200 TRA
U SER ' S M ANU AL
EN

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 200 TRA and is the answer not in the manual?

Questions and answers

Related Manuals for AURATON 200 TRA

Summary of Contents for AURATON 200 TRA

  • Page 1 200 TRA U SER ’ S M ANU AL...

  • Page 2: Basic Information

    Auraton 200 TRA controller, receiving information about the current temperature in the room and the preset temperature. There can be any number of radiators with Auraton TRA heads in a room but all must be paired with the same Auraton 200 TRA controller. If the number of the Auraton TRA heads is larger, the speed of response of the radiators to changes of temperature in the room increases, which is very beneficial.
  • Page 3 AURATON 200 TRA temperature controller explained LCD display acknowledge or on/off key temperature decrease key temperature temporary temperature increase key decrease mode keys • hold – controller on/off ( • short press – acknowledge temperature setting (...

  • Page 4: Display Screen

    Display screen 1. Temperature In normal operating mode, the controller displays the temperature of the room it is installed in. 2. Temperature unit ( Indicates temperature displayed in centigrade. 3. Temporary temperature decrease mode indicator ( ) Appears when the temporary temperature decrease program is active.

  • Page 5: Battery Installation/Replacement

    Place two AAA 1.5 V batteries in the battery socket observing the correct polarity. Then, to improve the operation, remove the battery cover from the heads associated with this AURATON 200 TRA for 5 seconds, after this time reinstall it back.
  • Page 6 Fixing the controller to the wall To fix the AURATON 200 TRA controller to the wall: 1. Remove the enclosure (as described on the „Battery installation/ replacement” section). 2. Drill 2 holes diameter 6 mm in the wall (use the back of the controller enclosure to set the right spacing of the holes).

  • Page 7: Temperature Setting

    <ok key to acknowledge selection. FrostGuard function AURATON 200 TRA controller features the special FrostGuard function to protect the room from possible freezing. The function is activated when the controller is switched off. With the controller switched off, when the room temperature drops to 2°C, the Fr (...
  • Page 8 Setting the temporary temperature decrease mode If, for some reasons, you would like to decrease temperature in the room, everyday and at the same time, by 3°C, temporary reduction for 6 hours is possible. To do so: 1. Press and hold for 3 seconds both keys.
  • Page 9 Description of the AURATON TRA head The AURATON TRA head works with the wireless controller AURATON 200 TRA. The head is installed directly on the radiator. battery cover closing button signaling diode...
  • Page 10 Method of installation of the TRA head on a radiator with an M30x1.5 insert In order to install the Auraton TRA head on a radiator with the most common insert in the market, i.e. M30x1.5, the following actions must be performed:...
  • Page 11 Close the head battery cover. Installation on the head with a Danfoss RA-N insert In order to install the Auraton TRA head on a radiator with a Danfoss RA-N insert, perform the following procedure: a) Put on the two halves of the reduction fitting B onto the Danfoss RA-N insert.
  • Page 12 <ad> + <ok>for more than 3 [s]. 3. After 3 [s], the Auraton 200 TRA controller sends pairing data to the Auraton TRA head, which the head indicates with three beeps. 4. After successful pairing of the Auraton 200 TRA with the head, close...
  • Page 13 After a maximum of 4 hours, the head should automatically synchronize itself with the Auraton 200 TRA controller. This time can be reduced to 2 minutes if, after the reset of the Auraton 200 TRA controller, the tab is taken off from the head and reinstalled after 3 [s].

  • Page 14: Installation Tips

    Installation tips Auraton 200 TRA should be places in the same room with the head and the radiator. It should not be placed near the radiator, on doors, or in places exposed to sunlight. The head, on the other hand, should be installed on the radiator insert not more than 20 cm away from the radiator.

  • Page 15: Technical Specification

    24-hours Operation status control: LED diode, sound (head) / LCD (controller) Power supply of AURATON 200 TRA: 2 alkaline AAA 1.5 V batteries Power supply of the TRA head: 2 alkaline AAA 1.5 V batteries Radio frequency of the TRA:...
  • Page 16 20190118...
