GeoVision GV-APOE4813 Manual

GeoVision GV-APOE4813 Manual

48-port gigabit web management poe switch
Hide thumbs Also See for GV-APOE4813:
Table of Contents

Advertisement

Quick Links

Download this manual
Packing List ..................................................................................................................... 1
Front Panel ....................................................................................................................... 2
LED Indicator ................................................................................................................... 2
Rear Panel ........................................................................................................................ 3
Mount Installation ............................................................................................................ 3
Leveled Installation .................................................................................................... 3
Rackmount Installation ............................................................................................... 4
Connecting to GV-IP Camera .......................................................................................... 5
Accessing the Web Interface .......................................................................................... 6
Basic Setup ...................................................................................................................... 7
Assigning an IP Address ................................................................................... 7
Configuring PoE Port Using GV-IP Device Utility .............................................. 9
Switching SFP Port between 1G / 10G Modes .................................................10
Enabling the DHCP Server ..............................................................................10
Loading Default Setting ..................................................................................................12
Hardware ..................................................................................................................12
Web Interface ...........................................................................................................12
Updating Firmware .........................................................................................................13
Specifications .................................................................................................................13
GV-APOE4813
Content

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the GV-APOE4813 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for GeoVision GV-APOE4813

Summary of Contents for GeoVision GV-APOE4813

  • Page 1: Table Of Contents

    GV-APOE4813 Content Packing List ........................1 Front Panel ........................2 LED Indicator ........................2 Rear Panel ........................3 Mount Installation ......................3 Leveled Installation ....................3 Rackmount Installation ....................4 Connecting to GV-IP Camera ..................5 Accessing the Web Interface ..................6 Basic Setup ........................

  • Page 2: Packing List

    GV-APOE4813 48-Port Gigabit Web Management PoE Switch Packing List 1. GV-APOE4813 2. Power Cord 3. Screw x 8 4. Rack Mount Kit 5. Rubber Feet x 4 Note: If any of these items is found missing or damaged, please contact your local supplier for replacement.

  • Page 3: Front Panel

    Front Panel Gigabit RJ-45 Ports SFP+ Uplink Ports Console Port Reset Button IMPORTANT: The Console port is used to connect to the serial port of a computer or other terminal device for debugging only. LED Indicator Color/Status Description No power supply Green System powered on No devices connected to the corresponding port...

  • Page 4: Rear Panel

    Rear Panel Mount Installation Leveled Installation January 22, 2024...

  • Page 5: Rackmount Installation

    Rackmount Installation January 22, 2024...

  • Page 6: Connecting To Gv-Ip Camera

    • Gigabit RJ-45 (Cat.5e, 6) can achieve 250 m (820 ft) by setting the network bandwidth of the 48 PoE ports to 10 Mbps per port on the switch’s Web interface. See details in 3.6 Port Rate, GV-APOE4813 User’s Manual. For connection that exceeds 250 m (820 ft), use the 10 Gigabit SFP+ ports.

  • Page 7: Accessing The Web Interface

    Accessing the Web Interface Users can log in the Web interface to manage and set up the switch. 1. To access the Web user interface, type the default IP 192.168.0.250 into your Web browser. The login page appears. 2. Type the default username admin and password admin. Click Login In. 3.

  • Page 8: Basic Setup

    Basic Setup Refer to the following sections for the basic setup of the switch, including assigning an IP address, port PoE configuration, and switching SFP port between 1G / 10G modes. A. Assigning an IP Address Adopt one of the following alternatives to assign an IP address to the switch. Assigning a Fixed or Dynamic IP on the Web Interface 1.
  • Page 9 Assigning an IP Using GV-IP Device Utility 1. Make sure a PC and the switch are connected to the same LAN, and GV-IP Device Utility (V.8.9.9 or later) is installed on the PC from our website. 2. On GV-IP Device Utility, click the button to search for the IP devices in the same LAN.

  • Page 10: Configuring Poe Port Using Gv-Ip Device Utility

    B. Configuring PoE Port Using GV-IP Device Utility You can quickly access and configure the PoE port status of the devices connected to the switch by using GV-IP Device Utility. Follow the instructions below: 1. Make sure a PC and the switch are connected to the LAN, and GV-IP Device Utility (V.8.9.9 or later) is installed on the PC from our website.

  • Page 11: Switching Sfp Port Between 1G / 10G Modes

    C. Switching SFP Port between 1G / 10G Modes By default, the switch’s SFP port ethernet speed is set to 10G. Follow the instructions below to switch the SFP ports between 1G and 10G modes: 1. On the Web interface, select Switch Config > Port Config > Port 10G Mode. 2.
  • Page 12 3. To create an address pool, select DHCP Config > DHCP Server > Create Address Pool. Here, we create an address pool called “1” as an example. 4. To configure IP parameters, type the switch’s IP in IP Address and the switch’s netmask in Netmask, and click Apply.

  • Page 13: Loading Default Setting

    Loading Default Setting If for any reason the device is not responding properly, you can reset it to its factory default settings either directly on the device or through its Web interface. Hardware 1. Turn on the switch. 2. Press and hold the Reset button on the front panel of the switch for 5 seconds until all the LED start blinking.

  • Page 14: Updating Firmware

    Updating Firmware 1. Select System Config > Firmware update > HTTP Upgrade. This page appears. 2. Click Select File to select the firmware file. 3. Click Apply. The upgrade process starts. 4. After the firmware is successfully upgraded, the system will automatically log out and reboot.
