AURATON 200 TRA
Ovner's manual ver. 20200327
The document contains information on the safety, assembly and use of the Auraton 200 TRA device.
Wireless electronic head and thermostat set
Thank you for purchasing the modern temperature controller based on an advanced microprocessor
AURATON 200 TRA.
U
FrostGuard function
Protects the interior from freezing.
&
Enables cyclic reduction of set temperature by 3°C for 6 hours.
Backlit LCD display
LCD
The backlit display enables device control even in dark rooms.
Basic information
The Auraton TRA head with the Auraton 200 TRA controller is a programmable electronic room

Advertisement

loading
Need help?

Need help?

Do you have a question about the 200 TRA and is the answer not in the manual?

Questions and answers

Related Manuals for AURATON 200 TRA

Summary of Contents for AURATON 200 TRA

  • Page 1 AURATON 200 TRA Ovner’s manual ver. 20200327 The document contains information on the safety, assembly and use of the Auraton 200 TRA device. Wireless electronic head and thermostat set Thank you for purchasing the modern temperature controller based on an advanced microprocessor AURATON 200 TRA.
  • Page 2 There can be any number of radiators with Auraton TRA heads in one room or there can be any number of circuits for a given room on the floor heating manifold, but they should all be paired with the same Auraton 200 TRA controller.
  • Page 3 Temperature decrease key Pairing buttons Acknowledge or on/off key • Hold for 5 seconds – controller on/off ( • short press – acknowledge temperature setting ( Display screen Temperature In normal operating mode, the controller displays the temperature of the room it is installed in. Temperature unit (...
  • Page 4 Indicates temperature displayed in centigrade. Temporary temperature decrease mode indicator ( Active during the “temporary temperature reduction” program Temporary temperature decrease mode programming indicator ( Indicates that the user is in “temporary temperature reduction” mode. Visible when the mode is not currently implemented, but the “temporary temperature reduction”...

  • Page 5: Battery Installation/Replacement

    Place two AAA 1.5 V batteries in the battery socket observing the correct polarity. NOTE: We recommend using alkaline bateries to supply AURATON controllers. Rechargeable batteries should not be used because their rated voltage is too low. Fixing the controller to the wall To fix the AURATON 200 TRA controller to the wall:...
  • Page 6 No expansion bolts are needed for wooden walls. Just drill holes diameter 2.7 mm (instead of 6 mm) and screw the screws directly into the wood. NOTE: Do not mount the Auraton 200 TRA controller on metal surfaces, as this significantly reduces the range of radio communication. Holes for fixing screws.

  • Page 7: First Start

    Alternative fixing methods The controller can be mounted to a smooth surface with e.g. two-sided adhesive tape. The controller can also be placed in any location on an even surface on a support at the back of the enclosure. First start After correct installation on batteries, the LCD will display, for a second, all segments (display test) followed by the firmware version number.
  • Page 8 FrostGuard function AURATON 200 TRA controller features the special FrostGuard function to protect the room from possible freezing. The function is activated even when the controller is switched off. With the controller switched off, when the room temperature drops to 2°C, the Fr ( ) symbols will appear and signal will be sent to the receiver to start heating.
  • Page 9 Setting the temporary temperature decrease mode & If, for various reasons, we would like to start reducing the room temperature by 3°C every day at the same time, it is possible to reduce it temporarily for a period of 6 hours. To do Press and hold for 3 seconds both keys.

  • Page 10: Head Assembly

    Heater with insert M30x1,5 or floor heating manifold In order to mount the Auraton TRA head on a radiator or floor heating manifold with the most popular M30x1.5 insert on the market, perform the following actions: Screw the reduction fitting A (1) onto the insert delivered with the head (all the way).
  • Page 11 Take off the head battery cover (2) using a flat screwdriver. Install two AAA batteries in the head, paying attention to their polarity. The pin of the head moves to the fully open position, which makes it easier to mount the head on the reduction fitting.
  • Page 12 Slide the safety ring (3) into the “released” position. Slide the head (4) all the way onto the reducing fitting A.
  • Page 13 Pair the head with the Auraton 200 TRA, unless pairing has been done earlier. Close the head Heater with Danfoss RA-N insert In order to install the Auraton TRA head on a radiator with a Danfoss RA-N insert, perform the following procedure:...

  • Page 14: Restore Factory Settings

    Put on the two halves of the reduction fitting B (1) onto the Danfoss RA-N insert. Tighten all the way the reduction fitting A (2) on the installed reduction fitting B (1) Perform steps 2 to 8 in chapter Heater with insert M30x1,5 Restore factory settings Take off...

  • Page 15: Pairing Devices

    3 seconds. After 3 seconds, Auraton 200 TRA will send its ID to the Auraton TRA head, which will be signaled by a triple beep by the head. After successfully pairing the Auratona 200 TRA and the head, close the battery cover (if installed on the radiator).
  • Page 16 After approx. 30 [s], the head will start regulating the temperature. triple beep – the Auraton 200 TRA controller is not paired with the head. After closing the battery cover, the head WILL NOT implement the temperature control algorithm. The pairing process described in chapter must be carried out Pairing devices.

  • Page 17: Installation Tips

    Installation tips Auraton 200 TRA should be placed in the room where the head with the radiator is located or the room to which the relevant floor heating circuits are connected. It should not be placed next to a radiator, next to a door or in sunny places.
  • Page 18 Working mode control: LED, sound (head) / LCD (regulator) Security level: IP20 AURATON 200 TRA power supply: 2 x AAA 1.5V alkaline batteries Power supply for the TRA head: 2 x AAA 1.5V alkaline batteries TRA: radio frequency: 868 MHz...
