MAXvent
MAXvent DN axial fans in explosion-proof design. Driven
directly with IEC standard motor for use in zone 1 (category
2), zone 2 (category 3) Group IIB+H2, zone 21 (category 2)
and zone 22 (category 3) Group IIIB
Assembly instructions
L-BAL-F076-GB 2025/11 Index 004
Keep for reference!
VENTILATOR-Typenschild
einkleben!
Part.-No. 00705156-GB
english
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for ZIEHL-ABEGG MAXvent DN31
Summary of Contents for ZIEHL-ABEGG MAXvent DN31
- Page 1 english MAXvent MAXvent DN axial fans in explosion-proof design. Driven directly with IEC standard motor for use in zone 1 (category 2), zone 2 (category 3) Group IIB+H2, zone 21 (category 2) and zone 22 (category 3) Group IIIB Assembly instructions Keep for reference! VENTILATOR-Typenschild einkleben!
-
Page 2: Table Of Contents
Assembly instructions MAXvent Content General notes ..........Scope of documentation . - Page 3 Assembly instructions MAXvent Connection cable & junction box ......Assembly in a humid atmosphere ..... . . Electrical installation .
-
Page 4: General Notes
Assembly instructions MAXvent General notes 1 General notes Compliance with the following instructions is mandatory to ensure the functionality and safety of the product. If the following instructions given especially but not limited for general safety, transport, storage, mounting, operating conditions, start-up, mainte- nance, repair, cleaning and disposal / recycling are not observed, the product may not operate safely and may cause a hazard to the life and limb of users and third parties. -
Page 5: Safety
Conveying abrasive, adhering and liquid media will cause material damage. • The conveyance of solid matter or solids content in the conveying medium is not permissible and can lead to dangerous situations. ZIEHL-ABEGG rejects any liability for damage of any kind as a result of such use. •... - Page 6 Assembly instructions MAXvent Safety • Protection of the motor against unusual heating according to EN 60204 must be ensured. • If the fan is accessible, guard grilles complying with EN 13857 must be installed. These must not be changed and must be adequately secured. •...
-
Page 7: Intended Use
Observe the permissible temperature classes on the rating plate. • ZIEHL-ABEGG fans from the MAXvent DN.. Series of categories EPL Gb, Gc for gas and EPL Db, Dc for dust with ignition protection type "h" due to design safety are suitable for conveying explosive atmospheres of groups IIA, IIB and IIB+H2, as well as groups IIIA and IIIB. -
Page 8: Special Hazards When Operating In Explosive Atmospheres
Assembly instructions MAXvent Safety 2.3 Special hazards when operating in explosive atmospheres When operating a fan in an explosive atmosphere and when conveying explosive gases with the fan, comply especially with the following potential hazards and ignition sources stated below: •... -
Page 9: Requirements Placed On The Personnel / Due Diligence
Assembly instructions MAXvent Safety The local provisions and regulations must be observed when planning and constructing the system. 2.6 Requirements placed on the personnel / due diligence Persons entrusted with any planning, installation, start-up, maintenance and servicing in connection with the product must have the corresponding qualifications and skills for their job. -
Page 10: Modifications/Interventions On The Product
ZIEHL-ABEGG. These parts are designed especially for the product. Parts acquired from other sources are not guaranteed to be designed and produced in accordance with the load and safety specifications. Parts and optional equipment not supplied by ZIEHL-ABEGG are not approved by ZIEHL-ABEGG for use. 2.9 Operator’s obligation of diligence •... -
Page 11: Product Overview
These customer specifications form the basis for the product design including the selection and allocation of suitable motors. ZIEHL-ABEGG cannot accept any liability for use cases that are not specified when ordering; the customer is responsible for taking precautionary measures against failure and damage to the fan. -
Page 12: Scope Of Application
(internal/external). • ZIEHL-ABEGG axial fans comply with the provisions of EN 14986 with regard to the regulations for selection of materials and protective measures in the possible contact areas between moving and rigid parts (tubular housing/impeller). Moving parts (impellers) are made of composite material (plastic). -
Page 13: Explosion Protection Zone
Assembly instructions MAXvent Product overview 3.1.2 Explosion protection zone MAXvent DN axial fans are only intended for conveying air or Zone 1 explosive atmos- pheres, EPL Gb and Zone 2, EPL Gc, as well as Zone 21, EPL Db and Zone 22, EPL 3.1.3 Equipment class EPL Gb and Gc or EPL Db and Dc fans are only approved for use in or for conveying explosive atmospheres of explosion groups IIA, IIB and IIB+H2, as well as explosion... -
Page 14: Fan Marking
Assembly instructions MAXvent Product overview 3.1.5 Fan marking Example for marking a MAXvent DN fan: II 2G Ex h IIB T4 Gb A fan marked in this manner would meet the following requirements. : General Ex marking • II: Group II requirements in accordance with Directive 2014/34/EU. Not suitable for underground applications! •... -
Page 15: Rating Plate
9 Airflow direction 2 Series 10 Country of manufacture 3 Part no. 11 ATEX marking 4 ZIEHL-ABEGG serial number, placeholder 12 Operating temperature range 5 Product standard 13 Rolling direct Type of current, rated voltage, way of con- 6 Customer number, optional... - Page 16 Assembly instructions MAXvent Product overview • Avoid extreme heat or cold (for the temperature range for storage and transport please see the technical data). • Watch out for possible damage to the packaging or fan. • Secure pallets during transport. •...
