interface

    Accessing the Web Interface Users can log in the Web interface to manage and set up the switch. 1. To access the Web user interface, type the default IP 192.168.0.250 into your Web browser. The login page appears. 2. Type the default username admin and password admin. Click Login In. 3.

  • Page 8: Basic Setup

    Basic Setup Refer to the following sections for the basic setup of the switch, including assigning an IP address, port PoE configuration, and switching SFP port between 1G modes. A. Assigning an IP Address Adopt one of the following alternatives to assign an IP address to the switch. Assigning a Fixed or Dynamic IP on the Web Interface 1.
  • Page 9 Assigning an IP Using GV-IP Device Utility 1. Make sure a PC and the switch are connected to the same LAN, and GV-IP Device Utility (V9.0.3 or later) is installed on the PC from our website. 2. On GV-IP Device Utility, click the button to search for the IP devices in the same LAN.

  • Page 10: Configuring Poe Port Using Gv-Ip Device Utility

    B. Configuring PoE Port Using GV-IP Device Utility You can quickly access and configure the PoE port status of the devices connected to the switch by using GV-IP Device Utility. Follow the instructions below: 1. Make sure a PC and the switch are connected to the LAN, and GV-IP Device Utility (V9.0.3 or later) is installed on the PC from our website.

  • Page 11: Enabling The Dhcp Server

    C. Enabling the DHCP Server To enable the DHCP server function on the switch, follow the instructions below. 1. On the Web interface, select DHCP Config > DHCP Server > Global Config. 2. Enable DHCP Server. To create an address pool, select DHCP Config > DHCP Server > Create Address Pool. Here, we create an address pool called “1”...

  • Page 12: Loading Default Setting

    Loading Default Setting If for any reason the device is not responding properly, you can reset it to its factory default settings either directly on the device or through its Web interface. Hardware 1. Turn on the switch. 2. Press and hold the Reset button on the front panel of the switch for 5 seconds until all the LED start blinking.

  • Page 13: Updating Firmware

    Updating Firmware 1. Select System Config > Firmware update > HTTP Upgrade. This page appears. 2. Click Select File to select the firmware file. 3. Click Apply. The upgrade process starts. 4. After the firmware is successfully upgraded, the system will automatically log out and reboot.