- Page 17 Assembly instructions MAXvent Product overview After unpacking proceed as follows: Fasten 4 hooks on the fan. " The hooks must point "outwards". " To turn the fan round, fasten the fan at 2 points so it does not warp. " L-BAL-F076-GB 2025/11 Index 004 Part.-No.
-
Page 18: Disposal
Assembly instructions MAXvent Mounting " Handling in the "horizontal axis" must be done at 4 points to prevent the flanges from warping. 3.4 Disposal Disposal must be carried out professionally and in an environmentally friendly way in accordance with the respective national legal stipulations. Separate the materials by type and in an environmentally-friendly way. -
Page 19: Particularities When Mounting Explosion Protected Fans
Assembly instructions MAXvent Mounting • Do not allow drilling chips, screws and other foreign bodies to reach the device interior! • Any use in ambient temperatures below -10 °C is dependent on not being subjected to unusual, sudden or mechanical loads or stresses on the material (for the min. permissible ambient temperature please see the technical data). -
Page 20: Installation, Protection From External Influences
Assembly instructions MAXvent Mounting The following vibration threshold values apply to fans used in industry: Threshold values ac- Rigid attachment mm/s (rms) Flexible attachment mm/s cording to ISO14694 Start-up value Alarm threshold 11.8 Switch-off value 12.5 4.2.2 Installation, protection from external influences Install the fan in a housing or in the system with no distortion or tension and protect it against the effects of external forces and vibrations (e.g. -
Page 21: Special Notes On Installing Axial Fans In The Maxvent Dn Series
As ZIEHL-ABEGG SE has no influence on the installation conditions that go beyond the delivered fan itself in this series, the customer or system manufacturer is responsible for compliance with all the necessary directives relevant to explosion protection. -
Page 22: Assembly Of The Maxvent Fan
Assembly instructions MAXvent Mounting 4.5 Assembly of the MAXvent fan Danger! • Motor and accessories (protective grille etc.) must be connected to earth. • Connection points must be reliably protected against the formation of corrosion. Observe the following points for all types of fans: •... - Page 23 Assembly instructions MAXvent Mounting The following minimum gap dimensions between the fan impeller and the inlet nozzle must be maintained, depending on the relevant contact diam- eter: fan type Size Relevant contact di- a (min.) Setting dimen- ameter sion or test di- mension a DN31 306.30...
-
Page 24: Connection Cable & Junction Box
Mounting Information ZIEHL-ABEGG supplies type “F” and “K” flange ring fans without an inlet nozzle. The axial supply from the unit/system structure must be as twist-free as possible and should have no additional air resistance. Disturbances in the supply may impair the function of the fan. -
Page 25: Electrical Installation
Assembly instructions MAXvent Electrical installation 5 Electrical installation 5.1 Safety precautions Danger due to electric current • Work on electric components may only be carried out by trained electricians or by persons instructed in electricity under the supervision of an electrician in accordance with electrical engineering regulations. -
Page 26: Frequency Inverter And Emc
• When operating on the inverter harmful bearing currents can occur in the motor. This depends on many factors which, in many cases, ZIEHL-ABEGG cannot influence. Thus, it comes down to the expert installation in the respective assembly situation. The following points serve as a guideline, but cannot always prevent bearing currents from occurring. -
Page 27: Electrical Connection, Grounding And Protection
Assembly instructions MAXvent Electrical installation • The specified measures with regard to EMC-compatible installation must be observed and implemented. • For electrical bridging of vibration dampers, use high-frequency equipotential bonding conductors made of braided flat copper strips with a minimum cross-section of 16mm². -
Page 28: Mains Connection
The motors contain triple thermistors. No more than two PTC thermistor chains may be connected in series, as this can lead to undefined shutdown. • Tripping device for motors with thermistors “TP” (PTC thermistor) e.g. ZIEHL-ABEGG type U-EK230E with switch-off via a contactor. •... -
Page 29: Start-Up
• ZIEHL-ABEGG SE fans are delivered balanced in compliance with DIN ISO 21940-11 for the corresponding fan category as set out in ISO 14694. Check the fan for mechanical vibrations after installation. If the limit values for the corresponding fan... -
Page 30: Troubleshooting
Assembly instructions MAXvent Troubleshooting Danger! When in operation with a frequency converter, no overmodulation is allowed. The fan wheel may burst – danger to life! In addition, perform the following tests before switching on an explosion-pro- tected fan: • Check the operating conditions / process parameters (see "Use as Intended"). Above all, ensure that the maximum permissible value for the speed, intake and ambient temperature (see rating plate) are never exceeded under any conditions and are never exceeded at any time! -
Page 31: Possible Causes And Remedial Measures
Assembly instructions MAXvent Troubleshooting Danger! Repair work which is not carried out correctly can result in serious injuries and/or material damage. • Please read the Safety instructions chapter before working on the fan! • Before working on the fan, this must be disconnected from the power supply and secured against switching back on! 7.2 Possible causes and remedial measures Type of error... -
Page 32: Maintenance
Check the blade(s) for damage, contamination or ice formation See “Impeller blocked or dirty” Unusual noises ball bearing damaged/worn Replacement of ball bearings by ZIEHL-ABEGG re- quired Impeller / blade drags / When indicated clear foreign bodies / dirt from the fan scrapes See “Impeller blocked or dirty”... - Page 33 Maintenance • Bolted-on impellers and/or wings may only be replaced by authorised ZIEHL-ABEGG SE staff. The manufacturer shall not be liable for damage caused through improper repair work. • In the case of complete dismantling and reinstallation of the fan, checking must be carried out before start-up (see start-up).
-
Page 34: Particularities When Using In Explosive Atmospheres
Be aware of the following Points: • ZIEHL-ABEGG recommends that during the phase of commissioning of a new fan, a visual inspection during which the fan is especially checked for the tight seating of all bolted connections, dirt, vibrations and unusual noises is undertaken at least weekly. -
Page 35: Motor And Bearing
Assembly instructions MAXvent Maintenance 8.2.2 Motor and bearing Inspect and clean the motor in regular intervals. This prevents the formation of dust and dirt layers, which present a risk of ignition, e.g. due to static electricity. Bearing wear may produce vibrations and shaft clearance, which can lead to the impeller coming into contact with stationary parts (e.g. -
Page 36: Clearances And Gap Dimension
Assembly instructions MAXvent Maintenance 8.2.5 Clearances and gap dimension Before reconnection of the fan after maintenance work, proceed as described in the Commissioning chapter. Above all, undertake the gap dimension check in accordance with "Protection against the Contact of Rotating and Stationary Parts" before putting into operation! 8.2.6 Flexible connections and seals Flexible connections (expansion joints) and seals can wear and become leaky. -
Page 37: Enclosure
Electronically commutated internal or external rotor motor with integrated EC controller Complies with the requirements in Appendix I, Articles 1.1.2, 1.1.5, 1.4.1, 1.5.1 in EC Machinery Directive 2006/42/EC. The manufacturer is ZIEHL-ABEGG SE Heinz-Ziehl-Straße D-74653 Künzelsau The following harmonized standards have been applied: EN 60204-1:2018 Safety of machinery –... - Page 38 Start-up of this incomplete machine is prohibited until it is ensured that the machine in which it has been installed complies with the provisions of the EC Machinery Directive. Künzelsau, 22.10.2024 (Location, date of issue) ZIEHL-ABEGG SE ZIEHL-ABEGG SE Moritz Krämer Jürgen Albig Director Product Development...
-
Page 39: Eu Declaration Of Conformity
Assembly instructions MAXvent Enclosure EU declaration of conformity - Translation - (english) ZA152ex-GB 2024/46 Index 005 The manufacturer is ZIEHL-ABEGG SE Heinz-Ziehl-Straße 74653 Künzelsau Germany The manufacturer is solely responsible for issuance of the declaration of conformity. The products: •... - Page 40 Assembly instructions MAXvent Enclosure Type Zone Equip- Type of pro- Explosion Tempera- Equipment protec- ment tection group* ture class* tion level EPL class Axial fan DN... h, (c) IIIA, IIIB, T 125°C IIIC Axial fan DN... h, (c) IIIA, IIIB, T 125°C IIIC Centrifugal...
- Page 41 Ex directives. The following persons are authorized to compile the technical documents, address see above. Künzelsau, 15.11.2024 (Location, date of issue) ZIEHL-ABEGG SE ZIEHL-ABEGG SE Moritz Krämer Jürgen Albig Director Product Development...
-
Page 42: Index
Assembly instructions MAXvent 9.3 Index Assembly 3, 24 gap dimension axis guard grilles ball bearing Imbalance impeller internal rotor motors cable glands capacitor charges lead to sparking cold greasing lightning protection linevoltage direction of rotation dismantling mains connection Drain holes material combinations 6, 12 dust... - Page 43 Assembly instructions MAXvent Tightening torques transformers transmitters tubular housing vibration monitoring system Zone 2 Zone 21 L-BAL-F076-GB 2025/11 Index 004 Part.-No. 00705156-GB 43/44...
-
Page 44: Manufacturer Reference
9.4 Manufacturer reference Our products are manufactured in accordance with the relevant international regulations. If you have any questions concerning the use of our products or plan special uses, please contact: ZIEHL-ABEGG SE Heinz-Ziehl-Straße 74653 Künzelsau phone: +49 (0) 7940 16-0 info@ziehl-abegg.de...
